SECTION 1
' ' GENERAL
• Frequency coverage
• Type of emission
• Number of channels
• Power supply requirement
• Current drain (approx.)
• Frequency stability
• Usable temperature range
• Dimensions (projections not included)
• Weight (with ant., BP-209)
' ' TRANSMITTER
• RF output power (at 7.2 V DC)
(with supplied battery pack)
• Modulation system
• Maximum frequency deviation
• Spurious emissions
• Adjacent channel power
• Transmitter audio distortion
• Limitting charact of modulator
• Ext. microphone connector
' ' RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity
• Adjacent channel selectivity
• Spurious response rejection
• Intermodulation rejection ratio
• Hum and noise
• Audio output power (at 7.2 V DC)
• Ext. speaker connector
Specifications are measured in accordance with EIA/TIA-603.
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

: 440.000–470.000 MHz
: 8K50F3E
: 32 ch (16 channels × 2 banks: 2-BANK version), 16 ch (16 channel version)
: 7.2 V DC (negative ground; supplied battery pack)
: Transmit at High (4.0 W)
at Low (1.0 W)
Receive rated audio
stand-by
: ±0.00025 %
: –30˚C to +60˚C; –22˚F to +140˚F
: 54(W) × 132(H) × 35(D) mm; 2
: 355 g; 12.5 oz.
: 4 W / 1 W (High / Low)
: Variable reactance frequency modulation
: ±2.5 kHz
: 73 dBc (typical)
: 60 dB (typical)
: Less than 3% at 1 kHz, 40% deviation
: 70–100% of max. deviation
: 3-conductor 2.5(d) mm (
: Double conversion superheterodyne system
: 1st
2nd
: 0.3 µV at 12 dB SINAD (typical)
: 0.3 µV at threshold (typical)
: 65 dB (typical)
: 70 dB (typical)
: 70 dB (typical)
: 40 dB (typical)
: 500 mW typical at 5% distortion with an 8 Ω load
: 3-conductor 3.5(d) mm (
1 - 1
1.55 A
800 mA
250 mA
70 mA
(W) × 5
5 ⁄
32
1 ⁄ ")/2.2 kΩ
10
46.35 MHz
450 kHz
")/8 Ω
1 ⁄
8
(H) × 1
3 ⁄ 3 ⁄ (D) in.
16 8
