KINO-6612 Mini-ITX Motherboard
,
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINO-6612LVDS and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology KINO-6612LVDS

Summary of Contents for IEI Technology KINO-6612LVDS

  • Page 1 KINO-6612 Mini-ITX Motherboard Page i...
  • Page 2 KINO-6612 Mini-ITX Motherboard Revision Date Version Changes 2007-08-14 V1.30 Removed TPM connector BIOS support on the LPC bus -12 V added to PCI slot 2007-11-29 1.12 Changed in accordance with Quick Installation Guide changes 2007-11-01 Removed the 800Z models and changed the LVDS connector pin definitions 2007-05-01 Initial release...
  • Page 3 KINO-6612 Mini-ITX Motherboard Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 KINO-6612 Mini-ITX Motherboard Manual Conventions WARNING! Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. Warnings are easy to recognize. The word “warning” is written as “WARNING,” both capitalized and bold and is followed by text.
  • Page 5 KINO-6612 Mini-ITX Motherboard NOTE: These messages inform the reader of essential but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes. Notes are easy to recognize. The word “note” is written as “NOTE,”...

  • Page 6: Packing List

    KINO-6612 Mini-ITX Motherboard Packing List NOTE: If any of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the KINO-6612 from or contact an IEI sales representative directly.

  • Page 7: Table Of Contents

    KINO-6612 Mini-ITX Motherboard Table of Contents INTRODUCTION..................... 4 2 0 H 1 .1 O ......................... VERVIEW 4 2 1 H 1 .1.1 KINO-6612 Introduction..................4 2 2 H 1 .1.2 KINO-6612 Model Variations ................4 2 3 H 1 .2 KINO-6612 O .....................
  • Page 8 KINO-6612 Mini-ITX Motherboard 2 .5.1 SIS964 Southbridge Overview ................. 3 1 H 4 5 0 H 2 .5.2 SiS964 Audio Codec ’97 Controller..............3 2 H 4 5 1 H 2 .5.2.1 Realtek ALC655 AC’97 Audio Codec............3 3 H 4 5 2 H 2 .5.3 SiS964 IDE Controllers ...................
  • Page 9 KINO-6612 Mini-ITX Motherboard 3 .3.2 Optional Items....................6 5 H 4 8 4 H CONNECTORS ...................... 6 6 H 4 8 5 H 4 .1 P ..............ERIPHERAL NTERFACE ONNECTORS 6 7 H 4 8 6 H 4 .1.1 KINO-6612 Layout................... 6 8 H 4 8 7 H 4 .2 P...
  • Page 10 KINO-6612 Mini-ITX Motherboard 5 .2.2 Installation Checklist ..................9 8 H 5 1 7 H 5 .3 U ......................NPACKING 9 9 H 5 1 8 H 5 .4 CPU, CPU C DIMM I ..........OOLING IT AND NSTALLATION 1 0 0 H 5 1 9 H 5 .4.1 Socket 479 CPU Installation................
  • Page 11 KINO-6612 Mini-ITX Motherboard 6 .1.4 Unable to Reboot After Configuration Changes..........1 07 1 3 2 H 5 5 1 H 6 .1.5 BIOS Menu Bar....................1 07 1 3 3 H 5 5 2 H 6 .2 M ........................1 08 1 3 4 H 5 5 3 H...
  • Page 12 KINO-6612 Mini-ITX Motherboard C .1 DIO I ................1 87 NTERFACE NTRODUCTION 1 6 5 H 5 8 4 H C .2 DIO C ................... 1 87 ONNECTOR INOUTS 1 6 6 H 5 8 5 H C .3 A ................

  • Page 13: List Of Figures

    KINO-6612 Mini-ITX Motherboard List of Figures F igure 1-1: KINO-6612 Mini-ITX CPU Card..............1 8 2 H 6 0 1 H F igure 1-2: KINO-6612 Overview [Front View]............1 8 3 H 6 0 2 H F igure 2-1: KINO-6612 Dimensions (mm) ..............1 8 4 H 6 0 3 H F igure 2-2: External Interface Panel Dimensions (mm)...........
  • Page 14 KINO-6612 Mini-ITX Motherboard F igure 4-11: PCI Slot Location ................... 2 1 0 H 6 2 9 H F igure 4-12: SATA Drive Connector Locations............2 1 1 H 6 3 0 H F igure 4-13: COM Connector Pinout Locations ............2 1 2 H 6 3 1 H F igure 4-14: RS-232/422/485 Serial Port Connector Location ........
  • Page 15 KINO-6612 Mini-ITX Motherboard F igure 5-21: PS/2 Keyboard/Mouse Connector............. 1 01 2 4 2 H 6 6 1 H F igure 5-22: Serial Device Connector ..............1 02 2 4 3 H 6 6 2 H F igure 5-23: USB Connector ................... 1 03 2 4 4 H 6 6 3 H...
  • Page 16 KINO-6612 Mini-ITX Motherboard List of Tables T able 1-1: Model Variations..................2 7 0 H 6 8 9 H T able 1-2: Technical Specifications ................2 7 1 H 6 9 0 H T able 2-1: Support Intel® Pentium® M Processors ..........2 7 2 H 6 9 1 H T able 2-2: Supported Intel®...
  • Page 17 KINO-6612 Mini-ITX Motherboard T able 5-1: Jumpers...................... 2 9 8 H 7 1 7 H T able 5-2: Clear CMOS Jumper Settings ..............2 9 9 H 7 1 8 H T able 5-3: CPU Frequency Setup Jumper Settings ..........3 0 0 H 7 1 9 H T able 5-4: FSB Setup Jumper Settings ..............
  • Page 18 KINO-6612 Mini-ITX Motherboard List of BIOS Menus M enu 1: Main......................1 08 3 0 6 H 7 2 5 H M enu 2: Advanced....................1 10 3 0 7 H 7 2 6 H M enu 3: CPU Configuration ..................1 11 3 0 8 H 7 2 7 H...

  • Page 19: Introduction

    KINO-6612 Mini-ITX Motherboard Chapter Introduction Page 1...

  • Page 20: Overview

    KINO-6612 Mini-ITX Motherboard 1.1 Overview Figure 1-1: KINO-6612 Mini-ITX CPU Card 1.1.1 KINO-6612 Introduction The KINO-6612 Mini-ITX motherboard ( F igure 1-1) is a socket 479 Intel® Pentium® M or 7 4 4 H 7 4 6 H Celeron® M CPU platform. This high performance platform supports a front side bus (FSB) of 400 MHz or 533 MHz and processors with maximum clock speed of 2.26 GHz.

  • Page 21: Kino-6612 Model Variations

    KINO-6612 Mini-ITX Motherboard 1.1.2 KINO-6612 Model Variations T able 1-1 shows the model variations that are available: 7 4 5 H 7 4 7 H Feature KINO-6612 KINO-6612LVDS 533 MHz FSB LVDS TV-OUT Dual PCI GbE Audio Dual SATA Table 1-1: Model Variations 1.2 KINO-6612 Overview...

  • Page 22: Kino-6612 Peripheral Connectors And Jumpers

    KINO-6612 Mini-ITX Motherboard Figure 1-2: KINO-6612 Overview [Front View] 1.2.2 KINO-6612 Peripheral Connectors and Jumpers The KINO-6612 has the following connectors on-board: 1 x 20-pin ATX power connector 1 x Backlight inverter connector 1 x CompactFlash® socket 2 x Fan connectors 2 x Front panel connectors (one is optional) 1 x General purpose input/output (GPIO) connector Page 4...

  • Page 23: Technical Specifications

    KINO-6612 Mini-ITX Motherboard 2 x IDE disk drive connectors (one 40-pin and one 44-pin) 1 x Infrared interface (IrDA) connector 1 x LVDS connector 1 x PCI slot 2 x Serial ATA II (SATA II) drive connectors 4 x RS-232 serial port connectors 1 x RS-232/422/485 serial port connector 1 x TV Out connector 1 x USB 2.0 connectors (supports two USB 2.0 devices)
  • Page 24 Super I/O Winbond W83697HG Analog VGA integrated on the SiS661CX and interfaced through an external DB-15 connector Display 24-bit dual-channel LVDS by SiS 302LV on (KINO-6612LVDS only) TV-OUT integrated in the SiS302LV AMI BIOS label BIOS SPI EEPROM 8.0 MB...
  • Page 25 KINO-6612 Mini-ITX Motherboard One RS-232 serial port through an external DB-9 connectors Four RS-232/422/485 serial ports through 10-pin pin headers One RS-232/422/485 serial port through 14-pin pin header Six USB 2.0 devices supported: USB2.0 Two by onboard pin-headers Four by external connectors One 40-pin IDE connector and one 44-pin IDE connector Hard Drives connect to four Ultra ATA33/66/100/133 devices...
  • Page 26 KINO-6612 Mini-ITX Motherboard 5V@3.79A, +12V@1.44A and 3.3V@0.92A Power Consumption 1.5 GHz Intel® Celeron® M CPU with one 400 MHz 1.0 GB DDR DIMM Temperature 0ºC – 60ºC (32ºF - 140ºF) Humidity (operating) 5%~95% non-condensing 170mm x 170mm Dimensions (LxW) Weight (GW/NW) 1,100g/420g Table 1-2: Technical Specifications Page 8...

  • Page 27: Detailed Specifications

    KINO-6612 Mini-ITX Motherboard Chapter Detailed Specifications Page 9...

  • Page 28: Dimensions

    KINO-6612 Mini-ITX Motherboard 2.1 Dimensions 2.1.1 Board Dimensions The dimensions of the board are listed below: Length: 170mm Width: 170mm Figure 2-1: KINO-6612 Dimensions (mm) Page 10...

  • Page 29: External Interface Panel Dimensions

    KINO-6612 Mini-ITX Motherboard 2.1.2 External Interface Panel Dimensions External peripheral interface connector panel dimensions are shown in F igure 2-2. 7 4 8 H 7 5 0 H Figure 2-2: External Interface Panel Dimensions (mm) 2.2 Data Flow F igure 2-3 shows the data flow between the two on-board chipsets and other components 7 4 9 H 7 5 1 H installed on the motherboard and described in the following sections of this chapter.

  • Page 30: Compatible Processors

    KINO-6612 Mini-ITX Motherboard Figure 2-3: Data Flow Block Diagram 2.3 Compatible Processors 2.3.1 Supported Processors The KINO-6612 supports the following Socket 479 Intel® processors: Intel® Pentium® M Page 12...

  • Page 31: Intel® Pentium® M Processors

    KINO-6612 Mini-ITX Motherboard Intel® Celeron® M The CPU socket is shown is show below: Figure 2-4: CPU Socket 2.3.2 Intel® Pentium® M Processors The KINO-6612 supports the Intel® Pentium® M processors listed in T able 2-1 below. 7 5 0 H 7 5 2 H CPU Speed Processor # Bus Speed Mfg Tech Cache Size...

  • Page 32: Intel® Celeron® M Processors

    KINO-6612 Mini-ITX Motherboard 1.70 GHz 400 MHz 90 nm 2 MB 1.60 GHz 533 MHz 90 nm 2 MB 1.60 GHz 400 MHz 90 nm 2 MB 1.50 GHz 400 MHz 90 nm 2 MB Table 2-1: Support Intel® Pentium® M Processors 2.3.3 Intel®...

  • Page 33: Front Side Bus (Fsb)

    KINO-6612 Mini-ITX Motherboard 1.30 GHz 400 MHz 90 nm 1 MB 1.20 GHz 400 MHz 0.13 micron 512 KB Table 2-2: Supported Intel® Celeron® M Processors 2.3.4 Front Side Bus (FSB) The Intel® processor on the KINO-6612 is interfaced to the SiS661CX Northbridge through an 800 MHz front side bus (FSB).

  • Page 34: Ddr Controller

    KINO-6612 Mini-ITX Motherboard functions and multiple RAM formats such as 400 MHz. 333 MHz and 266 MHz DDR. The SiS661CX ECLK and 1600 x 1200 high resolution can support UXGA TFT-LCD output. 2.4.2 DDR Controller There are twp 184-pin DDR DIMM sockets on the KINO-6612. These sockets support to DDR DIMM with the following specifications: 333 MHz or 400 MHz un-buffered DIMM 1.0 GB maximum capacity per DIMM (2.0 GB maximum system memory)

  • Page 35: Integrated Graphics Engine

    KINO-6612 Mini-ITX Motherboard 2.4.4 Integrated Graphics Engine The integrated graphics is a high performance 256-bit 3D or 128-bit 2D graphics engine with two, pixel rendering, pipelines and four texture units per cycle (2P4T) with an ECLK of up to 200 MHz. 2.4.5 SiS302LV Video Bridge 2.4.5.1 SiS302LV Video Bridge The SiS302LV video bridge is interfaced to the SiS661CX through the SiS video interface.

  • Page 36: Sis302Lv Video Bridge Tv Display Features

    KINO-6612 Mini-ITX Motherboard 2.4.5.2 SiS302LV Video Bridge TV Display Features Some of the TV display features supported by the SiS302LV are listed below. PAL and NTSC systems with resolutions up to 1024x768 Composite, S-Video and Component output signals Macrovision copy protection process rev. 7.1.L1 Progressive TV 480p YPbPr output signal Macrovision copy protection waveforms for 480p progressive scan output TV/primary VGA independent display resolution and frame rate at enhanced...

  • Page 37: Dual Display

    KINO-6612 Mini-ITX Motherboard 2.4.5.4 Dual Display The LVDS and TV windows driver supports dual display. When the TV and LCD are in the simultaneous display mode, the TV data stream runs through Channel B and the LCD data stream run through Channel A. 2.4.6 SiS MuTIOL®...

  • Page 38: Figure 2-8: Audio Codec And Connectors

    KINO-6612 Mini-ITX Motherboard Figure 2-8: Audio Codec and Connectors Some of the features of the Realtek ALC655 are listed below: Meets performance requirements for audio on PC99/2001 systems Meets Microsoft WHQL/WLP 2.0 audio requirements 16-bit Stereo full-duplex CODEC with 48KHz sampling rate Compliant with AC'97 Rev 2.3 specifications Front-Out, Surround-Out, MIC-In and LINE-In Jack Sensing 14.318MHz ->...

  • Page 39: Sis964 Ide Controllers 2

    KINO-6612 Mini-ITX Motherboard Boost preamplifier for MIC input LINE input shared with surround output; MIC input shared with Center and LFE output Built-in 50mW/20ohm amplifier for both Front-out and Surround-Out External Amplifier Power Down (EAPD) capability Power management and enhanced power saving features Supports Power-Off CD function Adjustable VREFOUT control Supports 48KHz S/PDIF output, complying with AC'97 Rev 2.3 specifications...

  • Page 40: Sis964 Lpc Host Bus Controller 2

    KINO-6612 Mini-ITX Motherboard Figure 2-9: IDE Connector 2.5.4 SiS964 LPC host bus controller The SIS964 Southbridge LPC interface complies with the LPC 1.1 specifications. The LPC bus from the Southbridge is connected to the following components: BIOS chipset Super I/O chipset LPC Serial Port Chipset 2.5.5 SiS964 PCI Host Bus Controller The PCI interface on the SIS964 Southbridge is compliant with the PCI Revision 2.3...

  • Page 41: Figure 2-10: Sata Connectors

    KINO-6612 Mini-ITX Motherboard Hiding of PCI devices by BIOS/hardware Spread spectrum 2.5.6 SiS694 Real Time Clock The SiS964 Real Time clock has 512B CMOS SRAM. 2.5.7 SIS964 SATA Controllers Two SATA ports on the KINO-6612 are interfaced to an integrated SATA Host controller on the SiS964.

  • Page 42: Figure 2-11: Keyboard And Mouse Connectors

    KINO-6612 Mini-ITX Motherboard Figure 2-11: Keyboard and Mouse Connectors 2.5.9 SIS964 USB Controllers The USB controllers on the SiS 964 Southbridge chipset are interfaced to six USB 1.1 or USB 2.0 devices. Four USB devices can be connected to external USB ports. The remaining two USB devices are connected to a single onboard USB connectors.

  • Page 43: Lpc Bu Component

    KINO-6612 Mini-ITX Motherboard Figure 2-12: USB Connectors 2.6 LPC Bus Components 2.6.1 LPC Bus Overview The SIS964 LPC bus is connected to components listed below: BIOS chipset Super I/O chipset LPC Serial Port Chipset 2.6.2 BIOS Chipset The BIOS chipset has a licensed copy of AMI BIOS installed on the chipset. Some of the BIOS features are listed below: AMI Flash BIOS SMIBIOS (DMI) compliant...

  • Page 44: Figure 2-13: Bios Chipset

    KINO-6612 Mini-ITX Motherboard The BIOS chipset is shown in F igure 2-13 below. 7 5 9 H 7 6 1 H Figure 2-13: BIOS Chipset 2.6.3 Winbond W83697HF Super I/O chipset The Winbond W83697HF Super I/O chipset is connected to the SiS964 Southbridge through the LPC bus.

  • Page 45: Figure 2-14: Super I/O Chipset

    KINO-6612 Mini-ITX Motherboard Figure 2-14: Super I/O Chipset The Winbond W83697HF is an LPC interface-based Super I/O device that comes with Environment Controller integration, floppy disk controller, UART controller and IR controller. Some of the features of the Winbond W83697HF chipset are listed below: LPC Spec.

  • Page 46: Super I/O Infrared 2

    KINO-6612 Mini-ITX Motherboard 2.6.3.2 Super I/O Infrared The onboard Super I/O supports the following infrared specifications: IrDA version 1.0 SIR protocol with a maximum baud rate up to 115.2Kbps Supports SHARP ASK-IR protocol with maximum baud rate of 57,600bps The infrared controller on the super I/O is interfaced through the board-to-board connectors on the KINO-6612 to an infrared pin-header on a backplane.

  • Page 47: Fintek F81216D Lpc Serial Port Chipset 2

    KINO-6612 Mini-ITX Motherboard 2.6.4 Fintek F81216D LPC Serial Port Chipset The KINO-6612 has a Fintek F81216D chipset onboard that enables the addition of four additional UART serial ports (COM3, COM4, COM5 and COM6). UART includes 16-byte send/receive FIFO. The Fintek serial port chipset is interfaced to the Southbridge chipset through the LPC bus.

  • Page 48: Pci Gbe Controllers 3

    KINO-6612 Mini-ITX Motherboard 2 x PCI GbE controllers 2.7.2 PCI Slot One PCI lanes is connected to a single PCI slot for PCI expansion. See F igure 2-15 7 6 0 H 7 6 2 H below. Figure 2-15: PCI Slot 2.7.3 PCI GbE Controllers Two PCI lanes are connected to two Realtek RTL8110SC GbE controllers shown in F igure 2-16 below.

  • Page 49: Figure 2-16: Realtek Pci Gbe Controllers

    KINO-6612 Mini-ITX Motherboard Figure 2-16: Realtek PCI GbE Controllers The Realtek RTL8110SC PCI GbE controllers combine a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, 32-bit PCI bus controller, and embedded memory. With state-of-the-art DSP technology and mixed-mode signal technology, they offer high-speed transmission over CAT 5 UTP cable or CAT 3 UTP (10Mbps only) cable.

  • Page 50: System Monitoring 3

    KINO-6612 Mini-ITX Motherboard Supports pair swap/polarity/skew correction Crossover Detection & Auto-Correction Wake-on-LAN and remote wake-up support Microsoft® NDIS5 Checksum Offload (IP, TCP, UDP) and largesend offload support Supports Full Duplex flow control (IEEE 802.3x) Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Supports IEEE 802.1P Layer 2 Priority Encoding Supports IEEE 802.1Q VLAN tagging Serial EEPROM...

  • Page 51: Table 2-3: Power Consumption

    KINO-6612 Mini-ITX Motherboard The KINO-6612 Super I/O Enhanced Hardware Monitor also monitors the following fan speeds: CPU Fan speed The values for the above environmental parameters are all recorded in the BIOS Hardware Health Configuration menu. 2.8.2 Operating Temperature and Temperature Control The maximum and minimum operating temperatures for the KINO-6612 are listed below.

  • Page 52: Unpacking 3

    KINO-6612 Mini-ITX Motherboard Chapter Unpacking Page 34...

  • Page 53: A Nti - Static P Recautions 3

    KINO-6612 Mini-ITX Motherboard 3.1 Anti-static Precautions WARNING! Failure to take ESD precautions during the installation of the KINO-6612 may result in permanent damage to the KINO-6612 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-6612.

  • Page 54: U Npacking C Hecklist 3

    KINO-6612 Mini-ITX Motherboard 3.3 Unpacking Checklist NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-6612 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 55: Optional Items

    KINO-6612 Mini-ITX Motherboard Dual RS-232 cable (P/N: 32200-028401-RS) I/O Shielding (P/N: 45002-450903-00-RS) Mini jumper pack (2.0mm) (P/N:33100-000033-RS) Utility CD Quick Installation Guide 3.3.2 Optional Items The KINO-6612 is shipped with the following components: Item and Part Number Image TV Out Cable (P/N:19800-000056-RS) CPU cooler (P/N: CF-479B-RS)
  • Page 56 KINO-6612 Mini-ITX Motherboard Dual RS-232 cable (P/N: 32200-000077-RS) Dual USB cable (w bracket) (P/N: CB-USB02-RS) Page 38...

  • Page 57: Connectors

    KINO-6612 Mini-ITX Motherboard Chapter Connectors Page 39...

  • Page 58: Peripheral Interface Connectors

    KINO-6612 Mini-ITX Motherboard 4.1 Peripheral Interface Connectors Section 4 .2 shows peripheral interface connector locations. Section 4 .2 lists all the 7 6 5 H 7 6 7 H 7 6 6 H 7 6 8 H peripheral interface connectors seen in Section 4 .2.

  • Page 59: Peripheral Interface Connectors

    KINO-6612 Mini-ITX Motherboard Figure 4-1: Connector and Jumper Locations 4.2 Peripheral Interface Connectors T able 4-1 shows a list of the peripheral interface connectors on the KINO-6612. Detailed 7 6 9 H 7 7 1 H descriptions of these connectors can be found below. Page 41...

  • Page 60: T Able 4-12: Pci Slot

    KINO-6612 Mini-ITX Motherboard Connector Type Label ATX power connector (20-pin) 20-pin ATX connector Backlight inverter connector 5-pin wafer INV1 CF Type II socket 50-pin socket GPIO connector 10-pin header DIO1 Fan connector, CPU 3-pin wafer FAN1 Fan connector, system 3-pin wafer FAN2 Front panel connector 14-pin header...

  • Page 61: External Interface Panel Connectors

    KINO-6612 Mini-ITX Motherboard TV out connector 6-pin header USB connector 8-pin header JUSB1 Table 4-1: Peripheral Interface Connectors 4.2.1 External Interface Panel Connectors T able 4-2 lists the rear panel connectors on the KINO-6612. Detailed descriptions of these 7 7 0 H 7 7 2 H connectors can be found in Section 4 .4 on page 6 6.

  • Page 62: Internal Peripheral Connectors

    KINO-6612 Mini-ITX Motherboard USB port USB port USB3 USB port USB port USB4 VGA port connector 15-pin female Table 4-2: Rear Panel Connectors 4.3 Internal Peripheral Connectors Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the KINO-6612.

  • Page 63: Backlight Inverter Connector

    KINO-6612 Mini-ITX Motherboard Figure 4-2: ATX Power Connector (20-pin) Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC5 PSON- VCC5 PWOK SB5V VCC5 +12V VCC5 Table 4-3: ATX Power Connector (20-pin) Pinouts 4.3.2 Backlight Inverter Connector CN Label: INV1 CN Type: 5-pin wafer (1x5) Page 45...

  • Page 64: Fan Connectors (+12V, 3-Pin)

    KINO-6612 Mini-ITX Motherboard F igure 4-3 CN Location: 7 7 5 H 7 7 7 H CN Pinouts: T able 4-4 7 7 6 H 7 7 8 H The backlight inverter connector provides the backlight on the LCD display connected to the KINO-6612 with +12V of power.

  • Page 65: Figure 4-4: +12V Fan Connector Location

    KINO-6612 Mini-ITX Motherboard The cooling fan connectors provide a 12V, 500mA current to two cooling fans. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed. Please note that only specified fans can issue the rotation signals.

  • Page 66: Front Panel Connector (14-Pin)

    KINO-6612 Mini-ITX Motherboard 4.3.4 Front Panel Connector (14-pin) CN Label: F_PANEL1, F_PANEL2 14-pin header (2x7) CN Type: CN Location: F igure 4-5 7 7 9 H 7 8 1 H CN Pinouts: T able 4-6 7 8 0 H 7 8 2 H The front panel connector connects to external switches and indicators to monitor and controls the motherboard.

  • Page 67: Gpio Connector

    KINO-6612 Mini-ITX Motherboard Button Reset HDD LED Reset- HDD LED- Table 4-6: Front Panel Connector Pinouts 4.3.5 GPIO Connector CN Label: CN14 CN Type: 10-pin header (2x5) CN Location: F igure 4-6 7 8 1 H 7 8 3 H CN Pinouts: T able 4-7 7 8 2 H 7 8 4 H...

  • Page 68: Ide Connector (40-Pin)

    KINO-6612 Mini-ITX Motherboard GPI2 GPI3 GPO0 GPO1 GPO2 GPO3 Table 4-7: GPIO Connector Pinouts 4.3.6 IDE Connector (40-pin) CN Label: IDE1 CN Type: 40-pin header (2x20) CN Location: F igure 4-7 7 8 3 H 7 8 5 H T able 4-8 CN Pinouts: 7 8 4 H 7 8 6 H One 40-pin IDE device connector on the KINO-6612 supports connectivity to two hard disk...

  • Page 69: Figure 4-7: Ide Device Connector Locations

    KINO-6612 Mini-ITX Motherboard Figure 4-7: IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0...

  • Page 70: Ide Connector(44-Pin)

    KINO-6612 Mini-ITX Motherboard HDC CS0# HDC CS1# HDD ACTIVE# GROUND Table 4-8: IDE Connector Pinouts 4.3.7 IDE Connector(44-pin) CN Label: IDE2 CN Type: 44-pin header (2x22) CN Location: F igure 4-8 7 8 5 H 7 8 7 H CN Pinouts: T able 4-9 7 8 6 H 7 8 8 H One 44-pin IDE device connector on the KINO-6612 supports connectivity to two hard disk...

  • Page 71: Figure 4-8: Secondary Ide Device Connector Locations

    KINO-6612 Mini-ITX Motherboard Figure 4-8: Secondary IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...

  • Page 72: Infrared Interface Connector (5-Pin)

    KINO-6612 Mini-ITX Motherboard HDC CS0# HDC CS1# HDD ACTIVE# GROUND GROUND Table 4-9: Secondary IDE Connector Pinouts 4.3.8 Infrared Interface Connector (5-pin) CN Label: CN Type: 5-pin header (1x5) CN Location: F igure 4-9 7 8 7 H 7 8 9 H CN Pinouts: T able 4-10 7 8 8 H 7 9 0 H...

  • Page 73: Lvds Lcd Connector

    KINO-6612 Mini-ITX Motherboard IR-RX IR-TX Table 4-10: Infrared Connector Pinouts 4.3.9 LVDS LCD Connector CN Label: LVDS1 CN Type: 30-pin crimp (2x10) F igure 4-10 CN Location: 7 8 9 H 7 9 1 H CN Pinouts: T able 4-11 7 9 0 H 7 9 2 H The 30-pin LVDS LCD connector can be connected to single channel or dual channel, 18-bit or 36-bit LVDS panel.

  • Page 74: F Igure 2-15: Pci Slot

    KINO-6612 Mini-ITX Motherboard CLK1P CLK1M CLK2P CLK2M LCD_VDD LCD_VDD LCD_VDD LCD_VDD Table 4-11: LVDS LCD Port Connector Pinouts 4.3.10 PCI Slot PCI1 CN Label: CN Type: PCI Slot CN Location: F igure 4-11 7 9 1 H 7 9 3 H CN Pinouts: T able 4-12 7 9 2 H 7 9 4 H...

  • Page 75: Figure 4-11: Pci Slot Location

    KINO-6612 Mini-ITX Motherboard Figure 4-11: PCI Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION TRST -12V +12V INTA INTC INTB INTD RESERVED3 PRSNT1 RESERVED1 RESERVED4 PRSNT2 Page 57...
  • Page 76 KINO-6612 Mini-ITX Motherboard 3.3V_AUX RESERVED2 AD30 AD31 +3.3V AD29 AD28 AD26 AD27 AD25 AD24 +3.3V IDSEL C/BE3 +3.3V AD23 AD22 AD20 AD21 AD19 AD18 +3.3V AD16 AD17 +3.3V C/BE2 FRAME IRDY TRDY +3.3V DEVSEL STOP +3.3V LOCK SDONE PERR +3.3V SERR +3.3V AD15...

  • Page 77: Sata Drive Connectors 5

    KINO-6612 Mini-ITX Motherboard AD13 AD11 AD12 AD10 C/BE0 +3.3V +3.3V REQ64 ACK64 Table 4-12: PCI Slot 4.3.11 SATA Drive Connectors CN Label: SATA1, SATA2 7-pin SATA drive connectors CN Type: CN Location: F igure 4-12 7 9 3 H 7 9 5 H CN Pinouts: T able 4-13 7 9 4 H 7 9 6 H...

  • Page 78: Figure 4-12: Sata Drive Connector Locations

    KINO-6612 Mini-ITX Motherboard Figure 4-12: SATA Drive Connector Locations PIN NO. DESCRIPTION Table 4-13: SATA Drive Connector Pinouts Page 60...

  • Page 79: Serial Port Connectors (Com 3, Com4, Com5 And Com6)

    KINO-6612 Mini-ITX Motherboard 4.3.12 Serial Port Connectors (COM 3, COM4, COM5 and COM6) CN Label: COM 3, COM4, COM5 and COM6 10-pin header (2x5) CN Type: CN Location: F igure 4-13 7 9 5 H 7 9 7 H CN Pinouts: T able 4-14 7 9 6 H 7 9 8 H The 10-pin serial port connector provides a second RS-232 serial communications...

  • Page 80: Serial Port Connector (Com 2)(Rs-232, Rs-422 Or Rs-485)

    KINO-6612 Mini-ITX Motherboard PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data Carrier Direct (DCD) Data Set Ready (DSR) Receive Data (RXD) Request To Send (RTS) Transmit Data (TXD) Clear To Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) Table 4-14: COM Connector Pinouts 4.3.13 Serial Port Connector (COM 2)(RS-232, RS-422 or RS-485) CN Label:...

  • Page 81: Figure 4-14: Rs-232/422/485 Serial Port Connector Location

    KINO-6612 Mini-ITX Motherboard Figure 4-14: RS-232/422/485 Serial Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD NDSR NRTS NCTS2 NDTR Table 4-15: RS-232/RS-485 Serial Port Connector Pinouts Page 63...

  • Page 82: Tv Out Connector

    KINO-6612 Mini-ITX Motherboard 4.3.14 TV Out Connector CN Label: 6-pin header (2x3) CN Type: CN Location: F igure 4-15 7 9 9 H 8 0 1 H CN Pinouts: T able 4-16 8 0 0 H 8 0 2 H The 2x3 pin TV out connector connects to a TV output by using an S-Video or RCA connector.

  • Page 83: Usb Connectors (Internal)

    KINO-6612 Mini-ITX Motherboard 4.3.15 USB Connectors (Internal) CN Label: JUSB1 8-pin header (2x4) CN Type: CN Location: F igure 4-16 8 0 1 H 8 0 3 H CN Pinouts: T able 4-17 8 0 2 H 8 0 4 H The 2x4 USB pin connectors each provide connectivity to two USB 1.1 or two USB 2.0 ports.

  • Page 84: External Peripheral Interface Connector Panel

    KINO-6612 Mini-ITX Motherboard PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATAN- DATA1M- DATAN+ DATAM+ Table 4-17: USB Port Connector Pinouts 4.4 External Peripheral Interface Connector Panel F igure 4-17 shows the KINO-6612 external peripheral interface connector (EPIC) panel. 8 0 3 H 8 0 5 H The KINO-6612 EPIC panel consists of the following: 2 x Audio jack connectors 2 x RJ-45 LAN connectors...

  • Page 85: Audio Connector

    KINO-6612 Mini-ITX Motherboard 4.4.1 Audio Connector CN Label: AUDIO1 2 x audio jacks CN Type: CN Location: F igure 4-17 8 0 4 H 8 0 6 H The three audio jacks on the external audio connector enable the KINO-6612 to be connected to external audio devices as specified below.

  • Page 86: Keyboard/Mouse Connector

    KINO-6612 Mini-ITX Motherboard 4.4.2 Keyboard/Mouse Connector CN Label: KB/MS1 Dual PS/2 CN Type: CN Location: F igure 4-17 8 0 5 H 8 0 7 H CN Pinouts: F igure 4-19 and T able 4-18 8 0 6 H 8 0 8 H 8 0 7 H 8 0 9 H The KINO-6612 keyboard and mouse connectors are standard PS/2 connectors.

  • Page 87: Lan Connectors

    KINO-6612 Mini-ITX Motherboard DESCRIPTION DESCRIPTION L_KDAT L_MDAT L_KCLK L_MCLK Table 4-18: PS/2 Connector Pinouts 4.4.3 LAN Connectors CN Label: LAN1A and LAN2A CN Type: RJ-45 CN Location: F igure 4-17 8 0 8 H 8 1 0 H T able 4-19 CN Pinouts: 8 0 9 H 8 1 1 H The KINO-6612 is equipped with two built-in RJ-45 Ethernet controllers.

  • Page 88: Serial Port Connector (Com1)

    KINO-6612 Mini-ITX Motherboard DESCRIPTION DESCRIPTION TXA+ TXC- TXA- TXB- TXB+ TXD+ TXC+ TXD- Table 4-19: LAN Pinouts Figure 4-20: RJ-45 Ethernet Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See T able 4-20.

  • Page 89: Usb Connectors

    KINO-6612 Mini-ITX Motherboard PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 4-21: RS-232 Serial Port (COM 1) Pinouts Figure 4-21: COM1 Pinout Locations 4.4.5 USB Connectors CN Label: USB1, USB2, USB3, USB4 CN Type: USB port CN Location: F igure 4-17 8 1 4 H 8 1 6 H CN Pinouts: T able 4-22...

  • Page 90: Vga Connector

    KINO-6612 Mini-ITX Motherboard PIN NO. DESCRIPTION PIN NO. DESCRIPTION USBV3L 5V USBP4N USBP5P USBP4P USBP5N USBV3L 5V Table 4-22: USB Port Pinouts 4.4.6 VGA Connector VGA1 CN Label: CN Type: 15-pin Female CN Location: F igure 4-17 8 1 6 H 8 1 8 H CN Pinouts: F igure 4-22 and T able 4-23...

  • Page 91: Table 4-23: Vga Connector Pinouts

    KINO-6612 Mini-ITX Motherboard DESCRIPTION DESCRIPTION GREEN BLUE VCC / NC DDC DAT HSYNC VSYNC DDCCLK Table 4-23: VGA Connector Pinouts Page 73...

  • Page 92: Installation

    KINO-6612 Mini-ITX Motherboard Chapter Installation Page 74...

  • Page 93: Anti-Static Precautions

    KINO-6612 Mini-ITX Motherboard 5.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the KINO-6612 may result in permanent damage to the KINO-6612 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-6612.

  • Page 94: Installation Considerations

    KINO-6612 Mini-ITX Motherboard 5.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the KINO-6612 is installed. All installation notices pertaining to the installation of the KINO-6612 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the KINO-6612 and injury to the person installing the motherboard.

  • Page 95: Installation Checklist 7

    KINO-6612 Mini-ITX Motherboard When working with the KINO-6612, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the KINO-6612 DO NOT: Remove any of the stickers on the PCB board. These stickers are required for warranty validation.

  • Page 96: Unpacking

    KINO-6612 Mini-ITX Motherboard RS-232 serial communications device USB devices 5.3 Unpacking When the KINO-6612 is unpacked, please check all the unpacking list items listed in Chapter 3 are indeed present. If any of the unpacking list items are not available please contact the KINO-6612 vendor reseller/vendor where the KINO-6612 was purchased or contact an IEI sales representative.

  • Page 97: Figure 5-1: Make Sure The Cpu Socket Retention Screw Is Unlocked

    KINO-6612 Mini-ITX Motherboard To install a socket 479 CPU onto the KINO-6612, follow the steps below: WARNING: When handling the CPU, only hold it on the sides. DO NOT touch the pins at the bottom of the CPU. Step 1: Unlock the CPU retention screw.

  • Page 98: Figure 5-2: Lock The Cpu Socket Retention Screw

    KINO-6612 Mini-ITX Motherboard CPU socket. See F igure 5-1. 8 2 0 H 8 2 2 H Step 5: Align the CPU pins. Carefully align the CPU pins with the holes in the CPU socket. Step 6: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are properly aligned, the CPU should slide into the CPU socket smoothly.

  • Page 99: Figure 5-3: Iei Cf-479B-Rs Cooling Kit

    KINO-6612 Mini-ITX Motherboard 5.4.2 Cooling Kit CF-479B-RS Installation Figure 5-3: IEI CF-479B-RS Cooling Kit An IEI Socket 479 CPU cooling kit ( F igure 5-3) can be purchased separately. The cooling 8 2 2 H 8 2 4 H kit comprises a CPU heat sink and a cooling fan. WARNING: Do not wipe off (accidentally or otherwise) the pre-sprayed layer of thermal paste on the bottom of the [Fan model#] heat sink.

  • Page 100: Figure 5-4: Cooling Kit Support Bracket

    KINO-6612 Mini-ITX Motherboard Figure 5-4: Cooling Kit Support Bracket Step 4: Tighten the screws. Use a screwdriver to tighten the four screws. Tighten each nut a few turns at a time and do not over-tighten the screws. Step 5: Connect the fan cable. Connect the cooling kit fan cable to the fan connector on the motherboard.

  • Page 101: Figure 5-6: Installing A Dimm

    KINO-6612 Mini-ITX Motherboard 5.4.3 DIMM Installation WARNING: Using incorrectly specified DIMM may cause permanently damage the KINO-6612. Please make sure the purchased DIMM complies with the memory specifications of the KINO-6612. DIMM specifications compliant with the KINO-6612 are listed in Chapter 2. To install a DIMM into a DIMM socket, please follow the steps below and refer to F igure 5-6.

  • Page 102: Figure 5-7: Jumper Locations

    KINO-6612 Mini-ITX Motherboard in the socket. See F igure 5-6. 8 2 7 H 8 2 9 H Step 3: Insert the DIMM. Once properly aligned, the DIMM can be inserted into the socket. As the DIMM is inserted, the white handles on the side of the socket will close automatically and secure the DIMM to the socket.

  • Page 103: Table 5-1: Jumpers

    KINO-6612 Mini-ITX Motherboard Table 5-1: Jumpers 5.5.1 Clear CMOS Jumper Jumper Label: Jumper Type: 3-pin header Jumper Settings: T able 5-2 8 3 0 H 8 3 2 H Jumper Location: F igure 5-8 8 3 1 H 8 3 3 H If the KINO-6612 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information.

  • Page 104: Figure 5-8: Clear Cmos Jumper

    KINO-6612 Mini-ITX Motherboard Figure 5-8: Clear CMOS Jumper 5.5.2 CPU Frequency Setup Jumper Jumper Label: Jumper Type: 3-pin header Jumper Settings: T able 5-3 8 3 4 H 8 3 6 H Jumper Location: F igure 5-9 8 3 5 H 8 3 7 H The CPU Frequency setup jumper enables a user to select the frequency of the CPU on the KINO-6612.

  • Page 105: Figure 5-9: Cpu Frequency Setup Jumper

    KINO-6612 Mini-ITX Motherboard Figure 5-9: CPU Frequency Setup Jumper 5.5.3 FSB Setup Jumper Jumper Label: Jumper Type: 3-pin header Jumper Settings: T able 5-4 8 3 8 H 8 4 0 H Jumper Location: F igure 5-10 8 3 9 H 8 4 1 H The clear FSB setup jumper enables a user to select the FSB speed on the KINO-6612.

  • Page 106: Figure 5-10: Fsb Setup Jumper

    KINO-6612 Mini-ITX Motherboard Figure 5-10: FSB Setup Jumper 5.5.4 LCD Voltage Selection WARNING: Permanent damage to the screen and KINO-6612 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that came with the monitor to select the correct voltage. Jumper Label: Jumper Type: 6-pin header...

  • Page 107: Figure 5-11: Lcd Voltage Selection Jumper Location

    KINO-6612 Mini-ITX Motherboard AT Power Select Description Short 1-2 Default Short 2-3 Short 2-3 +12V Table 5-5: LCD Voltage Selection Jumper Settings The LCD Voltage Selection jumper location. is shown in F igure 5-11. 8 4 5 H 8 4 7 H Figure 5-11: LCD Voltage Selection Jumper Location 5.5.5 RS-232/485 Serial Port Select Jumper Jumper Label:...

  • Page 108: Figure 5-12: Rs-232/485 Serial Port Select Jumper Location

    KINO-6612 Mini-ITX Motherboard The RS-232 or RS-422/RS-485 Serial Port Select jumper sets the communication protocol used by the second serial communications port (COM2) as RS-232 or RS-422/RS-485. The RS-232 or RS-422/RS-485 Serial Port Select settings are shown in T able 5-6. 8 4 8 H 8 5 0 H RS-232/485 Select Description...

  • Page 109: Table 5-7: Iei Provided Cables

    KINO-6612 Mini-ITX Motherboard The KINO-6612 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 110: Figure 5-13: Ide Cable Connection

    KINO-6612 Mini-ITX Motherboard Some optional items that can be purchased separately and installed on the KINO-6612 include: TV-OUT cable Dual RS-232 cable Dual USB cable 5.7.2 ATA Flat Cable Connection The ATA 66/100 flat cable connects to the KINO-6612 to one or two IDE devices. To connect an IDE HDD to the KINO-6612 please follow the instructions below.

  • Page 111: Figure 5-14: Sata Drive Cable Connection

    KINO-6612 Mini-ITX Motherboard Step 3: Connect the cable to an IDE device. Connect the two connectors on the other side of the cable to one or two IDE devices. Make sure that pin 1 on the cable corresponds to pin 1 on the connector. Step 0: 5.7.3 SATA Drive Connection The KINO-6612 is shipped with two SATA drive cables and one SATA drive power cable.

  • Page 112: Figure 5-15: Sata Power Drive Connection

    KINO-6612 Mini-ITX Motherboard of the cable to the connector at the back of the SATA drive. See F igure 5-15. 8 5 3 H 8 5 5 H Step 4: Connect the SATA power cable. Connect the SATA power connector to the back of the SATA drive.

  • Page 113: Figure 5-16: Dual Rs-232 Cable Installation

    KINO-6612 Mini-ITX Motherboard Figure 5-16: Dual RS-232 Cable Installation Step 3: Secure the bracket. The dual RS-232 connector has two D-sub 9 male connectors secured on a bracket. To secure the bracket to the chassis please refer to the reference material that came with the chassisStep 0: 5.7.5 USB Cable (Dual Port) with Slot Bracket The KINO-6612 is shipped with a dual port USB 2.0 cable.

  • Page 114: Figure 5-17: Dual Usb Cable Connection

    KINO-6612 Mini-ITX Motherboard Step 2: Align the connectors. The cable has two connectors. Correctly align pin 1on each cable connector with pin 1 on the KINO-6612 USB connector. Step 3: Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the KINO-6612, connect the cable connectors to the onboard connectors.

  • Page 115: E Xternal P Eripheral I Nterface C Onnection 9

    KINO-6612 Mini-ITX Motherboard 5.8 External Peripheral Interface Connection The following external peripheral devices can be connected to the external peripheral interface connectors. Audio devices RJ-45 Ethernet cable connectors PS/2 devices Serial port devices USB devices VGA monitors To install these devices, connect the corresponding cable connector from the actual device to the corresponding KINO-6612 external peripheral interface connector making sure the pins are properly aligned.

  • Page 116: Figure 5-18: Audio Connectors

    KINO-6612 Mini-ITX Motherboard Figure 5-18: Audio Connectors 5.8.2 LAN Connection (Single Connector) There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection to an external network. To connect a LAN cable with an RJ-45 connector, please follow the instructions below. Step 1: Locate the RJ-45 connectors.

  • Page 117: Figure 5-19: Lan Connection

    KINO-6612 Mini-ITX Motherboard Figure 5-19: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the onboard RJ-45 connector. Step 0: 5.8.3 Parallel Device Connection The KINO-6612 has a single female DB-25 connector on the external peripheral interface panel for parallel devices.

  • Page 118: Figure 5-20: Parallel Device Connector

    KINO-6612 Mini-ITX Motherboard Figure 5-20: Parallel Device Connector Step 3: Secure the connector. Secure the DB-25 connector to the external interface by tightening the two retention screws on either side of the connector. Step 0: 5.8.4 PS/2 Keyboard and Mouse Connection The KINO-6612 has a dual PS/2 connector on the external peripheral interface panel.

  • Page 119: Figure 5-21: Ps/2 Keyboard/Mouse Connector

    KINO-6612 Mini-ITX Motherboard Figure 5-21: PS/2 Keyboard/Mouse Connector 5.8.5 Serial Device Connection The KINO-6612 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the KINO-6612.

  • Page 120: Figure 5-22: Serial Device Connector

    KINO-6612 Mini-ITX Motherboard Figure 5-22: Serial Device Connector Step 3: Secure the connector. Secure the serial device connector to the external interface by tightening the two retention screws on either side of the connector. Step 0: 5.8.6 USB Connection (Dual Connector) The external USB Series "A"...

  • Page 121: Figure 5-23: Usb Connector

    KINO-6612 Mini-ITX Motherboard Figure 5-23: USB Connector 5.8.7 VGA Monitor Connection The KINO-6612 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the KINO-6612, please follow the instructions below.
  • Page 122 KINO-6612 Mini-ITX Motherboard Figure 5-24: VGA Connector Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA monitor to the external interface by tightening the two retention screws on either side of the connector. Step 0: Page 104...

  • Page 123: Bios Screens 1

    KINO-6612 Mini-ITX Motherboard Chapter BIOS Screens Page 105...

  • Page 124: Introduction

    KINO-6612 Mini-ITX Motherboard 6.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 125: Unable To Reboot After Configuration Changes

    KINO-6612 Mini-ITX Motherboard F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 6-1: BIOS Navigation Keys 6.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the...

  • Page 126: Main

    KINO-6612 Mini-ITX Motherboard 6.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered. 8 6 4 H 8 6 6 H The Main menu gives an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components.

  • Page 127: Advanced

    KINO-6612 Mini-ITX Motherboard Processor: Displays auto-detected CPU specifications Type: Names the currently installed processor Speed: Lists the processor speed Count: The number of CPUs on the motherboard System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time.

  • Page 128: Cpu Configuration

    KINO-6612 Mini-ITX Motherboard MPS Configuration (see Section 6 .3.6) 8 7 1 H 8 7 3 H USB Configuration (see Section 6 .3.7) 8 7 2 H 8 7 4 H BIOS Menu 2: Advanced 6.3.1 CPU Configuration Use the CPU Configuration menu ( B IOS Menu 3) to view detailed CPU specifications 8 7 3 H 8 7 5 H and configure the CPU.
  • Page 129 KINO-6612 Mini-ITX Motherboard BIOS Menu 3: CPU Configuration The CPU Configuration menu ( B IOS Menu 3) lists the following CPU details: 8 7 4 H 8 7 6 H Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used Frequency: Lists the CPU processing speed FSB Speed: Lists the FSB speed Cache L1: Lists the CPU L1 cache size...

  • Page 130: Ide Configuration

    KINO-6612 Mini-ITX Motherboard Intel (R) SpeedStep (tm) tech. [Automatic] Use the Intel (R) SpeedStep (tm) tech. option to set the CPU speed. Maximum Speed CPU speed is set to maximum EFAULT Minimum Speed CPU speed is set to minimum Disabled CPU speed is disabled Clock Spread Spectrum [Disabled] The Clock Spread Spectrum BIOS option can help to improve CPU EMI issues.
  • Page 131 KINO-6612 Mini-ITX Motherboard BIOS Menu 4: IDE Configuration OnBoard PCI IDE Controller [Both] The OnBoard PCI IDE Controller BIOS option specifies the IDE channels used by the onboard PCI IDE controller. The following configuration options are available. Disabled Disables all IDE controllers Primary Only enables the primary IDE controller Secondary...
  • Page 132 KINO-6612 Mini-ITX Motherboard Legacy Mode The PCI IDE mode will be the same as the IDE mode The PCI IDE mode will be the native mode Native Mode EFAULT Onboard PCI S-ATA Controller The Onboard PCI S-ATA Controller option sets the onboard SATA controller. If the RAID function is used (see Appendix E) this option must be set in the RAID mode.

  • Page 133: Ide Master, Ide Slave

    KINO-6612 Mini-ITX Motherboard 6.3.2.1 IDE Master, IDE Slave Use the IDE Master and IDE Slave configuration menu to view both primary and secondary IDE device details and configure the IDE devices connected to the system. BIOS Menu 5: IDE Master and IDE Slave Configuration Auto-Detected Drive Parameters The “grayed-out”...
  • Page 134 KINO-6612 Mini-ITX Motherboard Size: List the storage capacity of the device. LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method of addressing data on a disk drive is supported or not. Block Mode: Block mode boosts IDE drive performance by increasing the amount of data transferred.
  • Page 135 KINO-6612 Mini-ITX Motherboard LS-120 LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB. BIOS is prevented from using the LBA mode control on Disabled the specified channel.
  • Page 136 KINO-6612 Mini-ITX Motherboard Use the PIO Mode option to select the IDE PIO (Programmable I/O) mode program timing cycles between the IDE drive and the programmable IDE controller. As the PIO mode increases, the cycle time decreases. Auto BIOS auto detects the PIO mode. Use this value if the IDE disk EFAULT drive support cannot be determined.
  • Page 137 KINO-6612 Mini-ITX Motherboard transfer rate of 4.2MBps MWDMA1 Multi Word DMA mode 1 selected with a maximum data transfer rate of 13.3MBps MWDMA2 Multi Word DMA mode 2 selected with a maximum data transfer rate of 16.6MBps UDMA1 Ultra DMA mode 0 selected with a maximum data transfer rate of 16.6MBps UDMA1 Ultra DMA mode 1 selected with a maximum data transfer...

  • Page 138: Super Io Configuration

    KINO-6612 Mini-ITX Motherboard Disabled Prevents BIOS from using the HDD SMART feature. Enabled Allows BIOS to use the HDD SMART feature 32Bit Data Transfer [Enabled] Use the 32Bit Data Transfer BIOS option to enables or disable 32-bit data transfers. Prevents the BIOS from using 32-bit data transfers. Disabled Allows BIOS to use 32-bit data transfers on supported Enabled...
  • Page 139 KINO-6612 Mini-ITX Motherboard Serial Port1 Address [3F8/IRQ4] Use the Serial Port1 Address option to select the Serial Port 1 base address. Disabled No base address is assigned to Serial Port 1 3F8/IRQ4 Serial Port 1 I/O port address is 3F8 and the interrupt EFAULT address is IRQ4 3E8/IRQ4...
  • Page 140 KINO-6612 Mini-ITX Motherboard ASK IR Serial Port 2 mode is ASK IR Onboard CIR Port [Disabled] Use the Onboard CIR Port option to select the CIR base address. Disabled No base address is assigned to CIR EFAULT CIR base address is 3E0 CIR base address is 2E0 Parallel Port Address [Disabled] Use the Parallel Port Address option to select the parallel port base address.
  • Page 141 KINO-6612 Mini-ITX Motherboard and the parallel port device and the transmission rates between the two are much faster than the Normal mode. ECP+EPP The parallel port operates in the extended capabilities port (ECP) mode. The ECP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster than the Normal mode...
  • Page 142 KINO-6612 Mini-ITX Motherboard Serial port 3 IRQ address is 4 Serial port 3 IRQ address is 9 Serial port 3 IRQ address is 10 Serial port 3 IRQ address is 11 EFAULT Serial Port4 Address [2E8] Use the Serial Port4 IRQ option to select the interrupt address for serial port 4. Disabled No base address is assigned to serial port 3 Serial port 4 I/O port address is 3E8...

  • Page 143: Hardware Health Configuration

    KINO-6612 Mini-ITX Motherboard Serial port 5 I/O port address is 2E8 Serial port 5 I/O port address is 2E0 EFAULT Serial port 5 I/O port address is 2D0 Serial Port5 IRQ [11] Use the Serial Port5 IRQ option to select the interrupt address for serial port 5. Serial port 5 IRQ address is 10 Serial port 5 IRQ address is 11 EFAULT...
  • Page 144 KINO-6612 Mini-ITX Motherboard BIOS Menu 7: Hardware Health Configuration The following system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored Temperature Sensor #1 System Temperature Fan Speeds: The CPU cooling fan speed is monitored. Fan1 Speed Voltages: The following system voltages are monitored Vcore...

  • Page 145: Acpi Configuration

    KINO-6612 Mini-ITX Motherboard 6.3.5 ACPI Configuration The ACPI Configuration menu ( B IOS Menu 8) configures the Advanced Configuration 8 8 0 H 8 8 2 H and Power Interface (ACPI) and Power Management (APM) options. BIOS Menu 8: ACPI Configuration ACPI Aware O/S [Yes] ACPI Aware O/S can only be configured if the OS complies with the ACPI standard.

  • Page 146: Advanced Acpi Configuration

    KINO-6612 Mini-ITX Motherboard selection should be enabled if the OS does support ACPI 6.3.5.1 Advanced ACPI Configuration The Advanced ACPI Configuration menu ( B IOS Menu 9) selects the ACPI state when the 8 8 1 H 8 8 3 H system is suspended.

  • Page 147: Mps Configuration

    KINO-6612 Mini-ITX Motherboard (Default) RSDP pointers to 64-bit fixed systems are not provided to the system RSDP pointers to 64-bit fixed systems are provided to the system ACPI APIC Support [Enabled] The ACPI APIC Support BIOS option adds a pointer to an ACPI APIC table in the RSDT (Root System Description Table).

  • Page 148: Usb Configuration

    KINO-6612 Mini-ITX Motherboard BIOS Menu 10: MPS Configuration MPS Revision [1.1] The Multiprocessor Specification (MPS) for OS specifies the MPS version to be used. (Default) MPS version 1.1 is used MPS version 1.4 is used 6.3.7 USB Configuration Use the USB Configuration menu ( B IOS Menu 11) to read USB configuration 8 8 3 H 8 8 5 H information and configure the USB settings.
  • Page 149 KINO-6612 Mini-ITX Motherboard BIOS Menu 11: USB Configuration Onboard SiS USB1.1 DEVICE [Enabled] The Onboard SiS USB1.1 DEVICE BIOS option enables or disables the onboard SiS USB1.1 controller. If disabled, USB1.1 devices cannot be used on the system. Disabled USB 1.1 interface is disabled and cannot be used. Enabled USB 1.1 interface is enabled and can be used.
  • Page 150 KINO-6612 Mini-ITX Motherboard Enabled USB 2.0 interface is enabled and can be used. EFAULT Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded.

  • Page 151: Pci/P N

    KINO-6612 Mini-ITX Motherboard Enabled Systems with OSes that do not support EHCI cannot EFAULT use the EHCI handoff functionality. 6.4 PCI/PnP Use the PCI/PnP menu ( B IOS Menu 12) to configure advanced PCI and PnP settings. 8 8 4 H 8 8 6 H WARNING: Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction.
  • Page 152 KINO-6612 Mini-ITX Motherboard Clear NVRAM [No] Use the Clear NVRAM option to specify if the NVRAM (Non-Volatile RAM) is cleared when the power is turned off. System does not clear NVRAM during system boot EFAULT System clears NVRAM during system boot Plug &...
  • Page 153 KINO-6612 Mini-ITX Motherboard Allocate IRQ to PCI VGA [Yes] Use the Allocate IRQ to PCI VGA option to restrict the system from giving the VGA adapter card an interrupt address. Assigns an IRQ to a PCI VGA card if card requests IRQ EFAULT Does not assign IRQ to a PCI VGA card even if the card requests an IRQ...
  • Page 154 KINO-6612 Mini-ITX Motherboard OffBoard PCI/ISA IDE Card [Auto] Use the OffBoard PCI/ISA IDE Card BIOS option to select the OffBoard PCI/ISA IDE Card. Auto The location of the Off Board PCI IDE adapter card is EFAULT automatically detected by the AMIBIOS. PCI Slot 1 PCI Slot 1 is selected as the location of the OffBoard PCI IDE adapter card.
  • Page 155 KINO-6612 Mini-ITX Motherboard IRQ# [Available] Use the IRQ# address to specify what IRQs can be assigned to a particular peripheral device. Available The specified IRQ is available to be used by EFAULT PCI/PnP devices Reserved The specified IRQ is reserved for use by Legacy ISA devices Available IRQ addresses are: IRQ3...
  • Page 156 KINO-6612 Mini-ITX Motherboard DM Channel 1 DM Channel 3 DM Channel 5 DM Channel 6 DM Channel 7 Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices. Disabled No memory block reserved for legacy ISA devices EFAULT...

  • Page 157: Boot

    KINO-6612 Mini-ITX Motherboard 6.5 Boot Use the Boot menu ( B IOS Menu 13) to configure system boot options. 8 8 5 H 8 8 7 H BIOS Menu 13: Boot 6.5.1 Boot Settings Configuration Use the Boot Settings Configuration menu ( B IOS Menu 13) to configure advanced system 8 8 6 H 8 8 8 H boot options.
  • Page 158 KINO-6612 Mini-ITX Motherboard BIOS Menu 14: Boot Settings Configuration Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. Disabled No POST procedures are skipped Enabled Some POST procedures are skipped to decrease EFAULT the system boot time Quiet Boot [Disabled]...
  • Page 159 KINO-6612 Mini-ITX Motherboard Enabled OEM Logo displayed instead of POST messages AddOn ROM Display Mode [Force BIOS] The AddOn ROM Display Mode option allows add-on ROM (read-only memory) messages to be displayed. Allows the computer system to force a third party Force BIOS EFAULT BIOS to display during system boot.
  • Page 160 KINO-6612 Mini-ITX Motherboard Disabled PS/2 mouse support is disabled and prevented from using system resources. Allows the system to use a PS/2 mouse. Enabled EFAULT Auto The system auto-adjusts PS/2 mouse support. Wait For ‘F1’ If Error [Enabled] Use the Wait For ‘F1’ if Error option to specify how the system responds when the system detects an error on boot up.

  • Page 161: Boot Device Priority

    KINO-6612 Mini-ITX Motherboard Interrupt 19 Capture [Disabled] Use the Interrupt 19 Capture option to allow optional ROMs such as network controllers to trap BIOS interrupt 19. Disabled Does not allow optional ROM to trap interrupt 19 EFAULT Allows optional ROM to trap interrupt 19 Enabled 6.5.2 Boot Device Priority Use the Boot Device Priority menu (...

  • Page 162: Security

    KINO-6612 Mini-ITX Motherboard BIOS Menu 15: Boot Device Priority Settings 6.6 Security Use the Security menu ( B IOS Menu 16) to set system and user passwords. 8 8 8 H 8 9 0 H Page 144...
  • Page 163 KINO-6612 Mini-ITX Motherboard BIOS Menu 16: Security Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed. If a supervisor password must be installed, select this field and enter the password. After the password has been added, Install appears next to Change Supervisor Password.

  • Page 164: Chipset

    KINO-6612 Mini-ITX Motherboard 6.7 Chipset Use the Chipset menu ( B IOS Menu 17) to access the NorthBridge and SouthBridge 8 8 9 H 8 9 1 H configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.
  • Page 165 KINO-6612 Mini-ITX Motherboard BIOS Menu 18:NorthBridge Chipset Configuration Primary Graphics Adapter [PCI] Use the Primary Graphics Adapter option to select the graphics adapter the system is connected to. PCI graphics adapter is used EFAULT AGP graphics adapter is used DRAM CAS# Latency [By SPD] The DRAM CAS# Latency option sets the CAS (Column Address Strobe) latency.
  • Page 166 KINO-6612 Mini-ITX Motherboard By SPD D EFAULT 2.5T Graphic Win Size [64MB] The Graphic Win Size selects the size of the AGP aperture and the size of the GART (Graphics Address Relocation Table). The aperture is a portion on the PCI memory address range dedicated for use as AGP memory address space and the GART is a translation table that translates the AGP memory addresses into actual addresses.
  • Page 167 KINO-6612 Mini-ITX Motherboard LCD Display Type [Full Screen] Use the LCD Display Type BIOS to specify the screen display type. Configuration options are listed below: Full Screen EFAULT Center Screen LCD Panel Resolution Type Use the LCD Panel Resolution Type to determine the LCD panel resolution. Configuration options are listed below: 1024 x 768 1280 x 1924...

  • Page 168: Southbridge Configuration

    KINO-6612 Mini-ITX Motherboard TV UnderScan/OverScan Use the TV UnderScan/OverScan option to specify whether overscan or underscan functionalities are enabled on the system. Configuration options are listed below. UNDERSCAN OVERSCAN Different YPbPrTV Use the Different YPbPrTV option to specify the YPbPr TV settings. Configuration options are listed below.
  • Page 169 KINO-6612 Mini-ITX Motherboard BIOS Menu 19:SouthBridge Chipset Configuration OnBoard AC97 Audio Device The OnBoard AC97 Audio Device option enables or disables the AC’97 CODEC. Disabled The onboard AC’97 is disabled Auto The onboard AC’97 automatically detected and enabled EFAULT OnBoard Lan Rom [Enabled] The OnBoard Lan Rom option enables or disables the onboard LAN.

  • Page 170: Power

    KINO-6612 Mini-ITX Motherboard enabled 6.8 Power The Power menu ( B IOS Menu 20) allows the advanced power management options to be 8 9 2 H 8 9 4 H configured. BIOS Menu 20:Power Power Management/APM [Enabled] Use the Power Management/APM BIOS option to enable access to the advanced power management features.
  • Page 171 KINO-6612 Mini-ITX Motherboard feature Enabled Enables the APM feature EFAULT Power Button Mode [On/Off] Use the Power Button Mode BIOS to specify how the power button functions. On/Off When the power button is pressed the system is either EFAULT turned on or off Suspend When the power button is pressed the system goes into suspend mode...
  • Page 172 KINO-6612 Mini-ITX Motherboard RI Resume [Disabled] The RI Resume BIOS option specifies if the system will be roused from a suspended or standby state when there is activity on the RI (ring in) modem line. That is, the system will be roused by an incoming call on a modem.

  • Page 173: Exit

    KINO-6612 Mini-ITX Motherboard 6.9 Exit Use the Exit menu ( B IOS Menu 21) to load default BIOS values, optimal failsafe values 8 9 3 H 8 9 5 H and to save configuration changes. BIOS Menu 21:Exit Save Changes and Exit Use the Save Changes and Exit option to save the changes made to the BIOS options and to exit the BIOS configuration setup program.
  • Page 174 KINO-6612 Mini-ITX Motherboard Discard Changes Use the Discard Changes option to discard the changes and remain in the BIOS configuration setup program. Load Optimal Defaults Use the Load Optimal Defaults option to load the optimal default values for each of the parameters on the Setup menus.

  • Page 175: Software Drivers

    KINO-6612 Mini-ITX Motherboard Chapter Software Drivers Page 157...

  • Page 176: Installation

    KINO-6612 Mini-ITX Motherboard 7.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The following drivers can be installed on the system: SiS AGP SIS-IDE...

  • Page 177: Figure 7-2: Preparing Setup Screen

    KINO-6612 Mini-ITX Motherboard Step 3: The “Preparing Setup” window in F igure 7-2 appears next. 8 9 5 H 8 9 7 H Figure 7-2: Preparing Setup Screen Step 4: The “Install Shield” window in F igure 7-3 appears next. To continue installing 8 9 6 H 8 9 8 H the AGP pack driver, click “N .”...

  • Page 178: Figure 7-3: Install Shield Screen

    KINO-6612 Mini-ITX Motherboard Figure 7-3: Install Shield Screen Step 5: The installation shield starts to extract and install files as shown in F igure 7-4. 8 9 7 H 8 9 9 H Page 160...

  • Page 179: Figure 7-4: Installing Screen

    KINO-6612 Mini-ITX Motherboard Figure 7-4: Installing Screen Step 6: Once the installation process is complete, the computer may be restarted now or in the future. (See F igure 7-19). Select the preferred option and click “F ” to INISH 8 9 8 H 9 0 0 H complete the installation process.

  • Page 180: Realtek Audio Driver Installation

    KINO-6612 Mini-ITX Motherboard Figure 7-5: Restart the Computer 7.3 RealTek Audio Driver Installation To install the RealTek AC’97 Audio driver, please follow the steps below: Step 1: Insert the CD into the system that contains the KINO-6612. Open the CD folder and locate the AUDIO DRIVER A3.79 directory.

  • Page 181: Figure 7-6: Audio Driver Install Shield Wizard Starting

    KINO-6612 Mini-ITX Motherboard Figure 7-6: Audio Driver Install Shield Wizard Starting Step 3: The RealTek Audio Setup prepares the install shield to guide a user through the rest of the setup process. See F igure 7-7. 9 0 0 H 9 0 2 H Figure 7-7: Audio Driver Setup Prerparation Step 4: After install shield is prepared, the welcome screen shown in...

  • Page 182: Figure 7-8: Audio Driver Welcome Screen

    KINO-6612 Mini-ITX Motherboard Figure 7-8: Audio Driver Welcome Screen Figure 7-9: Audio Driver Software Configuration Step 5: At this stage the “Digital Signal Not Found” screen shown in F igure 7-10 9 0 3 H 9 0 5 H Page 164...

  • Page 183: Figure 7-10: Audio Driver Digital Signal

    KINO-6612 Mini-ITX Motherboard appears. To continue the installation process, click the “Y ” button. The installation notice shown below appears. Figure 7-10: Audio Driver Digital Signal Step 6: At this stage the clicking the “Y ” button in F igure 7-10 appears, the installation 9 0 4 H 9 0 6 H of the driver begins.

  • Page 184: Figure 7-11: Audio Driver Installation Begins

    KINO-6612 Mini-ITX Motherboard Figure 7-11: Audio Driver Installation Begins Step 7: After the driver installation process is complete, a confirmation screen shown in F igure 7-12 appears 9 0 6 H 9 0 8 H Page 166...

  • Page 185: Sis Vga Utilities Driver

    KINO-6612 Mini-ITX Motherboard Figure 7-12: Audio Driver Installation Complete Step 8: The confirmation screen shown in F igure 7-12 allows the computer to be 9 0 7 H 9 0 9 H restarted immediately after the installation is complete or at a later time. For the settings to take effect the computer must be restarted.

  • Page 186: Figure 7-13: Vga Utilities Welcome Screen

    KINO-6612 Mini-ITX Motherboard appears. Figure 7-13: VGA Utilities Welcome Screen Step 3: Select the setup type (see F igure 7-14). Once the setup type is selected, click 9 0 9 H 9 1 1 H on the N button in the setup type menu (see F igure 7-14).

  • Page 187: Figure 7-14: Select Setup Installation Type

    KINO-6612 Mini-ITX Motherboard Figure 7-14: Select Setup Installation Type Step 4: Select a folder to copy the files in (see F igure 7-15). Once the setup type is 9 1 1 H 9 1 3 H selected, click on the N button.

  • Page 188: Figure 7-15: Select Folders To Copy Files

    KINO-6612 Mini-ITX Motherboard Figure 7-15: Select Folders to Copy Files Step 5: Before the files are copied, review the selected settings (see F igure 7-16). To 9 1 2 H 9 1 4 H continue, click the N button. Figure 7-16: Review Settings Step 6: The driver installation starts.

  • Page 189: Figure 7-17: Read Readme File

    KINO-6612 Mini-ITX Motherboard Step 7: Once the installation is complete, the user is prompted to read the Read Me file. (see F igure 7-17) 9 1 3 H 9 1 5 H Figure 7-17: Read ReadMe File Step 8: The user is prompted to restart the computer. Select yes or no. Page 171...

  • Page 190: Installation

    KINO-6612 Mini-ITX Motherboard Figure 7-18: Restart the Computer 7.5 SiS IDE Driver Installation To install the SiS IDE driver in the IDE R204a directory please follow the steps below: Step 9: Insert the CD into the system that contains the KINO-6612. Open the IDE R204a and locate the icon for the setup installation file.

  • Page 191: Figure 7-19: Select A Language

    KINO-6612 Mini-ITX Motherboard Figure 7-19: Select a Language Step 11: After a language is selected a welcome screen shown in F igure 7-20 appears. 9 1 5 H 9 1 7 H To continue the installation, click the “N ” button. Figure 7-20: Welcome Screen Step 12: Select an OS.

  • Page 192: Figure 7-21: Chipset Driver Readme File Information

    KINO-6612 Mini-ITX Motherboard Figure 7-21: Chipset Driver Readme File Information Step 13: Select an OS and click on the “N ” button to initiate driver installation. The installation screen shown in F igure 7-22 appears. 9 1 7 H 9 1 9 H Page 174...

  • Page 193: Installation

    KINO-6612 Mini-ITX Motherboard Figure 7-22: Chipset Driver Installation Complete Step 14: After the installation is complete the user is prompted to restart the computer now or later. Step 0: 7.6 LAN Driver Installation To install the LAN driver, please follow the steps below: Step 1: Insert the CD into the system that contains the KINO-6612driver.

  • Page 194: Figure 7-24: Lan Driver Installation Complete

    KINO-6612 Mini-ITX Motherboard Step 3: To continue installing click “Next.” The driver is installed and a confirmation screen at the end of the installation appears. (See F igure 7-24) Step 0: 9 1 9 H 9 2 1 H Figure 7-24: LAN Driver Installation Complete Page 176...

  • Page 195: Bios Menu Options

    KINO-6612 Mini-ITX Motherboard Appendix BIOS Menu Options Page 177...
  • Page 196 KINO-6612 Mini-ITX Motherboard System Overview ..................... 1 08 3 3 0 H 9 2 2 H System Time [xx:xx:xx]................... 1 09 3 3 1 H 9 2 3 H System Date [xx/xx/xx]..................1 09 3 3 2 H 9 2 4 H Intel (R) SpeedStep (tm) tech.
  • Page 197 KINO-6612 Mini-ITX Motherboard Serial Port5 Address [2E0] ................1 24 3 6 0 H 9 5 2 H Serial Port5 IRQ [11]..................1 25 3 6 1 H 9 5 3 H Serial Port6 Address [2D8] ................1 25 3 6 2 H 9 5 4 H Serial Port6 IRQ [10]..................
  • Page 198 KINO-6612 Mini-ITX Motherboard Change User Password .................. 1 45 3 9 2 H 9 8 4 H Primary Graphics Adapter [PCI] ..............1 47 3 9 3 H 9 8 5 H DRAM CAS# Latency [By SPD] ..............1 47 3 9 4 H 9 8 6 H Graphic Win Size [64MB] ................

  • Page 199: Bterminology

    KINO-6612 Mini-ITX Motherboard Appendix Terminology Page 181...
  • Page 200 KINO-6612 Mini-ITX Motherboard AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 201 KINO-6612 Mini-ITX Motherboard CMOS Complimentary metal-oxide-conductor is a type of integrated circuit used in chips like static RAM and microprocessors. COM is used to refer to serial ports. Serial ports offer serial communication to expansion devices. The serial port on a personal computer is usually a male DE-9 connector.
  • Page 202 KINO-6612 Mini-ITX Motherboard L2 Cache The Level 2 Cache (L2 Cache) is an external processor memory cache. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer. The Media Access Control (MAC) protocol enables several terminals or network nodes to communicate in a LAN, or other multipoint networks.
  • Page 203 KINO-6612 Mini-ITX Motherboard transfers between storage devices and the computer chipsets. The SATA bus has transfer speeds up to 1.5 Gbps and the SATA II bus has data transfer speeds of up to 3.0 Gbps. S.M.A.R.T Self Monitoring Analysis and Reporting Technology (S.M.A.R.T) refers to automatic status checking technology implemented on hard disk drives.

  • Page 204: Dio Interface

    KINO-6612 Mini-ITX Motherboard Appendix DIO Interface Page 186...

  • Page 205: Dio Interface Introduction

    KINO-6612 Mini-ITX Motherboard C.1 DIO Interface Introduction The DIO connector on the KINO-6612 is interfaced to GPIO ports on the Winbond W83697HG Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 206: Samples

    KINO-6612 Mini-ITX Motherboard C.3 Assembly Language Samples C.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. AX, 6F08H Sets the digital port as input Initiates the INT 15H BIOS call C.3.2 Enable the DIO Output Function The BIOS interrupt call INT 15H controls the digital I/O.

  • Page 207: Watchdog Timer

    KINO-6612 Mini-ITX Motherboard Appendix Watchdog Timer Page 189...
  • Page 208 KINO-6612 Mini-ITX Motherboard NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 209 KINO-6612 Mini-ITX Motherboard NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 210: Address Mapping

    KINO-6612 Mini-ITX Motherboard Appendix Address Mapping Page 192...

  • Page 211: Map

    KINO-6612 Mini-ITX Motherboard E.1 I/O Address Map Page 193...
  • Page 212 KINO-6612 Mini-ITX Motherboard Table E-1: IO Address Map Page 194...

  • Page 213: Map

    KINO-6612 Mini-ITX Motherboard E.2 IRQ Address Map Table E-2: IRQ Address Map Page 195...

  • Page 214: Map

    KINO-6612 Mini-ITX Motherboard E.3 Memory Address Map Table E-3: IRQ Address Map Page 196...

  • Page 215: Compatibility

    KINO-6612 Mini-ITX Motherboard Appendix Compatibility Page 197...

  • Page 216: Compatible Operating Systems

    KINO-6612 Mini-ITX Motherboard NOTE: The compatible items described here have been tested by the IEI R&D team and found to be compatible with the KINO-6612 F.1 Compatible Operating Systems The following operating systems have been successfully run on the KINO-6612. MS-DOS 6.22 Microsoft Windows Server 2003 (32-bit) Microsoft Windows Server 2003 (64-bit)

  • Page 217: Modules

    KINO-6612 Mini-ITX Motherboard AMD Athlon™ 64 X2 Dual-Core 4800+ 2.4 GHz 1 MB AMD Athlon™ 64 X2 Dual-Core 4200+ 2.1 GHz 1 MB AMD Athlon™ 64 X2 Dual-Core 3400+ 1.8 GHz 1 MB AMD Athlon™ 64 3500+ 2.2 GHz 512 KB AMD Athlon™...

  • Page 218: Hazardous Materials Disclosure

    KINO-6612 Mini-ITX Motherboard Appendix Hazardous Materials Disclosure Page 200...

  • Page 219: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    KINO-6612 Mini-ITX Motherboard G.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 220 KINO-6612 Mini-ITX Motherboard Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Hg) (Cd) Chromium (Pb) Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery O: This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below...
  • Page 221 KINO-6612 Mini-ITX Motherboard 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 203...

  • Page 222: Index

    KINO-6612 Mini-ITX Motherboard Index Page 204...
  • Page 223 KINO-6612 Mini-ITX Motherboard BIOS chipset ACPI 127, 128 Advanced Power Management cables 147, 148, 158, 159 ATA flat cable airflow dual port USB anti-static precautions 35, 75 dual RS-232 cable anti-static pad 35, 75 SATA drive anti-static wristband 35, 75 SATA drive power handling 35, 75...
  • Page 224 KINO-6612 Mini-ITX Motherboard USB port board connectors, pinouts and location external peripheral interface connector ATX power panel backlight inverter DIMM COM 2 serial port 61, 62 installation specifcations GPIO DIO Interface 50, 52 dual port USB cable infrared interface LVDS LCD (30-pin) PCI slot electrostatic discharge 35, 75...
  • Page 225 KINO-6612 Mini-ITX Motherboard LCD voltage setup RS-232/422/485 COM2 setup GPIO jumper GPIO connector 4, 49 clear CMOS location and pinouts clear CMOS CPU Frequency Setup FSB Setup jumper configuration hard disk drives jumper settings SATA LCD voltage selection HDD LED RS-232/485 serial port select heat sink keyboard connector...
  • Page 226 KINO-6612 Mini-ITX Motherboard LVDS panel 18-bit RAID 36-bit RealTek Audio Driver dual channel reset button single channel RJ-45 connection single connector RJ-45 connector memory module installation RJ-45 connector motherboard RJ-45 Ethernet connector installation RJ-45 LAN connector mouse connector RS-232 61, 62, 63, 70, 94 cable connection COM 1 location and pinouts COM 2 location and pinouts...

  • Page 227: T Able 1-2: Technical Specifications

    KINO-6612 Mini-ITX Motherboard SATA drive unpacking precautions cables 64, 65, 66, 95, 130, 131, 132 connection cable power cable dual port SATA drive connector 5, 59 cable location and pinouts cable connection SATA drives connectors Serial Device devices connection external USB device connection serial port port serial port connector...

Table of Contents
