Summary of Contents for Repotec RP-G3224DB
- Page 1 24-Port 10/100M + 2-Port Gigabit Fast Ethernet Switch User´s Manual V1.0 P a g e...
-
Page 2: Ce Mark Warning
FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Hardware Installation
The Ethernet Switch is suitable for the networking of small and medium-sized enterprises, Internet cafe and households. The Ethernet Switch provides 24 * 10/100M, 2 * 10/100/1000M, and 2 SFP Ports. HARDWARE INSTALLATION Location Choose a suitable location for the rack mountable switch, considering the following requirements: Suitable power source ... -
Page 4: Led Indicators
LED Indicators When the power to the switch is on, the following indicators show system status: Technical Specifications Items Specification Standards and IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, Protocols IEEE 802.3x 24 10/100M auto-negotiation RJ45 port Fixed Port 2 gigabit uplink RJ45/SFP(mini GBIC) multiplex port 10Base-T: Category 3/4/5 UTP, support maximum transmission distance 100m... -
Page 5: Package Contents
Storage Humidity 5%～90% RH Non-Condensing Heat Dissipation natural heat dissipation Package contents: Fast Ethernet switch*1 AC power cord*1 Rubber foot*4 and screws Rack-mounted bracket *2 User manual*1 P a g e...
