INSTRUCTION MANUAL FOR
BLANCO DISHWASHER
BSID1465X

Advertisement

loading
Need help?

Need help?

Do you have a question about the BSID1465X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blanco BSID1465X

Summary of Contents for Blanco BSID1465X

  • Page 1 INSTRUCTION MANUAL FOR BLANCO DISHWASHER BSID1465X...
  • Page 2 You will find that the clean lines and modern look of your Blanco appliance blends in perfectly with your kitchen décor. It is easy to use and performs to a high standard.

  • Page 3: Table Of Contents

    Table of Contents Important Safety Instructions ………………………………………………………………………………4 Product Description …………………………………………………………………………………………5 Installation ……………………………………………………………………………………………..…6-13 Operation Instruction ……………………………………………………………………….………….14-28 Maintenance and Cleaning ……………………………………………………………………..…….29-32 Troubleshooting Tips ………………………………………………………………………………,…33-36 Product Specification ……………………….…………………………………………………....37 Australian & New Zealand Product Warranty Statements of Standard Warranty Conditions……..38 Disposal Information  Most of the packaging materials are recyclable. Please dispose of these materials through your local recycling depot or by placing them into appropriate collection containers.

  • Page 4: Important Safety Instructions

    Important Safety Instructions Read the assembly instruction and safety precaution sections of this IMPORTANT: booklet before removing the contents of the carton. This appliance is intended to be used in household and similar applications , such as: a. staff kitchen areas in shops, offices and other working environments; b.

  • Page 5: Product Description

    Product Description IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Product Overview...

  • Page 6: Installation

    Installation Product Dimensions Height (H) 815 mm Width (W) 598 mm Depth (D1) 570 mm (with the door closed) Depth (D2) 1150 mm (with the door opened 90°)
  • Page 7 Installation Water Supply and Drain Cold water connection Connect the cold water supply hose to a threaded 3/4 inch connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear.
  • Page 8 Installation Connection of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000mm. The free end of the hose must not be immersed in water to avoid the back flow of it.
  • Page 9 Installation Position the Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can be positioned either to the right or the left sides to facilitate proper installation. Step 1.
  • Page 10 Installation Step 2. Aesthetic panel’s dimensions and installation Note The aesthetic wooden panel could be processed according to the installation drawings. Semi-integrated model Magical paster A and magical paster B be disjoined on, magical paster A on the aesthetic wooden panel and felted magical paster B of the outer door of dishwasher (see figure A).
  • Page 11 Installation Step 4. Dishwasher installation steps Note Please refer to the specified installation steps in the installation drawings. r to the specified installation steps in the installation 1. Affix the condensation strip under the work surface of cabinet. Please ensure the condensation strip is flush with edge of work surface.
  • Page 12 Installation Levelling the Dishwasher Dishwasher must be level for proper dish rack operation and wash performance. 1. Place a spirit level on door and rack track inside the tub as shown to check that the dishwasher is level. 2. Level the dishwasher by adjusting the three levelling legs individually. 3.
  • Page 13 Installation Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. The installation of the pipes and electrical equipments should be done by professionals. For personal safety: Do not use an extension cord or an adapter plug with this appliance. Do not, under any circumstances, cut or remove the earthing connection from the power cord.
  • Page 14 Operating Instruction QUICK USER GUIDE Please read the corresponding content the instruction manual for detailed operating method. Install the dishwasher (Please refer to “Installation Instruction” Section Removing the larger residue Loading the baskets on the cutlery Filling the dispenser Selecting a program and running the dishwasher...
  • Page 15 Operating Instruction USING YOUR DISHWASHER Before using your dishwasher: 1. Loading the basket 2. Fill the rinse aid dispenser 3. Fill in detergent Basket Used Tips Adjusting the upper basket Type 1: The height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket.
  • Page 16 Operating Instructions USING YOUR DISHWASHER Type 2: To raise the upper basket, just lift the To lower the upper basket, lift the adjust upper basket at the center of each side handles on each side to release the until the basket locks into place in the basket and lower it to the lower position.

  • Page 17: Operation Instruction

    Operating Instructions Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen will light up. Power Select the appropriate washing program, the selected program indicator Program will be lit. Press the button to select either upper basket or lower basket loaded, and the response indicators will be lit.
  • Page 18 Operating Instructions Display (Indicator) Function Upper basket loaded indicator To show upper basket loaded function starting up or not. Lower basket loaded To show lower basket loaded function starting up or not Warning Rinse Aid indicator If the “ ” indicator is lit, it means the dishwasher is low on dishwasher rinse aid and requires a refill.
  • Page 19 Operating Instructions Preparing and Loading Dishes  Consider buying utensils which are identified as dishwasher-proof.  For delicate items, select a program with the lowest possible temperature.  To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended.
  • Page 20 Operating Instructions Removing the dishes To prevent water dripping from the upper basket into the lower basket, we recommend that you empty the lower basket first, followed by the upper basket. WARNING Items will be hot ! To prevent damage, do not take glass and cutlery out of the dishwasher for around 15 minutes after the program has ended.
  • Page 21 Operating Instructions Loading the cutlery basket Cutlery should be placed in the cutlery rack separately from each other in the appropriate positions, and do make sure the utensils do not nest together, this may cause bad performance. WARNING Do not let any item extend through the bottom.
  • Page 22 Operating Instructions Function of detergent The chemical ingredients that compose the detergent are necessary to remove, crush and dispense all dirt out of the dishwasher. Most of the commercial quality detergents are suitable for this purpose. WARNING  Proper Use of Detergent Use only detergent specifically made for dishwashers use.
  • Page 23 Operating Instructions Adjusting the rinse aid reservoir The rinse aid reservoir has six settings. Both the recommended setting and the factory setting is “4”. If the dishes are not drying properly or are spotted, adjust the dial to the next higher number until your dishes are spot-free.
  • Page 24 Operating Instructions Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also shows various information about the programs. Means: need to fill rinse into the Rinse-Aid Dispenser.
  • Page 25 Operating Instructions NOTE: *AS/NZS 2007.1: This program is the test cycle. The information for comparability test in accordance with AS/NZS 2007.1. Starting a Cycle Wash 1. Draw out the lower and upper basket, load the dishes and push them back. It is commended to load the lower basket first, then the upper one.
  • Page 26 Operating Instructions Forget To Add A Dish? A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1. Press the Start/Pause button to pause the washing. 2. Wait 5 seconds then open the door. 3.
  • Page 27 Operating Instructions LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1:...
  • Page 28 Operating Instructions LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1: Information for comparability tests in accordance with (*AS/NZS 2007.1 ) Capacity: 14 place settings Position of the upper basket: lower position Program: Normal Rinse aid setting: 6 Detergent(Pre/main): 5g/27.5g Door is open at the end of the drying cycle for the drying performance test (Door position: Open 50 mm)

  • Page 29: Maintenance And Cleaning

    Maintenance and Cleaning WARNING: Disconnect the dishwasher from the power supply (unplug or switch off at the circuit breaker) and allow all its parts to cool before any cleaning or maintenance. External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door.
  • Page 30 Maintenance and Cleaning Hold the coarse filter and rotate it The fine filter can be pulled off the anticlockwise to unlock the filter. Lift bottom of the filter assembly. The the filter upwards and out of the coarse filter can be detached from the dishwasher.
  • Page 31 Maintenance and Cleaning Spray arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the lower spray arm, pull To remove the upper spray arm, hold the out the spray arm upward.
  • Page 32 Maintenance and Cleaning Caring For The Dishwasher Frost precaution Please take frost protection measures on the dishwasher in winter. Every time after washing cycles, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2.

  • Page 33: Troubleshooting Tips

    Troubleshooting Tip Before Calling For Service Before calling for service, check the following list for problems probable causes and what you can Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the circuit break Replace fuse or reset circuit tripped.
  • Page 34 Troubleshooting Tip Problem Possible Causes What To Do Stained tub interior Detergent with colourant may Make sure that the detergent has have been used. no colourant. White film on Hard water minerals. To clean the interior, use a damp sponge with dishwasher detergent inside surface and wear rubber gloves.
  • Page 35 Troubleshooting Tip Problem Possible Causes What To Do Detergent left in Dishes block detergent dispenser Re-loading the dishes properly. dispenser The dishes aren't Improper loading Load the dishwasher as suggested drying in the directions. Too little rinse-aid Increase the amount of rinse- aid/refill the rinse-aid dispenser Dishes are removed too soon Do not empty your dishwasher...
  • Page 36 Troubleshooting Tip If there is a malfunction, the dishwasher will display error codes to identify these: Codes Meanings Possible Causes Longer inlet time. Faucets is not opened, or water intake is restricted, or water pressure is too low. Not reaching required Malfunction of heating element.

  • Page 37: Product Specification

    Product Specification Standard place settings 14 place settings Energy efficiency class Water consumption class Standard cleaning cycle Normal Energy consumption of the standard cleaning 0.73 kWh cycle Water consumption of the standard cleaning 12 liter cycle Program duration of the standard cleaning 170 mins cycle Noise level...

  • Page 38: Australian & New Zealand Product Warranty Statements Of Standard Warranty Conditions

    WHAT IS COVERED: By Our Warranty During the warranty period, Blanco or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
  • Page 39 We appreciate your feedback. Please review our products at www.blanco-australia.com...
