Summary of Contents for Blanco BDW146X

  • Page 1 BDW146X 14 place settings half-load function...
  • Page 2 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only. (Follow the User Manual Check the rinse aid level...
  • Page 3 Dear Customer, This appliance is in tended to be used in household and similar app lications such as: -staff kitch en areas in shop s, offices and other workin g en viron ments; -farm hous es; -by clients in hotels, motels and othe r residential type environments; -bed and breakfast type environments.
  • Page 4 CONTENTS Control Panel.......................2 Dishwasher Fe atures....................2 、 A Fill th e Rin se Aid Disp enser..................3 、 B Function of Dete rgent .....................4 Attention before or after loading the Dishwasher Baskets........................6 The Method of Loading Normal Dishware ............
  • Page 5 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of an electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
  • Page 6 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. 1. On/Off Button: to switch On/Off the a ppliance. 7. Half load function Button: To select Half load functio n. (With this Half load function you can 2.
  • Page 7 Before using your dishwas her for the first time: Fill th e rinse a id dispenser Function Of Detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks.

  • Page 8: Adjusting Rinse Aid Dispenser

    Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are a pro ble m, increase the amount of rinse aid dispensed by removing the dispe nser lid and rotating the dial to "5". If the dishes are still not drying properly or are showing spots, adjust the dial to the next higher lever until your dishes are spot-free.

  • Page 9: Amount Of Detergent To Use

    Amount of Detergent to Use If th e lid is close d: press rele ase button. The lid will spring ope n. Always add the dete rgent just before starting each wash cycle. Only use branded detergent aid for d ishwash er. Dishwasher detergent is corrosive.
  • Page 10 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, do not take gla ss a nd c utlery out of the dishwasher immediately after the programme h as ended.

  • Page 11: Adjusting The Upper Basket

    The Method Loading Normal Dishware The Method Loading Normal Dishware Loading the Lower Basket Loading the Lower Basket Loading the Upper Basket Loading the Upper Basket The upper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clean items into the lower basket: such as tea cups and saucers, as well as plates, small bowls...
  • Page 12 Cutlery tray can be 5 different positions Mode 1 Position one: lift the left basket up, both left and right baskets are slanting. Mode 2 Position two: adjust the left basket to lower position, left basket is flat and right basket is slanting. Mode 3 Position three: lift the right basket up, both left and right baskets are flat.
  • Page 13 Means: need to fill rinse into the Rinse-Aid Dispenser. Means: need to fill rinse into the Rinse-Aid Dispenser. ℃ Pre-wash(50 ) ℃ Wash (65 Intensive For heaviest soiled crockery, Rinse 、 、 /27.5g and soiled pots pans 1.40 18.0 Rinse (Or All dishes etc with dried ℃...

  • Page 14: Unloading The Dishwasher

    When you press th e Start/Pause button to pause du ring washing, the running indicator will stop blinking a nd the dishwasher will be beeping eve ry minu te unless you press the Start/Pause button to start. A cycle that is underway can on ly be modified if it has only been running for a short time. Otherwise, the detergent may have already be en released, a nd the appliance may have already drained the wash water.

  • Page 15: Filter Assembly

    The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Fo od and soil particles trap ped in this filter are pulverized by a specia l jet on the lower spray arm and washed down to drain.

  • Page 16: Cleaning The Filter

    Remarks: - Inspect the filters for blo cking a fter e very time the dishwa sher has been used. - By unscrewing the coarse filter, you can remove the filter system. Re move any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week.

  • Page 17: Moving The Appliance

    When not in Use for a Long Time After Every Wash It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty an d the n remove the plug from the appliance and leave the door slightly open so that socket, turn off the wa ter supply and leave the door of moisture and odours are not trapped inside.
  • Page 18 Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.

  • Page 19: Water Outlet

    Insert the drain h ose into a drain pipe with a minimum diameter of 40mm, or let it run into the sink, making sure to avo id bendin g or crimping it. The top of the ho se must be less than 100 0mm. Front Counter NOTE...
  • Page 20 Fuse blown, or the home Replace fuse or reset circuit breaker. Remove any other circuit breaker has been appliances sharing the same circuit with the dishwasher triggered. Make sure the dishwasher is turned on and the door is Power supply is not closed securely.
  • Page 21 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
  • Page 22 Height : 845mm Width : 598 mm (with the door closed) Depth : 600mm Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 14 place settings...
