Makita HR2631F Instruction Manual
Combination hammer
Hide thumbs
Also See for HR2631F:
- Instruction manual (88 pages) ,
- Instruction manual (76 pages) ,
- Instruction manual (68 pages)
Related Manuals for Makita HR2631F
Summary of Contents for Makita HR2631F
- Page 1 INSTRUCTION MANUAL Combination Hammer HR2631F HR2631FT HR2641 HR2320T HR2630 HR2630T 015335 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model HR2631F HR2631FT HR2641 HR2320T HR2630 HR2630T Concrete 26 mm 23 mm 26 mm Core bit 68 mm Capacities Diamond core bit (dry type) 80 mm 70 mm 80 mm Steel 13 mm Wood 32 mm... - Page 3 Avoid body contact with earthed or grounded 17. If devices are provided for the connection of surfaces such as pipes, radiators, ranges and dust extraction collection facilities, refrigerators. There is an increased risk of ensure these are connected and properly electric shock if your body is earthed or grounded.
-
