Summary of Contents for Repotec RP-1716RT
- Page 1 16-P 10/100Mbps NWay Switch User's Manual V2.0...
- Page 2 CE Declaration of conformity This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
-
Page 3: Table Of Contents
Copyright © 2002 All Rights Reserved. Company has an on-going policy of upgrading its products and it may be possible that information in this document is not up-to-date. Please check with your local distributors for the latest information. No part of this document can be copied or reproduced in any form without written consent from the company. -
Page 4: Unpacking Information
MAC Address Table & Learning Filtering and Forwarding Store and Forward 5. Product Specifications 1. Unpacking Information Thank you for purchasing the 16-port NWay switch. Before you start, please check all the contents of this package. The product package should include the following: 1. -
Page 5: Introduction To 16-Port Nway Switch
2. Introduction To 16-Port NWay Switch 2.1 General Description The device is a powerful, high-performance Fast Ethernet switch, with all 16 ports capable of 10 or 100Mbps auto-negotiation operation (NWay) which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode. -
Page 6: Key Features
mode, transmission and reception of the frames can occur simultaneously without causing collisions as well as double the network bandwidth. The switch is plug-n-play without any software to configure and also fully compliant with all kinds of network protocols. Moreover, the rich diagnostic LEDs on the front-panel provide the operating status of individual port and whole system. -
Page 7: The Front Panel
Supports 8K MAC address entries and 128 entries of CAM 512KBytes buffer memory Supports extensive LED indicators for network diagnostics Internal universal switching power supply (100 ~ 240VAC) FCC Class A, CE 2.3 The Front Panel The front panel of the switch is shown as below. 11-inch model 19-inch model The auto-negotiation feature of the switch allows each port of the device running at... -
Page 8: System Leds
＊Each 10/100Mbps port supports auto MDI-X capability that is the port could connect either the PC or switch without any cable adjustment. 2.3.1 System LEDs System LED indicators are located on the front panel for showing the operating status of the whole device. 2.3.1.1 Power LED This indicator lights green when the switch is receiving power;... -
Page 9: The Rear Panel
2.4 The Rear Panel The rear panel of the switch is shown as below 11-inch model 19-inch model 2.4.1 Power Connecting For compatibility with electric service in most areas of the world, the switch’s power supply automatically adjusts to line power in the range 100~240 VAC and 50~60 Hz. -
Page 10: Installing And Using 16-Port Nway Switch
3. Installing And Using 16-Port NWay Switch 3.1 Installing The 16-Port NWay Switch The switch does not require software configuration. Users can immediately use any of the features of this product simply by attaching the cables and turning the power 3.1.1 Desktop Installation Locate the switch on the desktop and place the switch on a clean, flat desk or table close to a power outlet. -
Page 11: Installing Network Cables
Rack Mounting the Switch in the 19-inch rack: Disconnect all cables from the switch before continuing. Place the unit the right way up on a hard, flat surface with the front facing toward you. Locate a mounting bracket over the mounting holes on one side of the unit. -
Page 12: Network Application
3.1.3.3 Network Application... -
Page 13: Switch Operation
4. Switch Operation 4.1 MAC Address Table and Learning The switch is implemented with a MAC address table where is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding. - Page 14 5. Product Specifications Standard IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX Interface RJ-45 x 16 NWay switching ports Cable Connections RJ-45 (10BASE-T) : UTP Category 3,4,5 RJ-45 (100BASE-TX) : UTP Category 5 Network Data Rate Auto-negotiation (10Mbps, 100Mbps) Transmission Mode Auto-negotiation (Full-duplex, Half-duplex) LED indications System Power x1...
