6

Connector pin assignment

19-pin Color Display Signal Cable*

PIN No.
Description
1
TMDS Data2+
3
TMDS Data2–
5
TMDS Data1 Shield
7
TMDS Data0+
9
TMDS Data0–
11
TMDS Clock Shield
13
CEC
15
SCL
17
DDC/CEC Ground
19
Hot Plug Detect
* only for certain models
PIN No.
2
TMDS Data2 Shield
4
TMDS Data1+
6
TMDS Data1–
8
TMDS Data0 Shield
10
TMDS Clock+
12
TMDS Clock–
14
Reserved (N.C. on device)
16
SDA
18
+5V Power
19
17
15
13
11
9
7
5
3
1
18
16
14
12
10
8
6
4
2
Description
