Power
12V DC
100-240V AC, 50-60Hz adapter
DC+12V
Antenna
Connection
(SMA)
Console (RJ-45)
Optional connection to the management computer
Provides access to the CLI
CONSOLE
Internet
WAN
4
Ethernet Ports 1 - 4 (RJ-45)
Gigabit Ethernet ports for local
network connection
WAN Port (RJ-45)
Gigabit Ethernet port for Internet connection
Antenna
Connection
(SMA)
3
2
1
