Black Stone 1620 Owner's Manual

Grill+kabob
Hide thumbs

Advertisement

Quick Links

Owner's Manual
Grill + Kabob
VIDEO ASSEMBLY
www.blackstoneproducts.com/kabob
North Atlantic Imports LLC | 513 West 2500 North, North Logan UT 84341 | www.blackstoneproducts.com
FOR OUTDOOR USE ONLY
Please read manual carefully before assembly
Retain this manual for future reference
MODEL #1620

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Stone 1620

Summary of Contents for Black Stone 1620

  • Page 1 MODEL #1620 Owner’s Manual Grill + Kabob FOR OUTDOOR USE ONLY VIDEO ASSEMBLY Please read manual carefully before assembly Retain this manual for future reference www.blackstoneproducts.com/kabob North Atlantic Imports LLC | 513 West 2500 North, North Logan UT 84341 | www.blackstoneproducts.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY SYMBOLS The symbols and boxes shown below explain what each heading means. Read and follow all of the messages found throughout the manual. Product Registration ......2 DANGER For Your Safety .......3 Parts List ........4 DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 3: For Your Safety

    FOR YOUR SAFETY • DO NOT use this product in a manner other than its This instruction manual contains important information intended purpose. It is NOT intended for commercial necessary for the proper assembly and safe use of this use. It is not intended to be installed or used in or on a appliance.

  • Page 4: Parts List

    PARTS LIST Logo Plate (1 pc.) M4 Screw (2 pcs.) M4 Nut (4 pcs.) M5x10 Screw (6 pcs.) M5x12 Screw (2 pcs.) M5 Nut (4 pcs.) M6x12 Screw (4 pcs.) M6x20 Screw (2 pcs.) M6x38 Bolt (4 pcs.) M6x62 Bolt (8 pcs.) M6 Flange Nut (16 pcs.) M8 Screw (4 pcs.) Lid (1 pc.)
  • Page 5 PARTS LIST Short Thumbscrew (2 pcs.) Short Hitch Pin (4 pcs.) Charcoal Tray (1 pc.) Charcoal Tray Bracket (2 pcs.) Charcoal Door Knob with door Air Vent (2 pcs.) catch, ST3.9 Screw, and mica plate thermal shield (1 pc.) Leg Frame (1 pc.) Leg Frame with Wheels (1 pc.) Side Shelf (1 pc.) Crank Handle Collar (1 pc.)

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS WARNING VIDEO ASSEMBLY Watch an actual BLACKSTONE Grill+Kabob The manufacturer has made every effort to eliminate assembly. Use a QR Code any sharp edges. However, you should handle all App and scan the QR code. components with care to avoid accidental injury. Please read all instructions thoroughly before proceeding.
  • Page 7 STEP 3 STEP 5 Use (4) M6x38 bolts and (4) M6 flange nuts to attach Turn the grill upright. Use (4) M6x62 bolts and (4) M6 flange the legs to the main body. Use (2) M5 screws through nuts to attach the other leg support to the back of the legs. the front of the main body to secure the legs.
  • Page 8 STEP 7 STEP 9 Use (4) short hitch pins and (4) cotter pins to attach the Use the ST3.9 screw to attach the charcoal door knob to charcoal tray brackets. the charcoal door. Make sure the door catch and mica plate are on the inside of the door and the knob is on the outside.
  • Page 9 STEP 11 STEP 13 Install the thermometer. Use (2) M5 nuts and install the logo plate. M5 Nut STEP 14 STEP 12 Use the handle spacers and M8 screws to install the handles on the lid and side of the grill. Use (2) M5x10 screws and (2) M5 nuts to install the chimney.
  • Page 10 STEP 15 STEP 17 Use (2) short thumbscrews to attach the side tray. Install the crank handle. Remove the retention screw at the end of the crank handle before installation. One the crank handle is installed into the crank handle collar, replace the retention screw.
  • Page 11 STEP 19 STEP 21 Install the gear drive with (2) M6x20 screws. Install the grill grates, the skewers, or a combination of both. Grill Grates M6x20 Skewers STEP 20 Install the motor on the gear drive.

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS SEASONING UNIT DANGER Before your first cooking you should season the unit to enhance the cooking and to provide better overall durability. Failure to properly follow these steps may CARBON MONOXIDE HAZARD. Burning charcoal damage the finish and/or impart metallic flavors to inside can kill you.

  • Page 13: Customer Service

    OPERATING INSTRUCTIONS GRILLING WARNING Charcoal is recommended, however wood or a combination of both may be used as the fuel source for grilling if the fuel source is placed and ignited on the Most surfaces on this unit are hot when in use. •...

  • Page 14: Grill Warranty

    WARRANTY North Atlantic Imports LLC, the warranty, read below: 90 Day & Limited Warranty North Atlantic Imports LLC warrants to the owner that the product covered by this agreement is free from defects in material and North Atlantic Imports LLC, the manufacturer of workmanship under normal use and service for which it was intended BLACKSTONE Products, will warranty for 90 days from if, but only if, it has been operated in accordance with North Atlantic...
