  • Page 3: Declaration Of Conformity

    Declaration of Conformity (As referred to in Annex IV 2. of Directive 2004/108/EC) Declares under his sole responsibility that the produced manufactured by Digital Broadband Sonar Koden Electronics Co., Ltd. 5278 Uenohara Uenohara-Shi Yamanashi-Ken 409-0112, Japan Telephone +81 554 20 5865...
  • Page 5 Koden Electronics Co., Ltd. The technical descriptions contained in this publication are subject to change without notice. Koden assumes no responsibility for any errors, incidentals or consequential damages caused by misinterpretation of the descriptions contained in this publication.

  • Page 6: Important Notice

    Koden is needed. Koden prohibits the un-authorized copy and transcription of this manual. • If this manual is lost or damaged, consult a dealer of Koden or Koden. • The specification of the products and the contents in this manual are subject to change without notice.
  • Page 7 When the inside is to be checked, ensure to switch off the power and to discharge the residual voltage for safety. An engineer authorized by Koden shall carry out the inspection and maintenance works.
  • Page 8 In case of failure, please Warning contact Koden’s dealers or Koden. In case of smoking or firing, switch off the power in the boat and of this equipment. It may lead to firing, electric shock or damages.

  • Page 9: Table Of Contents

    KDS-6000BB Contents Contents Document Revision History ..................... i Important Notice ........................ii For Your Safe Operation ......................iii Contents ..........................v Introduction .......................... viii System Configuration ......................ix Configuration of Equipment ....................x Basic knowledge for making use of sonar ................xvi Chapter 1 Preparation .....................1-1...
  • Page 10 Contents KDS-6000BB 2.2.7 FIR (Bandwidth) ......................2-10 2.2.8 Interference rejection ..................... 2-12 2.2.9 Noise reduction ......................2-12 2.2.10 Image correction ......................2-13 2.2.11 Color selection ....................... 2-14 2.2.12 Background color ......................2-14 2.2.13 Color palette ........................2-15 2.2.14 Initialization of Color palette ................... 2-18 2.2.15...
  • Page 11 KDS-6000BB Contents 2.4.4 Menu time-out period ..................... 2-54 2.4.5 Hull unit auto up ......................2-54 2.4.6 Hull unit operation at the start ..................2-55 2.4.7 Transducer unit baud rate ....................2-56 2.4.8 Slow down the Bearing speed ..................2-57 2.4.9 Menu (transparent) ......................
  • Page 12 This unit equipped with the latest digital process can accurately display circumstances in the water under all conditions. KDS-6000BB is the Black Box type without the display unit, for which customer can select the display monitor of preference. The external monitor and connecting cable are user supply.
  • Page 13 KDS-6000BB System Configuration System Configuration Connection Diagram Legend Standard DOU-620 Operation Option unit DOU-620R DPU-610ST Owner supply (with RCW-14) (Sona-Tone model) Cable for CW-412-5M external speaker External speaker NP-108 J7 (16P) Remote controller J1 (5P) Processor unit RCW-14 Onboard DC...
  • Page 14 Configuration of Equipment KDS-6000BB Configuration of Equipment Standard Equipment Configuration List a. DPU-610/610ST (Processor unit), DOU-620/620R (Operation unit) Weight/ Name of item Type Remark Length Processor unit DPU-610/ No display unit 5.1kg DPU-610ST VGA output (Sona-Tone model) Operation unit DOU-620 With mounting bracket 1.1kg...
  • Page 15 KDS-6000BB Configuration of Equipment Weight/Lengt Name of item Type Remark Fuse F-7161-10A/N30C-125V Normal fusion type Cylinder (ø 6.4x30) for main power Operation manual KDS-6000BB.OM.E English Quick Reference KDS-6000BB.QR.E English Installation manual KDS-6000BB.IM.E English b. TD tank / TD shaft Name of item...
  • Page 16 Configuration of Equipment KDS-6000BB c. DHU-6301 (Hull unit) Package 1-1 Name of item Type Remark Weight/Length Hull unit DHU-6301 17.0kg DC power cable CW-275-10M Cable is built into the Hull unit Hull unit CW-593-20M Cable is built control cable into the Hull unit c.
  • Page 17 KDS-6000BB Configuration of Equipment Name of item Type Remark Weight/Length Crank handle OB-03 Grease 100g Fuse F-7161-4A At input of 12 V EACH F-7161-8A At input of 24 V ANP base ANP-1 Binding Band AB-100-1000 Damper 34924D Fixing collar 32681D...
  • Page 18 Configuration of Equipment KDS-6000BB Package 2-2 Name of item Type Remark Weight/Length Transducer unit DHU-6302 9.0kg With 10m cable (With 18 pin water resistant connector) Bath cork Bath cork (White) 50g HEX rod wrench 3.0mm ×1 EACH 5.0mm ×1 Caution: Don’t carry the Transducer unit (DHU-6302) by holding its cable. Such manner may cause breakage of the equipment.
  • Page 19 KDS-6000BB Configuration of Equipment Option List Name of item Type Remark Remote controller RCW-14 With 5m cable, (Assembled the connection cable into the Operation unit) TD tank ESR-1506 PVC, 1230mm (For 1411mm of TD shaft) (For *xxxx mm of TD...
  • Page 20 Basic knowledge for making use of sonar KDS-6000BB Basic knowledge for making use of sonar We suppose that you, the user of sonar, already know how to use sonar. In this section we will theorize your experience to improve your fishing.
  • Page 21 KDS-6000BB Basic knowledge for making use of sonar Surface layer: This layer is greatly affected by the natural phenomena (e.g., sun, wind, rain, etc.) since it is adjacent to the atmosphere. Besides, the propagation route of ultrasonic wave refracts on the boundary where the temperature variations in addition to the difference in temperature between daytime and night are the greatest depending on the temperature distribution.
  • Page 22 (In order to reduce this failure, KDS-6000BB provides a built-in stabilizer function.) (3) Reduction of gain due to traveling noise Noises produced by the engine rotation, propeller rotation, and the friction between the ship’s hull and sea water are mixed into echoes to reduce the detecting gain of echoes.

  • Page 23: Chapter 1 Preparation

    KDS-6000BB Chapter 1 Preparation Chapter 1 Preparation 1.1 To use keys Operation unit of KDS-6000BB (12) (13) (14) (15) (10) (11) (16) (17) (18) Key Name Description [Power/Panel brightness] Press: Power on. Adjust brilliance of Operation unit (panel brightness). Long press: Power off.
  • Page 24 Chapter 1 Preparation KDS-6000BB [TVG] Press: Change of TVG setting [Tilt] Press: Change of the tilt angle [Sector] Press: Change of the scan sector [Menu] Press: Open/Close/Switch the menu [Knob/left] Turn: Change the setting item of operation keys ・Bearing center ・GAIN ・RANGE...
  • Page 25 KDS-6000BB Chapter 1 Preparation Normal operation is done with [Press]. When the relevant key is long-pressed, the menu box of the function defined for the key is displayed. Release the key immediately, once the menu box is displayed. Operation of the knobs (left/right) are in two ways, [Turn] and [Press].

  • Page 26: Power On/Off

    Caution: If an error occurs during the memory check, the unit may have a failure, In this case please contact your Koden dealer or Koden directly. Caution: Please wait for the startup to complete, takes about 30 seconds to fully start.

  • Page 27: Power Off

    KDS-6000BB Chapter 1 Preparation 1.2.2 Power Off Keep pressing (the power key) for 3 seconds to power off. After countdown for power shut down, when the message of [Preparing to shutdown] and the indication below is displayed, release key immediately.

  • Page 28: Open/Close The Menu

    Chapter 1 Preparation KDS-6000BB 1.4 To use Menu KDS-6000BB has three sets of menu; [Menu1], [Menu2] and [Menu3]. 1.4.1 Open/Close the Menu To display the menu, press Each time is pressed, [Menu1] / [Menu2] / [Menu3] are switched over. Name of the selected setting item...
  • Page 29 KDS-6000BB Chapter 1 Preparation Name of the selected setting item in red color box Setting item box Setting value box Menu1 Freq select 130.0 200.0 Freq 2 select Dynamic range 26 dB Pulse width Middle Auto TX power Color rejection...

  • Page 30: Adjustment Of Brilliance

    Chapter 1 Preparation KDS-6000BB 1.5 Adjustment of brilliance 1.5.1 Adjustment of LCD brilliance Caution: For KDS-6000BB the screen brilliance cannot be adjusted by pressing . Please adjust brilliance by the LCD monitor. Please refer to the operation manual of the LCD monitor.

  • Page 31: Screen Display

    KDS-6000BB Chapter 1 Preparation 1.6 Screen display The screen data presentation system is as follows. The KDS-6000BB offers a variety of display modes in split screen by combination of Mode dials and Menu. Split screen left Split screen right [Sonar]...

  • Page 32: Sonar Mode Display

    Time Information- Data display Range Bearing center Sector Tilt Gain VRM1 (Range marker, Bearing marker) VRM2 (Cross cursor) Caution: To present this info will require Bearing the KDS-6000BB to be connected to Speed an external navigator. Ship’s position 1-10 0093160002-05...

  • Page 33: Sonar Mode Operation

    KDS-6000BB Chapter 1 Preparation 1.6.2 Sonar mode Operation The Transducer unit sends out a beam of ultrasonic sound which sweeps in the specified sector and bearing. The echoes of reflected sound waves are picked up by the Transducer unit and displayed like a radar in their respective range and direction on the Display unit screen.
  • Page 34 Chapter 1 Preparation KDS-6000BB The tilt angle can be changed from 5° above horizontal to -90° vertical in a 1° step. ５゜ ・With this range all directions from extremely ０゜ shallow waters to deep areas may be searched. ・When adjusting the tilt angle please consider the Tilt angle 俯角可変範囲...

  • Page 35: Bottom-Scan Mode Display

    (Depth, Slant distance, Horizontal distance from the intersection of the Depth marker and the side marker.) VRM2 (Depth, Slant distance, Horizontal distance from the cross cursor) Bearing Caution: To present this info will require Speed the KDS-6000BB to be connected to Ship’s position an external navigator. 0093160002-05 1-13...

  • Page 36: Bottom-Scan Mode Operation

    Chapter 1 Preparation KDS-6000BB 1.6.4 Bottom-scan mode operation The sonar beam sweeps from side to side underneath the vessel. The screen will clearly display echoes from the middle depth and sea-bottom contour. ・The ultra sonic sound beams out as the beam sweeps from side to side.

  • Page 37: Echo Sounder Mode Display

    The depth display can be appeared when the tilt angle is set to -90° only. Information- Data display Range Bearing center Sector Tilt Gain Depth display (VRM) Water temp. Bearing Speed Ship’s position Caution: To present this info will require the KDS-6000BB to be connected to an external navigator. 0093160002-05 1-15...

  • Page 38: Echo Sounder Mode Operation

    1.6.6 Echo sounder mode operation The sonar beam sweeps underneath the vessel and the KDS-6000BB can be used as echo sounder mode by selecting of [Echo sounder] mode of the presentation mode. The screen will clearly display echo sounder images from the middle depth and the sea-bottom contour.

  • Page 39: Sonar & One Line Mode Display

    One line scale display Range or Depth Information- Data display Range Bearing center Sector Tilt Gain VRM1 or VRM2 (Selectable) Bearing Caution: To present this info will require Speed the KDS-6000BB to be connected to Ship’s position an external navigator. 0093160002-05 1-17...

  • Page 40: Sonar & One Line Mode Operation

    Chapter 1 Preparation KDS-6000BB 1.6.8 Sonar & One line mode operation The vertical sonar image can be shown in the Sub-screen beside the main circular image. The vertical sonar image like an echo sounder image is called “One line”. The image setting can be changed by [Menu2] >...

  • Page 41: Sonar X 2 Mode Display

    KDS-6000BB Chapter 1 Preparation 1.6.9 Sonar x 2 mode display [Sonar x 2] mode of the presentation mode Left Sonar Freq. Right Sonar Freq. ([Menu1] => ([Menu1] => [Freq select] menu) Tilt angle [Freq 2 select] menu) (Pink line: Left Sonar)

  • Page 42: Sonar X 2 Mode Operation

    Chapter 1 Preparation KDS-6000BB 1.6.10 Sonar x 2 mode operation Two sonar images can be displayed side by side. Each image can be set to the frequency, range, tilt angle and gain individually. The frequency of the left / right side image can be changed by [Menu1] => [Freq select] / [Freq 2 select] [Range] / [Tilt] / [Gain] setting can be switched by pressing [Range] / [Tilt] / [Gain] keys.

  • Page 43: Chapter 2 Function Setting

    KDS-6000BB Chapter 2 Function setting Chapter 2 Function setting Menu configuration 2.1.1 Initial setting The factory default setting is shown in square. Functions Factory setting (in the item Setting Menu Change at Menu1 Freq select 130, 130.1, 130.2 => 209.8, 209.9, 210...
  • Page 44 Chapter 2 Function setting KDS-6000BB Functions Factory setting (in the item Setting Menu Depth unit M, ft, fm, I.fm Range & Speed unit , km, km/h NM, kn Temperature unit °C, °F Temperature adjustment -9.9 • • • •0.0 • • • •9.9 Train correct -180.00 =>...
  • Page 45 KDS-6000BB Chapter 2 Function setting CM keys, F1/F2/F3 key Functions Factory setting (in the item Setting Menu Refer to “2.5.1 Initial setting of [CM] keys” CM keys Change at CM menu Refer to page 2-64 F1 key Change at Event (TLL)

  • Page 46: Menu1

    Chapter 2 Function setting KDS-6000BB Menu1 To display the menu, press and select [Menu1]. The selected menu item will be displayed in red color box. There are 22 setting items in [Menu1] box. Menu1 Freq select 130.0 Freq 2 select 200.0...

  • Page 47: Frequency, Frequency 2

    2.2.1 Frequency, Frequency 2 On KDS-6000BB, the frequencies can be set in a range of 130 to 210 kHz. [Freq select]: In Sonar x2 mode, the frequency of Left side Sonar image can be set. [Freq 2 select]: In Sonar x2 mode, the frequency of Right side Sonar image can be set.

  • Page 48: Gain (Td)

    Chapter 2 Function setting KDS-6000BB 3． Turn (knob/left) to select [Range number]. 4． Press (knob/left) or to move setting value box. The setting value will be displayed in red color box. Range1 20 m 5． Turn (knob/left) to select [Range setting value].

  • Page 49: Dynamic Range

    KDS-6000BB Chapter 2 Function setting The setting value will be displayed in red color box. Gain (TD) 4. Turn (knob/left) to select [GAIN (TD) setting value]. Gain (TD) adjustment When the bottom cannot be detected or when the bottom is of mud pool or seaweed, [Gain (TD)] shall be turned up.

  • Page 50: Pulse Width

    Chapter 2 Function setting KDS-6000BB Menu1 Freq select 130.0 Freq 2 select 200.0 Dynamic range 26 dB Pulse width Middle TX power Auto Color rejection Noise reduction Color Background color 3. Press (knob/left) or to move setting value box. 26 dB Dynamic range 4.

  • Page 51: Tx Power

    KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting value box. Middle Pulse width 4. Turn (knob/left) to select the setting value from [Short], [Middle] or [1] to [100]. Short: automatically changes the transmit pulse width according to the range (defaults) listed below.

  • Page 52: Fir (Bandwidth)

    Chapter 2 Function setting KDS-6000BB In crowded fishing areas, this function may be used to reduce power and avoid interference to other fishing boat’s sonars and echo sounders. [100] indicates the maximum power and then gradually reduced by moving from [90]=>[80] =>...
  • Page 53 KDS-6000BB Chapter 2 Function setting Setting: Set the value of [FIR] by “Tilt angle” and “Speed”. Refer to the figure as below. Tilt 0° Medium speed High speed -30° -60° Low speed -90° 15 kn：Speed Setting value Description [High speed] Ship’s speed: 10 knots or more.

  • Page 54: Interference Rejection

    Chapter 2 Function setting KDS-6000BB 2.2.8 Interference rejection The interference can be reduced, but the scanning speed is about two times slower. 1. Press to display [Menu1]. 2. Turn (knob/left) to select [Interference rejection]. Menu1 Gain (TD) Auto Interference rejection...

  • Page 55: Image Correction

    KDS-6000BB Chapter 2 Function setting Menu1 Dynamic range 26 dB Pulse width Middle TX power Auto Color rejection Noise reduction Color Background color Image correct Gain (TD) 3. Press (knob/left) or to move setting value box. Noise reduction 4. Turn (knob/left) to select the setting value from [0] to [10].

  • Page 56: Color Selection

    Chapter 2 Function setting KDS-6000BB [Off]: No effect [1]: Medium effect [2]: Strong effect [3]: Weak effect which is effected between [Off] to [1] 5. Press to close the menu. 2.2.11 Color selection Color table can be selected from [A-1, A-2], [B-1, B-2], [C-1, C-2] or [Z-1, Z- 2].

  • Page 57: Color Palette

    KDS-6000BB Chapter 2 Function setting 2. Turn (knob/left) to select [Background color]. Menu1 Freq select 130.0 Freq 2 select 200.0 Dynamic range 26 dB Pulse width Middle TX power Auto Color rejection Noise reduction Color Background color 3. Press (knob/left) or to move setting value box.
  • Page 58 Chapter 2 Function setting KDS-6000BB 3. Press (knob/left) or to display Color palette menu. If there is no need to change the color palette of “Z-1” and “Z-2”, go on to the below 7. Blue 4. Press (knob/left) or to move setting value box.
  • Page 59 KDS-6000BB Chapter 2 Function setting 7. Turn (knob/left) and move to select appropriate color. If you want to set the same color as the background color, select “Background color”. 8. Press (knob/left) or to move the setting value box of the “Red value”.

  • Page 60: Initialization Of Color Palette

    Chapter 2 Function setting KDS-6000BB 11. Select the setting value of the green color value and the blue color value from [0] to [31] like a red color value. 12. Press (knob/left) or to move 13. Press to close the menu.

  • Page 61: Color Rejection

    KDS-6000BB Chapter 2 Function setting 6. Turn (knob/left) to select the setting value from [A], [B] or [Z]. 7. Press (knob/left) or to move setting value box. 8. Turn (knob/left) to select the setting value from [No] or [Yes]. [No]: No initialization.

  • Page 62: Sub-Screen Selection

    Chapter 2 Function setting KDS-6000BB 2.2.16 Sub-screen selection Select the Sub-screen to be displayed and display the multi information into the window. 1. Press to display [Menu1]. 2. Turn (knob/left) to select [Sub-screen selection]. Menu1 Range (Sonar, Off-center) Range (Bottom-scan)
  • Page 63 KDS-6000BB Chapter 2 Function setting [Wake disp (N up)] [Wake disp (S up)] [Bottom-scan] You can choose the combination of “Sonar / Bottom-scan”, “Sonar (offset) / Bottom scan”, “Bottom-scan / Bottom-scan” and “Echo sounder / Bottom-scan” In this mode, the sonar scan alternately between a Sonar mode and a Bottom-scan mode.

  • Page 64: Sub-Screen Display

    Chapter 2 Function setting KDS-6000BB 2.2.17 Sub-screen display Sub-screen display can be selected from [Off], [Small], [Middle] and [Large]. When [Bottom-scan] is selected, the Sub-screen size is same at [small] and [Middle]. 1. Press to display [Menu1]. 2. Turn (knob/left) to select [Sub-screen display].
  • Page 65 KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting value box. Wake range (Sub-screen) 1. 0 4. Turn (knob/left) to select the setting value from [0.1] to [10.0]. Wakes are shown within the range. Scale bar is indicated at the top right of the screen.

  • Page 66: Language

    Chapter 2 Function setting KDS-6000BB 2.2.19 Language Displayed language can be changed. 1. Press to display [Menu1]. 2. Turn (knob/left) to select [Language]. Menu1 Range (Sonar, Off-center) Range (Bottom-scan) Range (Echo sounder) Remote key set Color palette Wake disp (H up)

  • Page 67: Menu2

    KDS-6000BB Chapter 2 Function setting Menu2 To display the menu, press and select [Menu2]. The selected menu item will be displayed in red color box. There are 29 setting items in [Menu2] box. Menu2 Step (Sonar, Off-center) 10° Step (Bottom-scan) 5°...

  • Page 68: Step (Sonar, Off-Center)

    Chapter 2 Function setting KDS-6000BB Basic Operation of the Menu 1. Turn (knob/left) to select the setting item. 2. Press (knob/left) or to confirm of the setting item. 2.3.1 Step (Sonar, Off-center) The step angle (scanning angle) in the Sonar mode may be selected.

  • Page 69: Step (Bottom-Scan)

    KDS-6000BB Chapter 2 Function setting 2.3.2 Step (Bottom-scan) The step angle (scanning angle) in the Bottom-scan mode may be selected. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [Step (Bottom-scan)]. Menu2 Step (Sonar, Off-center) 10° Step (Bottom-scan) 5°...

  • Page 70: Off-Center Position

    Chapter 2 Function setting KDS-6000BB 2.3.3 Off-center position The ship’s position on the screen may be selected in the Off-center mode. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [Off-center position]. Menu2 Step (Sonar, Off-center) 10° Step (Bottom-scan) 5°...

  • Page 71: A Scope

    KDS-6000BB Chapter 2 Function setting 2.3.4 A scope A scope expresses the echo strength of fish image from one set of the latest transmitted/received signal as width, to provide better view by displaying stronger response wide and weaker response narrow.

  • Page 72: Scale

    Chapter 2 Function setting KDS-6000BB Menu2 Step (Sonar, Off-center) 10° Step (Bottom-scan) 5° Off-center position Fore Target lock Reverse A scope White line Scale Internal buzzer volume NMEA monitor 3. Press (knob/left) or to move setting value box. White line 4.

  • Page 73: Internal Buzzer Volume

    KDS-6000BB Chapter 2 Function setting 4. Turn (knob/left) to select the setting value from [Off], [1], [2], [3], [4], [5] or [6]. 表示有り 表示無し 表 スケール スケール Scale [Off] : displays no scale. [1] to [6]: displays scale (dots). Select from 6 types.

  • Page 74: Nmea Monitor

    Chapter 2 Function setting KDS-6000BB The minimum volume is [0]. (silence) Turn the volume up as the setting value is increased from [0]=>[1]=>[2]=>[100]. The maximum volume is [100]. 5. Press to close the menu. 2.3.8 NMEA monitor This is the function to confirm the data input/output from NMEA1 (J8) and Transducer unit (J2).

  • Page 75: Compass Display

    KDS-6000BB Chapter 2 Function setting 2.3.9 Compass display The points of the compass can be shown on the screen in the Sonar mode by connecting the KDS-6000BB to an external navigator. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [Compass display].

  • Page 76: Wake Display

    Chapter 2 Function setting KDS-6000BB Menu2 Depth unit Range & Speed unit NM kn Temperature unit ℃ Temperature adjustment Train correct 0.00 Ext synchronized Bearing display True / Relative bearing Relative Step (Bearing center) 3. Press (knob/left) or to move setting value box.

  • Page 77: Wake Memory Interval

    KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting box. Wake display 4. Turn (knob/left) to select the setting value from [Off] or [On]. 航 跡 を 表 示 Wake display [Off]: displays no wake (trackline). [On]: displays the wake (trackline).

  • Page 78: Sonic Speed

    Chapter 2 Function setting KDS-6000BB When Wake memory interval is set to the short time, the smooth trail is displayed, but the trail length is short compared with setting to the long interval. When Wake memory interval is set to the long time, the trail length is long, but the zigzag trail is displayed compared with setting to the short interval.

  • Page 79: True / Relative Bearing

    KDS-6000BB Chapter 2 Function setting 2.3.14 True / Relative bearing Select the cursor display mode when an external navigation equipment is connected. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [True / Relative bearing]. Menu2 Depth unit Range & Speed unit...
  • Page 80 Chapter 2 Function setting KDS-6000BB Menu2 Step (Sonar, Off-center) 10° Step (Bottom-scan) 5° Off-center position Fore Target lock Reverse A scope White line Scale Internal buzzer volume NMEA monitor 3. Press (knob/left) or to move setting value box. Target lock Reverse 4.

  • Page 81: Ext Synchronized

    KDS-6000BB Chapter 2 Function setting Marker Mode1 / Marker Mode2 • The target mark is displayed and tracked automatically by pressing With the VRM movement, VRM position is worked as a target position. When Target lock ceases Bearing and Sector angles will return to their original positions.

  • Page 82: Depth Unit

    Chapter 2 Function setting KDS-6000BB When KDS-6000BB is used with external equipment as synchronization movement, the bearing speed may be reduced depending on the range settings. To avoid this, it is recommended to use with the internal synchronized signal of the KDS-6000BB as synchronization movement.

  • Page 83: Temperature Adjustment

    KDS-6000BB Chapter 2 Function setting 2. Turn (knob/left) to select [Temperature unit]. Menu2 Depth unit Range & Speed unit NM kn Temperature unit °C Temperature adjustment Train correct 0.00 Ext synchronized Bearing display True / Relative bearing Relative Step (Bearing center) 3.

  • Page 84: Range & Speed Unit

    Chapter 2 Function setting KDS-6000BB 4. Turn (knob/left) to select the setting value from [-9.9] to [9.9]. (every 0.1 steps) 9.9゜ : maximized the value of the adjustment ↑ increases the value 0.0゜ : no adjustment ↓ decreases the value -9.9゜: minimized the value of the adjustment...

  • Page 85: Train Correct

    KDS-6000BB Chapter 2 Function setting 2.3.21 Train correct To adjust the deviation of the bow direction (0°). In the Sonar mode use to adjust the Bearing toward Bow direction. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [Train correct].

  • Page 86: Power Freq Adjust

    Chapter 2 Function setting KDS-6000BB 2.3.22 Power freq adjust To adjust of switching frequency of power supply. The image may have noise due to the interference with the frequency of the internal power supply. Erase the noise by changing the transmit frequency or the frequency of the power supply.

  • Page 87: Audio Level

    10° 20° 5. Press to close the menu. 2.3.24 Audio level Control the Audio level when an audio speaker is connected to the KDS-6000BB. Audio level menu is valid for Sona-Tone model only. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [Audio level].

  • Page 88: Audio Tune

    (knob/left) to select the setting value from [1] to [40]. 5. Press to close the menu. 2.3.25 Audio tune Control the Audio tune when an audio speaker is connected to the KDS-6000BB. Audio tune menu is valid for Sona-Tone model only. 1. Press to display [Menu2].

  • Page 89: One Line Display

    KDS-6000BB Chapter 2 Function setting 2.3.26 One line display One line display can be selected from [Small] and [Large]. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [One line display]. Menu2 Bearing display True / Relative bearing Relative...

  • Page 90: One Line Scale

    Chapter 2 Function setting KDS-6000BB 2.3.27 One line scale One line scale can be selected from [Range] and [Depth]. [Depth]: The scale value is calculated by Range and Tilt angle. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [One line scale].

  • Page 91: One Line Shift

    KDS-6000BB Chapter 2 Function setting 2.3.28 One line shift The display range of [One line display] can be selected. One line shift can be selected from [0-100%], [0-50%], [0-75%], [25-100%] and [50-100%]. 1. Press to display [Menu2]. 2. Turn (knob/left) to select [One line shift].

  • Page 92: One Line Interval

    Chapter 2 Function setting KDS-6000BB 2.3.29 One line interval One line interval can be selected from [5°] and [10°]. [5°] : The image of the Sonar mode is displayed every 5° steps in [One line display]. [10°]: The image of the Sonar mode is displayed every 10°steps in [One line display].

  • Page 93: Menu3

    KDS-6000BB Chapter 2 Function setting Menu3 To display the menu, press and select [Menu3]. The selected menu item will be displayed in red color box. There are 23 setting items in [Menu3] box. Menu3 Baud rate 4800 DBT output DPT output...

  • Page 94: Baud Rate

    Chapter 2 Function setting KDS-6000BB 2.4.1 Baud rate Select the baud rate of NMEA1 when external equipment is connected. 1. Press to display [Menu3]. 2. Turn (knob/left) to select [Baud rate]. Menu3 Baud rate 4800 DBT output DPT output GGA output...

  • Page 95: Simulation

    KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting value box. DBT output 4. Turn (knob/left) to select the setting value from [On] or [Off]. 5. Press to close the menu. 2.4.3 Simulation The actual movie stored in the internal memory can be played for the operating instructions.

  • Page 96: Menu Time-Out Period

    Chapter 2 Function setting KDS-6000BB 2.4.4 Menu time-out period You can set the Menu time-out period to close the menu automatically from the last menu operation. 1. Press to display [Menu3]. 2. Turn (knob/left) to select [Menu time-out period]. Menu3...

  • Page 97: Hull Unit Operation At The Start

    KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting value box. Hull unit auto up 4. Turn (knob/left) to select the setting value from [Off] or [1] to [17] (Speed unit: kn). Or select from [Off] or [1] to [30] (Speed unit: km/h).

  • Page 98: Transducer Unit Baud Rate

    Chapter 2 Function setting KDS-6000BB Menu3 ZDA output Simulation Menu time-out period Hull unit auto up Hull unit operation at the start Transducer unit baud rate 19200 Slow down the Bearing speed Menu (transparent) Message (transparent) 3. Press (knob/left) or to move setting value box.

  • Page 99: Slow Down The Bearing Speed

    KDS-6000BB Chapter 2 Function setting 3. Press (knob/left) or to move setting value box. Transducer unit baud rate 19200 4. Turn (knob/left) to select the setting value from [4800], [9600] or [19200]. 5. Press to close the menu. 2.4.8 Slow down the Bearing speed The bearing speed may be unstable depending on the range settings.

  • Page 100: Message (Transparent)

    Chapter 2 Function setting KDS-6000BB Menu3 ZDA output Simulation Menu time-out period Hull unit auto up Hull unit operation at the start Transducer unit baud rate 19200 Slow down the Bearing speed Menu (transparent) Message (transparent) 3. Press (knob/left) or to move setting value box.

  • Page 101: Sub-Screen (Transparent)

    KDS-6000BB Chapter 2 Function setting 2.4.11 Sub-screen (transparent) The background image can be easy to see by changing the transparent rate of the sub-screen. 1. Press to display [Menu3]. 2. Turn (knob/left) to select [Sub-screen (transparent)]. Menu3 Hull unit operation at the start...

  • Page 102: Localtime Offset

    Chapter 2 Function setting KDS-6000BB 3. Press (knob/left) or to move setting value box. Information display 4. Turn (knob/left) to select the setting value from [Off], [Lat/long], [Date], or [Lat/long/Date]. [Lat/long]: displays own position and VRM in numerical values of latitude and longitude.

  • Page 103: Dynamic Range Standard

    KDS-6000BB Chapter 2 Function setting 2.4.14 Dynamic range standard Set the base point of the Dynamic range. 1. Press to display [Menu3]. 2. Turn (knob/left) to select [Dynamic range standard]. Menu3 Hull unit operation at the start Transducer unit baud rate...
  • Page 104 Chapter 2 Function setting KDS-6000BB [Sample image] Dynamic range standard: [Top], Dynamic range: [12dB] [Under]: the echo is displayed based on the strong echo. The echo is changed depending on the [Dynamic range] settings in the “Menu1” (Refer to page 2-7).

  • Page 105: The Origin Detection

    KDS-6000BB Chapter 2 Function setting 2.4.15 The origin detection Set the timing for the origin detection. 1. Press to display [Menu3]. 2. Turn (knob/left) to select [The origin detection]. Menu3 Transducer unit baud rate 19200 Slow down the Bearing speed...

  • Page 106: Cm] Keys

    For example, it is possible to switch the setting for seine fishing to the setting of squid fishing with one touch of a key button. KDS-6000BB is equipped with six [CM] keys, so can be used as if six units of sonars were used at a time.
  • Page 107 KDS-6000BB Chapter 2 Function setting Menu2 10° 5° 10° Step (Sonar, Off-center) Step (Bottom-scan) 5° 3° 5° Off-center position Fore Target lock Reverse A scope White line Scale Internal buzzer volume NMEA monitor Compass display Wake display Wake memory display...
  • Page 108 Chapter 2 Function setting KDS-6000BB Menu3 4800 Baud rate DBT output DPT output GGA output GLL output MTW output RMC output TLL output VTG output ZDA output Simulation Menu time-out period Hull unit auto up Hull unit operation at the start...

  • Page 109: Function Of [Cm] Keys

    KDS-6000BB Chapter 2 Function setting 2.5.2 Function of [CM] keys By pressing each key of CM1 to CM6, and the screen mode, Range, Shift, Gain and Menu setting item turn to the setting mode (Color of light turns green). Caution: setting [CM] number displays on screen, down left.
  • Page 110 Chapter 2 Function setting KDS-6000BB When new setting is to be stored in [CM2] key, based on the present setting in [CM1] key 1. Keep pressed to display the menu of [CM1]. 2. Turn (knob/left) to select [Copy to CM2].

  • Page 111: Function Keys ([F] Keys)

    KDS-6000BB Chapter 2 Function setting Function keys ([F] keys) [F] keys can be assigned with the functions used frequently, to be operated with one touch operation. 2.6.1 Setting to function to [F] keys The functions can be assigned to Function Function ・Freq select...

  • Page 112: Event (Tll)

    Chapter 2 Function setting KDS-6000BB 2.6.3 Event (TLL) The latitude and longitude at the VRM cursor position can be sent to external equipment. The applicable VRM is the selected VRM shown in white color. Caution: Requires position data from a GPS sensor to perform the Event (TLL).

  • Page 113: Remote Control Set

    KDS-6000BB Chapter 2 Function setting Caution: Requires position data from GPS sensor to display Marks and Wakes. When turning power off, all Marks are erased. When [Wake erase] is done, all wake data and the all marks are erased. 5. Press to close the menu.
  • Page 114 - This page intentionally left blank.-...

  • Page 115: Chapter 3 Operation Keys

    Chapter 3 Operation keys Chapter 3 Operation keys 3.1 To use keys Operation unit of KDS-6000BB 3.1.1 Presentation mode key Select one of the display mode, [Sonar], [Sonar (Off-center)], [Bottom-scan], [Echo sounder] [Sonar & One line] or [Sonar x 2].

  • Page 116: Sector Key

    Chapter 3 Operation keys KDS-6000BB 3.1.3 Sector key Change the scanning historical angle (sector angle) in the Sonar mode. Change the scanning sector angle (vertical angle) in the Bottom-scan mode. display the selected angle Bottom-scan mode 選択した角度を表示 サイドスキャン時 レンジ 旋回中心...

  • Page 117: Tvg Key

    KDS-6000BB Chapter 3 Operation keys 3.1.5 TVG key Set the TVG curve to correct the attenuation echo. When the ultrasonic is sent into the sea, the reflection of the ultrasonic (echo) is decreased, as distance is long. To cover the attenuation, the gain is increased automatically in accordance with the distance.
  • Page 118 Chapter 3 Operation keys KDS-6000BB (Setting value: [0] to [40] or [- -], Initial setting: 28) [TVG] is set to small, the correction rate is gradual from near to far. [TVG] is set to large, the correction rate becomes high from the near side.
  • Page 119 KDS-6000BB Chapter 3 Operation keys TVG adjustment (Setting value: [50] to [300], Initial setting: 170) [TVG adjustment] is the start depth of the TVG correction. [TVG adjustment] is set to small, the start depth of the TVG correction becomes near.
  • Page 120 Chapter 3 Operation keys KDS-6000BB Emphasize (Setting value: [Off] or [1] to [30], Initial setting: Off) [Emphasize] is a function to emphasize the attenuation correction from the Emphasize depth. The larger setup becomes, the stronger effect becomes. When [Emphasize] is set to small, the TVG curve is gradually increased from the Emphasize depth.
  • Page 121 KDS-6000BB Chapter 3 Operation keys Emphasize depth (Setting value: [20] to [900], Initial setting: 100) [Emphasize] is set to [OFF], the effect is disable. [Emphasize] is set to [OFF], the effect is disabled. [Emphasize] is set from [1] to [30], the effect is enabled.

  • Page 122: Power/Panel Brightness Key

    Chapter 3 Operation keys KDS-6000BB 3.1.6 Power/Panel brightness key Power On/Off. Power On Press to power on. On start-up, the internal memory (ROM and RAM) is automatically checked, if the checking completes normally, the start-up screen is displayed. Power Off Keep pressing for 3 seconds to power off.

  • Page 123: Bearing Center Key

    KDS-6000BB Chapter 3 Operation keys 3.1.8 Bearing center key Use this key to define the center of current scanning sector in Sonar mode. The bearing angle of the display is shifted by 5° steps. Press 旋回 旋回中心位置 Turn the knob/left Turn the knob/left の角度を表示...

  • Page 124: Tilt Key

    Chapter 3 Operation keys KDS-6000BB In case of Sonar mode [Tilt key] explained in the next section is collaborated with the bearing key. The shifted angles are the same as those of Bottom scan mode. (Refer to page 2-27) 3.1.9 Tilt key Use this key to control the tilt angle in the Sonar mode.

  • Page 125: Vrm Key

    KDS-6000BB Chapter 3 Operation keys Variable tilt angle: 3° step: -3° to -90° (every 3°) 5° step: -5° to -90° (every 5°) Refer to page 2-27 for step. to define the direction of the detection in the Echo sounder mode.
  • Page 126 Chapter 3 Operation keys KDS-6000BB Press to switch two VRMs. Keep pressed to clear two VRMs. Sonar and Sonar (Off-center) mode operation There are two VRMs. VRM1 is the combination of Ring marker and the Bearing marker. VRM2 is the cross cursor marker.
  • Page 127 KDS-6000BB Chapter 3 Operation keys 3. Turn (knob/ right) to move the Bearing marker. 4. The direction and the distance of the target can be measured by the following method. Turn or press (knob/ right) repeatedly and set the intersection of the Ring marker and Bearing marker on the target.
  • Page 128 Chapter 3 Operation keys KDS-6000BB Bottom-scan mode operation There are two VRMs. VRM1 is the combination of the Depth marker and the Vertical marker. VRM2 is the Cross cursor marker. (After the power on, the Depth marker is selected.) Depth marker...
  • Page 129 KDS-6000BB Chapter 3 Operation keys 5. Press to select the cross cursor. 6. Check [Direction/Distance] from the target by the Cross cursor. Turn of press (knob/ right) repeatedly and set the Cross cursor on the target. The center position of the Cross cursor is displayed on the [Information-Data display] of VRM2.
  • Page 130 Chapter 3 Operation keys KDS-6000BB Sonar & One line mode operation There are three VRMs. VRM1 and VRM2 is the same as the Sonar mode. VRM3 is Depth marker. It will depend on the [One line scale] settings. [Depth]: The scale value is calculated by Range and Tilt angle.

  • Page 131: Target Lock Key

    KDS-6000BB Chapter 3 Operation keys 3.1.11 Target lock key When Menu2/Target lock/[Reverse is selected. When pressing in Sonar mode or Bottom-scan mode, the direction of sweep of the Sonar beam is reversed. When Menu2/Target lock/[Mode1] or [Mode2] is selected. When pressing in Sonar mode, the Sonar beam tracks the echo automatically.

  • Page 132: Remote Controller (Rcw-14) (Optional)

    Chapter 3 Operation keys KDS-6000BB 3.2 Remote controller (RCW-14) (Optional) Target lock key •Turn on or off the target lock mode. Hoist key •Raise/Lower the Transducer unit. Tilt key •Adjust tilt angle. Mark key •Enters marks Bearing key •Moves cursor-center right or left.
  • Page 133 KDS-6000BB Chapter 3 Operation keys 3. Press (knob/left) or to move Remote key setting box. Hull unit U/D Target lock Tilt angle up Event (TLL) Marker up Tilt angle down Marker left Marker switching Marker right 4. Turn (knob/left) to select the setting number from [A1] to [D3] The remote control key position and assignment.
  • Page 134 Chapter 3 Operation keys KDS-6000BB 8. Press to close the menu. ・Set as the same way as other Remote key setting. ・The sheet of remote control key shows the initial setting of the remote control keys. ・The range operation of Remote control key;...

  • Page 135: Chapter 4 Appendix

    Chapter 4 Appendix KDS-6000BB Chapter 4 Appendix External view and dimensions Processor unit (DPU-610) Processor unit (DPU-610ST) (Sona-Tone model) Unit: mm (inch) 0093160002-05...
  • Page 136 KDS-6000BB Chapter 4 Appendix Operation unit (DOU-620) TD position alarm / Ext. Sync. Box (JB-36) Installation dimensions Unit: mm (inch) 0093160002-05...
  • Page 137 Chapter 4 Appendix KDS-6000BB Remote controller (RCW-14) (Optional) Unit: mm (inch) 0093160002-05...
  • Page 138 KDS-6000BB Chapter 4 Appendix Hull unit (DHU-630) Unit: mm (inch) 0093160002-05...

  • Page 139: Disposal

    Chapter 4 Appendix KDS-6000BB Disposal Dispose of this equipment in accordance with local regulations. 0093160002-05...
  • Page 140 - This page intentionally left blank.-...

  • Page 141: Chapter 5 Index

    KDS-6000BB Chapter 5 Index Chapter 5 Index Depth unit ........... 2-2, 2-40 Detectability ............xviii Digital broadband sonar ........viii Direction ............. 1-10 A scope ............2-1, 2-29 DPT output ..........2-2, 2-52 Absorption and attenuation ........xvi Dynamic range ..........2-1, 2-7 Attenuation ............
  • Page 142 Chapter 5 Index KDS-6000BB Hull unit auto up ......... 2-2, 2-54 Hull unit operation at the start ....2-2, 2-55 NM:nautical mile ..........2-42 NMEA monitor ..........2-1, 2-32 Noise reduction .......... 2-1, 2-12 I.fm:Italian fathoms ..........2-40 Image correct ..........2-1, 2-13 Information display ........
  • Page 143 KDS-6000BB Chapter 5 Index Scale ..........1-10, 2-1, 2-30 TLL output ........... 2-2, 2-52 Scanning direction ..........1-13 Trail position data ..........2-36 Sea water temperature ......... xvi Train correct ..........2-2, 2-43 Sector ..............1-2 Transducer unit ............ 1-1 Sector key ............

Table of Contents
