Summary of Contents for Blanco BDW6345W
- Page 1 INSTRUCTION MANUAL FOR BLANCO DISHWASHER BDW6345W...
- Page 2 You will find that the clean lines and modern look of your Blanco appliance blends in perfectly with your kitchen décor. It is easy to use and performs to a high standard.
-
Page 3: Table Of Contents
Table of Contents Safety Information ............................1-2 Specifications ..............................3 Installation ..............................4-6 Usage ................................7-8 Loading Your Dishwasher ..........................9-12 Program Descriptions ............................13 Operating Instructions ..........................14-16 Maintenance and Cleaning ......................... 17-18 Responding to Problems ..........................19-20... -
Page 4: Safety Information
Do not put into your machine those items which are not suitable for dishwashing. Do not fill any basket above its capacity. Blanco is not responsible for any scratches or rust on the interior of your machine due to basket movement. - Page 5 Safety Information Because hot water may flow out, the door should not be opened under any circumstances whilst the machine is in operation. A safety device ensures that the machine stops if the door is opened. Do not leave the door open as this can be a tripping hazard. ...
-
Page 6: Specifications
Specifications Capacity 15 Place Settings Height 850 mm Height (without worktop) 820 mm Width 598 mm Depth 598 mm Net Weight 52 kg 220 – 240 V, 50 Hz Electricity Input Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W... -
Page 7: Installation
Installation Positioning the machine When determining where to install your machine, take care to choose a place where you can easily load and unload it. Make sure not to install the machine where there is the possibility that the ambient temperature will fall below 0°C. - Page 8 If there is no earth connection, have a competent electrician carry out an earthing installation. In the case of usage without proper earthing, Blanco will not be responsible for damage that might occur. The indoor fuse current value should be 10-16 A.
- Page 9 Installation Fitting the Machine under a Counter If you wish to fit your machine under a counter, check whether you have sufficient space under your countertop and whether the wiring and plumbing is suitable to do so. If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
-
Page 10: Usage
Usage Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. Remove all packaging materials inside the machine. Fill the rinse aid compartment. Detergent Use a detergent specifically designed for use in domestic dishwashers. - Page 11 Usage Points to Consider when using Combined Detergent: Always make sure to check the specifications of the product you will use and whether or not it is a combined product. Observe the instructions on the packaging when using such products. ...
-
Page 12: Loading Your Dishwasher
Loading Your Dishwasher Placing dishes into the machine properly will allow it to operate with the highest efficiency and performance. There are two separate baskets for you to load your dishes into your machine. The lower basket has been designed to hold items such as round and deep items like pots with long handles, pot lids, plates, salad plates and cutlery sets. - Page 13 Loading Your Dishwasher Spoon Rack The spoon rack provides a convenient area for you to place your forks and spoons. It also functions as a brace for you to lean your long- stemmed glasses and goblets against. This ensures that they remain secure and upright during washing.
- Page 14 Loading Your Dishwasher Lower Basket – Folding Racks The lower basket contains four folding racks which are designed to allow you to place large items such as pots and pans into the basket easier. Each part can be folded down separately, if required. Modular Cutlery Basket The cutlery basket can be separated into two parts and placed in different locations...
- Page 15 Loading Your Dishwasher Incorrect Loading For maximum cleaning performance, ensure that you do not overload the machine, obstruct the spinning arms, or place dishes on top of one another. Items which hold fluids, such as bowls, pots and glasses, should be placed facing down so as to not fill with water during the washing cycle.
-
Page 16: Program Descriptions
Program Descriptions Program Number Prewash Quick *Super Daily Intensive 40°C 50°C 65°C 60°C 70°C Temperature Duration (mins) Small Medium Medium Small Large Level of Dirtiness Electricity Consumption (kW 0.02 0.84 0.79 1.21 1.34 1.73 hours) Water Consumption 10.9 13.5 10.7 14.4 24.6 (litres) -
Page 17: Operating Instructions
Operating Instructions 1. ON/OFF Button Pushing this buttons turns the machine on or off. 2. Extra Hygiene Button By using this option, washing temperature and periods during respective cycles may be changed, which ensures more hygienic washing. 3. Tablet Detergent Button Push this button when using combined detergent that contains rinse-aid and extra functions. - Page 18 Operating Instructions Switching on the Machine 1) Press the Power On/Off button 2) Select the program suiting your dishes via the Program Selector button. 3) If you prefer, you can choose additional functions. 4) Start the program by pressing the Start/Pause button. Tracking the Cycle Progress You can follow the progress of the wash cycle by using the lights located on the control panel.
- Page 19 Operating Instructions Cancelling a Wash You can cancel a wash that has already begun. Switching the Machine Off Note: Leaving the door slightly open during the drying stage will result in your dishes drying faster. Note: If the door is opened or the power is cut whilst the machine is washing, the program will resume once the door is shut or power restored.
-
Page 20: Maintenance And Cleaning
Maintenance and Cleaning Cleaning the machine at regular intervals prolongs its service life. NOTE: Unplug your machine and turn off the water inlet before performing any maintenance or cleaning. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation: Fill the detergent compartment without loading any dishes into the machine, select a program that runs at high temperature, and start the machine. - Page 21 Maintenance and Cleaning Spray Arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning it to the left.
-
Page 22: Responding To Problems
Responding to Problems Error Error Description What to do Code Make sure the water input tap is totally open and that there is no water cut. Close the water input tap, separate the water input hose Inadequate water supply from the tap and clean the filter at the connection end of the hose. - Page 23 Responding to Problems If the machine stops during a wash operation: Power failure. Water inlet failure. Program can be on standby mode. If shaking and hitting noises are heard during a wash operation: Dishes placed incorrectly. ...
- Page 24 WHAT IS COVERED: By Our Warranty During the warranty period, Blanco or its authorised Service Centre will, at no extra charge, if your appliance is readily accessible without the need of special equipment and subject to the terms and conditions of this warranty, repair or replace any parts which it considers defective.
- Page 25 We appreciate your feedback. Please review our products at www.blanco-australia.com...
