Jøtul F 50 TL Rangeley
Installation and Operating Instructions
Keep these instructions for future reference.

Advertisement

Table of Contents
loading

Summary of Contents for Jøtul F 50 TL Rangeley

  • Page 1 Jøtul F 50 TL Rangeley Installation and Operating Instructions Keep these instructions for future reference.
  • Page 2: Table Of Contents

    139262 Rev_N F 50 TL Rangeley 2/16 Table of Contents Installation and Operation Accessories Instructions for USA/Canada ................... 2 Standards and Safety Notices Installation et Standards / Codes ................3 ..Safety Notices .................. 4 fonctionnement pour Canada 1.0 Installation 1.1.
  • Page 3 Gorham, Maine 04038-2644 manufactured after May 15, 2015. The Jøtul F 50 TL Rangeley wood stove is listed to burn solid wood only. Do not burn any other fuels. This manual describes the installation and operation of Check Building Codes the Jøtul F 50 TL Rangeley non-catalytic wood heater.
  • Page 4: Safety Notices

    139262 Rev_N F 50 TL Rangeley 2/16 Safety Notices Installation Tools Required, but not • BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT limited to: BURN ANY OTHER FUEL. • Measuring Tape • DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE.
  • Page 5: Installation

    139262 Rev_N F 50 TL Rangeley 2/16 1.0 Installation 27 1/4” (692 mm) If this solid fuel room heater is not properly installed, a house fire may result. For your safety, follow the installation directions. Contact the local building or fire officials about restrictions and installation inspection requirements in your area.
  • Page 6: Flue Collar Installation

    139262 Rev_N F 50 TL Rangeley 2/16 1.2 Flue Collar Orientation Figure 2. Flue Collar heat shield attachment. The Flue Collar is oriented in the Top Exit position. To change orientation to Rear Exit: 1. Twist and remove the perforated cut-out section from the top edge of the rear shroud.
  • Page 7: Chimney Requirements

    139262 Rev_N F 50 TL Rangeley 2/16 A short exterior masonry chimney will give the poorest Figure 5. performance because it will be difficult to warm the flue Chimney connector and sustain the temperatures necessary to maintain draft orientation. strength. In extremely cold climates, it may be necessary to reline the chimney or extend the height to help establish draft.
  • Page 8: Prefabricated Chimneys

    139262 Rev_N F 50 TL Rangeley 2/16 2.2 Prefabricated Chimneys Figure 7. 2’ A prefabricated metal chimney must be tested and Chimney Height 61 cm 3’ listed for use with solid fuel burning appliances. High Requirement. 10’ 91.5 cm Temperature (HT) Chimney Standard UL 103 for the U.S. and 305 cm High Temperature Standard ULC S-629 for Canada.
  • Page 9: Connecting To The Chimney

    139262 Rev_N F 50 TL Rangeley 2/16 Refractory mortar must be used at the junction of the 3.2 Hearthmount into a Masonry chimney and the pass-through liner. The pass-through Fireplace liner must not penetrate the chimney liner beyond the inner surface of the chimney liner. Use extreme care when The Jøtul F 50 TL may be installed into a masonry fireplace...
  • Page 10: Prefabricated Chimneys

    139262 Rev_N F 50 TL Rangeley 2/16 3.4 Mobile Home Installation The cross-sectional area of the flue of a chimney with one or more walls exposed to the outside below the roofline The Jøtul F 50 TL is approved for installation in...
  • Page 11: Clearances To Combustibles

    139262 Rev_N F 50 TL Rangeley 2/16 4.0 Clearance to Combustibles 4.1 Floor Protection 2” The Jøtul F 50 TL includes a bottom heat shield which must 2” be installed unless the stove is on a concrete floor poured on earth.
  • Page 12: Alcove Installation

    139262 Rev_N F 50 TL Rangeley 2/16 19” 8” (203 mm) (483 mm) Maximum Maximum 48” 48” (1219 mm) (1219 mm) 6” 6” 16” 16” (152 mm) (152 mm) (406 mm) (406 mm) 39 1/2” (1003 mm) 59 1/2” (1511 mm) Figure 13.
  • Page 13: Clearance Diagrams

    139262 Rev_N F 50 TL Rangeley 2/16 4.6 Jøtul F 50 TL Rangeley Clearance Specifications PROTECTED WALLS UNPROTECTED WALLS PER NFPA211 OR CAN/CSA -B365-M93 SIDE REAR CORNER SIDE REAR CORNER Single Wall Connector 14” / 356 mm 18” / 457 mm 12”...
  • Page 14: Operation

    Please read the following section before building the first GLASS. KEEP THE LOGS SPACED AT LEAST ONE INCH FROM fire in your new Jøtul F 50 TL Rangeley. THE GLASS TO ALLOW FOR PROPER AIR FLOW WITHIN THE STOVE. AVOID STRIKING THE GLASS WITH LOGS.
  • Page 15: F 50 Tl Rangeley Functionality

    139262 Rev_N F 50 TL Rangeley 2/16 NOTE: Avoid letting logs rest directly on the glass panel. The logs should be spaced off of the glass enough to allow for proper air flow within the firebox. 5.4 F 50 TL Rangeley Functionality...
  • Page 16: Controlling The Fire

    400° and 5.8 Break-In Procedure 700° (204°C -371°C). Chimney draft should be in the Although your Jøtul F 50 TL Rangeley is constructed of .05 - 1.0 w.c. range. welded, 1/4” steel plate, it also incorporates cast iron components.
  • Page 17: Adding Fuel

    139262 Rev_N F 50 TL Rangeley 2/16 5.10 Adding Fuel 5.12 Creosote Formation and the Follow this procedure when reloading the stove while it is still hot and a bed of hot embers remains: Need for Removal • Always wear gloves when tending to the stove.
  • Page 18: Maintenance

    139262 Rev_N F 50 TL Rangeley 2/16 6.0 Maintenance 6.1 Door Latch Adjustment Shim Plates Over time, as the door gasket becomes compressed, it may be necessary to adjust the door latch in order to maintain the integrity of the door seal. To check the seal of the front door, close and latch the door on a dollar bill and slowly try to pull the bill free.
  • Page 19: General Care

    139262 Rev_N F 50 TL Rangeley 2/16 6.3 General Care 6.6 Chimney System As with your car, regular maintenance will assure good The Jøtul F 50 TL is designed to burn cleanly and efficiently performance and prolong the life of your stove. The when used according to the guidelines in this manual.
  • Page 20: Appendix

    139262 Rev_N F 50 TL Rangeley 2/16 2. Attach the Air Deflector: See figs. 21 and 22 /#3. 7.0 Appendix Use pliers to bend the deflector tabs at the perforation lines as shown. Attach the deflector to the interior side of the rear shroud using two #8 X 12 sheet metal screws from the exterior side.
  • Page 21 139262 Rev_N F 50 TL Rangeley 2/16 Figure 23. Blower Parts Identification. Lower Air Deflector Blower Assembly Snapstat Blower Mounting Bracket Snapstat Bracket Air Deflector M6 Flange Hex Nut (3) Control Box Assembly M6 Wingnut (2) Control Box Bracket 10. #8 x 1/2” sheet metal screws (9) 8.
  • Page 22: Outside Air Kit Installation

    139262 Rev_N F 50 TL Rangeley 2/16 Front Manifold Main Manifold M6 Hex Nuts, M6 Hex Nuts 4” Duct Collar #8 x 12 Sheet M6 Hex Nuts, Metal Screws Outside Air Bottom Heat Shield Figure 25. Outside Air Kit parts identification and orientation.
  • Page 23: Mobile Home Floor Bracket

    139262 Rev_N F 50 TL Rangeley 2/16 4. Orient the Front Manifold Panel as shown in figs. 25 and 26. Set it in place above the ash housing between the front legs of the stove. 5. Attach the Main Manifold to the four studs on the stove bottom and the two studs on the Front Manifold using the hex head nuts provided.
  • Page 24: Illustrated Part List

    139262 Rev_N F 50 TL Rangeley 2/16 Figure 29. F 50 TL Illustrated Parts...
  • Page 25 139262 Rev_N F 50 TL Rangeley 2/16 8.0 Jøtul 50 TL Rangeley Part List Description Part Number Description Part Number Air Baffle Manifold Assembly 157345 Hinge Pin - Grooved, Nickel Plate 225098 Gasket, LD2, .500 Ø Fiberglass Rope, SS Jacket 223828 Slotted Spring Pin, 5mm Ø...
  • Page 26: Warranty Statement

    139262 Rev_N F 50 TL Rangeley 2/16 9.0 Jøtul F 50 TL Rangeley the stove with the ash door open, can damage the stove. Over-firing Limited Lifetime Warranty occurs when any part of the stove glows red. Over-firing can also be...
  • Page 27 139262 Rev_N F 50 TL Rangeley 2/16 This page is intentionally blank.
  • Page 28 139262 Rev_N F 50 TL Rangeley 2/16 Jøtul pursues a policy of continuous product development. Products supplied may therefore differ in specification, colour and type of accessories from those illustrated and described in this manual. Jøtul North America Inc. P.O. Box 1157...
