VDH-NK380
Hardware Manual
2015 JUL V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDH-NK380 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vacron VDH-NK380

  • Page 1 VDH-NK380 Hardware Manual 2015 JUL V1.2...
  • Page 2: Table Of Contents

    VDH-NK380 Hardware Manual Contents CAUTION .............................. 1 Introduction ............................2 1. Product Overview ........................2 2. Main functions ........................... 2 Unpacking ............................3 1. Accessories ..........................3 2. Unpacking ........................... 3 Installation ............................3 Product appearance ......................... 4 1. Front Panel ..........................4 2.
  • Page 3: Caution

    VDH-NK380 Hardware Manual A. CAUTION To our dear customers! Thank you for using our products. If you encounter any problems when using, please do not hesitate to contact our resellers. We will provide excellent services to you via our resellers.
  • Page 4: Introduction

    VDH-NK380 Hardware Manual B. Introduction Product Overview This equipment is an excellent digital surveillance product designed specifically for the security use. Using embedded LINUX operating system, it makes the system more stable. Using standard H.264 video compression and G.711A audio compression technology achieves audio and video functions such as high-quality, low bit rate and single-frame playback.
  • Page 5: Unpacking

    VDH-NK380 Hardware Manual C. Unpacking Accessories ★ Power cable and adaptor AC100-240V/DC12V 4.16A x 1PCS ★ HDD screws x 8pcs ★ Operation CD x 1pcs ★ Mouse Unpacking When you receive the product, check first whether the packing of the equipment has obvious damage.
  • Page 6: Product Appearance

    VDH-NK380 Hardware Manual E. Product appearance Front Panel Under the live viewing mode, press MENU to enter the MENU MENU main menu. Exit the current menu. Under the live mode, press the REC button to enter recording menu. STOP Stop the playback under the playback mode.
  • Page 7: Rear Panel

    VDH-NK380 Hardware Manual Preview CH1/5 Preview CH1/CH5. Press this button to switch CH1/CH5. Preview CH2/6 Preview CH2/CH6. Press this button to switch CH2/CH6. Preview CH3/7 Preview CH3/CH7. Press this button to switch CH3/CH7. Preview CH4/8 Preview CH4/CH8. Press this button to switch CH4/CH8.
  • Page 8: Installation Illustration

    VDH-NK380 Hardware Manual Installation Illustration Video input  Input interface is RJ-45 type; input signal is IP CAM The Video signal should comply with national standards, a higher signal to noise ratio, low distortion, low-interference; clear images, no deformation, nature color and appropriate brightness.
  • Page 9: Audio Output

    VDH-NK380 Hardware Manual Do not remain switched on for a long time to extend the life of the equipment; Regular degaussing will help to maintain the normal operation of the monitor. Keep away from equipment with strong electromagnetic interference. Using TV as video output device is an unreliable alternative. It is also required to minimize the time of use and strictly control the power, the interference caused by neighboring devices.
  • Page 10: Q & A And Maintenance

    VDH-NK380 Hardware Manual F. Q & A and Maintenance 1. Q & A Q 1. After power on, NVR doesn’t work. A: The possible causes: 1. Wrong power input 2. bad connection of power cable 3. Power error 4. Firmware update error 5.
  • Page 11 VDH-NK380 Hardware Manual Q 6. No recorded file in local side A : The possible causes: 1. Wrong data cable or jumper error in the hard disk 2. Hard Disk error 3. Upgraded firmware cannot recognize the existing file system 4.
  • Page 12 VDH-NK380 Hardware Manual 1. Operating system is Win98 or Win Me and the client software cannot be installed or displayed normally; Upgrade the operating system to Win2000sp4 or above, or use lower versions of the client software. 2. ActiveX control blocked; install the ActiveX control in the attached CD.
  • Page 13: Maintenance

    VDH-NK380 Hardware Manual 4. Wrong firmware problem; Upgrade firmware to fix it. Q 18. Alarms do not work A : The possible causes: 1. Wrong alarm setting 2. Wrong alarm wiring 3. Wrong AlarmIn signal 4. One alarm equipment involves into two loops.
  • Page 14 VDH-NK380 Hardware Manual Do not remove audio/video cables when the NVR is powered on, or they  will be damaged. Do not use the TV interface in the NVR video output (VOUT), or the NVR  output circuit will be damaged easily.
  • Page 15: Appendix : Specifications

    VDH-NK380 Hardware Manual G. Appendix : Specifications 16CH NVR System Operating system:Linux Storage Build in SATA interface x 2, compatible SATA / SATA II / SATA III HDD( Max. 8TB) Device/Interface E-SATA x 1(Max. 16T) User Interface 17 operating buttons on Front panel controller Video And Other Dual video:HD OUT/VGA...
  • Page 16 VDH-NK380 Hardware Manual Authorization: Maximum 10 group accounts, Hierarchical authority. Support 3 users log on by Client-side software or browser. Systems operation records, record login time, IP and selected video. Browser: MS IE7-IE9 Support Equipment Support megapixel IP Camera video Support CCTV camera video via Video Server.
  • Page 17 Manufacturer : FUHO TECHOLOGY CO., LTD. No. 30 Lane 726 Sec. 3 Jinma Rd., Changhua City Phone: 886-4-751-2881 Fax: 886-4-751-6631...
