1
)
Set
CONTROLS
and
SWITCHES.
1)
Set the
CONTROLS
and
SWITCHES
as stated in
SECTION
6
-
1
SETTINGS.
Other
controls are unrelated to operation
in
this
mode.
2)
Push IN
POWER
SWITCH.
2)
Push IN the
POWER
SWITCH.
The meter lamp
lights,
and
shortly thereafter,
the display lights
and
indicates
the
frequency and
HAM/GENERAL
mode which
are
stored
in
the
VFO A
memory. The
memory
channel
number
"01"
also
lights.
/ t
USB
j
j
1
n n
1 1.
L
/
u.
u
LI
1
VFO A
3) Select
GENERAL COVERAGE
mode
by
pushing
HAM/GENE
SWITCH.
AM
1 1 c
:/
n n n
1 1.
c
1
u
u.
u
U
1
VFO «
"GENE"
lights.
3)
If
the transceiver
does not- display
"GENE",
push
the
HAM/
GENE
SWITCH. The
GENERAL COVERAGE
mode
is
now
selected.
When
the
HAM BAND
mode
is
selected,
the
"GENE"
indicator
goes out.
NOTE:
In
the
HAM BAND
mode,
the
letters
"GENE"
do
not
light,
4)
Push desired
MODE
SWITCH.
4)
Push
the desired
MODE
SWITCH. When
the
SSB
mode
is
chosen,
USB
is
automatically selected
on
the
10MHz
band and above,
and
LSB
is
selected
on
the
9MHz
band and below.
Note, however, once either
USB
or
LSB
mode
is
automatically
selected, this
mode
is
maintained regardless of
frequency or
band
changes.
To
change to the opposite sideband,
push
the
FUNC-
TION
SWITCH,
then the
SSB
SWITCH
again.
5)
Select desired
band and frequency.
5)
Push the
BAND
SELECT SWITCH,
then use the
TUNING
CON-
TROL
to select
the desired
band
of operation.
Push and
release
the
BAND
SELECT SWITCH
again,
and tune the
TUNING
CONTROL
until a signal
is
located.
6)
Adjust
AF GAIN CONTROL.
6)
Adjust the
AF GAIN
CONTROL
for
a
comfortable audio
level.
The multifunction
meter
indicates
the
signal
strength
of the
received signal,
therefore
tune
for
the highest reading
on
the
meter with the
clearest
audio.
Jiumbui AM HBM cwBQS ssbBQrttyIS^
O
a
HAM/GENE SPEECH MODE-S
SCAN
—
a
n
la
Refer to
SECTIONS
6
-
3 to 6
-
7 for further
information
on each
mode.
-31 -
