Summary of Contents for Repotec RP-G2602D
- Page 1 24-P + 2-SFP Gigabit Ethernet Switch User Manual V1.0...
-
Page 2: Ce Mark Warning
FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Unpacking Information
Unpacking Information Thank you for purchasing this product. Before installation, please verify that your package contains the following items. One 24-Port Gigabit Ethernet switch with 2 SFP ports One AC power cord Rack-mount bracket x2 Rubber foot x4 and screws One user manual Introduction Easily boost your networking throughput,... -
Page 4: Key Feature
The switch features with easy installation maintenance. supports N-Way auto-negotiation protocol, which detects the networking speed (either 10/100/1000 Mbps) and the duplex modes (Full or Half duplex mode) automatically and do an immediately adjustment to advance the capability and performance. Auto-MDI/MDI-X function alleviates... - Page 5 Supports back-pressure (half duplex) and flow control (IEEE 802.3x) Supports N-Way protocol for speed (10/100/1000Mbps) and duplex mode (Half/Full) auto-detection Supports MDI/MDI-X auto crossover and polarity correction Store-and-forward architecture filters fragment & CRC error packets Push on/off button to enable/disable ...
-
Page 6: Front Panel
Front Panel The front panel of the switch contains the RJ45 ports, LEDs, 2 SFP ports and an IEEE802.3az ON/OFF button. detailed LED definition, please refer to the next paragraph. The front panel of the switch is shown as below: LEDs Definition This switch contains one power LED and Link/Act LEDs that shows the activities and... -
Page 7: Mini-Gbic Slots
RJ-45 Ports All the RJ-45 ports in the device are auto-negotiating and auto-crossover. An auto-negotiating port can detect and adjust optimum Ethernet speed (10/100/1000 Mbps) and duplex mode (full duplex or half duplex) of the connected device. An auto-crossover (auto-MDI/MDI-X) port automatically works... -
Page 8: Rear Panel
802.3az ON/OFF button: IEEE802.3az ON/OFF button helps reducing the power consumption of switch. This button allows users to keep the best performance without transmission impacted or to have the green support of Energy Efficient Ethernet mode with the simple push of a button. Rear Panel The three-pronged power receptacle is located on the rear panel of the switch. -
Page 9: Desktop Installation
Installation This switch can be placed on your desktop directly, mounted rack. installation is a snap. Users can use all the features of the switch with simply attaching the cables and turning the power on. Before installing the switch, we strongly recommend: 1. -
Page 10: Rack Mount Installation
Rack-mount Installation The switch may standalone, or may be mounted in a standard 19” rack. Rack mounting produces an orderly installation when have number related network devices. The switch is supplied with two optional rack mounting brackets and screws, which are used for rack mounting the unit. -
Page 11: Network Cables
Network Cables 1. Crossover or straight-through cable: All the ports on the switch support Auto-MDI/MDI-X functionality. Both straight-through or crossover cables can be used to connect the switch with PCs as well as other devices like switches, hubs or router. 2. -
Page 12: Product Specifications
Product Specifications IEEE802.3 (10BASE-T) IEEE802.3u (100BASE-TX) IEEE802.3ab (1000BASE-T) IEEE 802.3z (1000Base-X) Standard IEEE802.3x full-duplex flow control IEEE 802.3az Energy Efficient Ethernet IEEE 802.1p Cos 24x10/100/1000Mbps RJ-45 ports Interface 2xMini-GBIC open slots 1x IEEE802.3az push button RJ-45 (10BASE-T): Category 3,4,5 UTP/STP RJ-45 (100BASE-TX): Category 5 Cable UTP/STP...
