IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive
Installation and User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultrium Gen 6 and is the answer not in the manual?

Questions and answers

Related Manuals for IBM Ultrium Gen 6

Summary of Contents for IBM Ultrium Gen 6

  • Page 1 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive Installation and User's Guide...
  • Page 3 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive Installation and User's Guide...
  • Page 4 Note: Before using this information and the product it supports, read the general information in “Notices” on page 77 and the IBM Safety Information, and IBM Environmental Notices and User's Guide on the IBM Documentation CD, and the IBM Warranty Information document that comes with the system.

  • Page 5: Table Of Contents

    . 17 Resolving problems reported by the server . . 55 Status lights . . 18 Resolving problems with the tape media . 55 Unload button . . 21 Replacing the tape drive . . 56 © Copyright IBM Corp. 2013...
  • Page 6 Important notes . . 78 Index ....95 Particulate contamination. . 79 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 7: Figures

    . 71 Tape drive diagnostic page . . 41 Leader Pin Reattachment Kit . . 72 The IBM LTO Ultrium Data Cartridge. . 43 Attaching the leader pin attach tool to the Ultrium data cartridge on the left; WORM cartridge .
  • Page 8 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 9: Tables

    CRU and Option part numbers . . 56 Meaning of status lights and single-character Error codes on the SCD . 63 display (SCD) . . 19 Limits for particulates and gases . 79 Functions that the Unload button performs © Copyright IBM Corp. 2013...
  • Page 10 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 11: Safety

    Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information. Avant d'installer ce produit, lisez les consignes de sécurité. Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. © Copyright IBM Corp. 2013...

  • Page 12: Guidelines For Trained Service Technicians

    If you identify IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 13: Guidelines For Servicing Electrical Equipment

    Make sure that the insulation is not frayed or worn. 4. Remove the cover. 5. Check for any obvious non-IBM alterations. Use good judgment as to the safety of any non-IBM alterations. 6. Check inside the system for any obvious unsafe conditions, such as metal filings, contamination, water or other liquid, or signs of fire or smoke damage.

  • Page 14: Safety Statements

    Be sure to read all caution and danger statements in this documentation before you perform the procedures. Read any additional safety information that comes with your system or optional device before you install the device. Statement 1 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 15 DANGER Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: v Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. v Connect all power cords to a properly wired and grounded electrical outlet. v Connect to properly wired outlets any equipment that will be attached to this product.
  • Page 16 To remove all electrical current from the device, ensure that all power cords are disconnected from the power source. Statement 8 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 17 CAUTION: Never remove the cover on a power supply or any part that has the following label attached. Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components.
  • Page 18 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 19: Chapter 1. Introduction

    Chapter 1. Introduction The product description of the IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive. The IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive is a high-performance, high-capacity data-storage device that is designed to back up and restore open systems applications.

  • Page 20: Front Panel Of The Drive

    Rear panel of the drive The tape drive rear panel's elements descriptions. SAS and power cable connector Figure 3. Tape drive rear panel element descriptions IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 21: Drive Performance

    Ultrium 1 Read/Write Note: The IBM Half High LTO Ultrium 6 Tape Drive reads and writes Ultrium 6 cartridges to Ultrium 6 format and also reads and writes Ultrium 5 cartridges to Ultrium 5 format, including WORM and Data Encryption.

  • Page 22: Speed Matching

    A backhitch is usually the result of a mismatch between the data rates of the server and the drive. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 23: Channel Calibration

    , Windows Server, Linux and Solaris. Encryption requires the latest device drivers available on the IBM website: http://www.ibm.com/support/fixcentral. For more information, see the IBM Tape Device Drivers Encryption Support and IBM LTO Ultrium Tape Drive SCSI Reference documentation. Inhibit firmware down-leveling...

  • Page 24: Supported Servers And Operating Systems

    Ethernet port The IBM LTO 6 Half High Tape Drive has a single 1 Gbps Ethernet port on the rear panel, with a RJ45 connector. The default IP address is 169.254.0.3, but the drive’s IP address can be changed as needed.
  • Page 25 the host operating system’s graphical file manager, reading data on a LTO tape cartridge is as easy as dragging and dropping. Users can run any application designed for disk files against tape data without concern for the fact that the data is physically stored on tape.
  • Page 26 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 27: Chapter 2. Tape Drive Installation

    To avoid static electricity damage when handling the drive, use the following precautions. v Limit your movement. Movement can cause static electricity to build around you. v Always handle the drive carefully. Never touch exposed circuitry. v Prevent others from touching the drive. © Copyright IBM Corp. 2013...

  • Page 28: Inventory Checklist

    Unpack the drive and store the packaging for future moves or shipping. Attention: If you return the unit for service, ship it in its original or equivalent packing material, or the warranty may be invalidated. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 29: Acclimating The Drive And Media

    Acclimating the drive and media Acclimation time is required if the temperature of the drive and media when unpacked is different than the temperature of its operating environment (measured at the front of the bezel near the air intake area). The recommended acclimation time is four hours after the drive has been unpacked or one hour after any condensation that you can see has evaporated, whichever is greater.

  • Page 30: Mounting The Drive In An Enclosure Or Server

    4. Connect the power cord to the enclosure (or unit that supplies power to the drive) and to the electrical outlet. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 31: Connecting The Cable

    5. Review the location of the single-character display (SCD) and the status LED in “Front panel of the drive” on page 2. To make sure that the drive is receiving power, watch for the following while turning on the power to the enclosure or server: v During the power-on/initialization and POST (Power-On Self Test), the SCD briefly displays...

  • Page 32: Connecting The External Interface Cable (Enclosure Or Server Installations Only)

    Enter. 3. In the list of search results, click the link Tape Files (index) - Software for tape drives and libraries. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 33: Registering For My Support

    Use this information to register for My Support. My Support registration provides e-mail notification when new firmware levels have been updated and are available for download and installation. To register for My Support, visit the web at http://www.ibm.com/support/mySupport. Chapter 2. Installation...
  • Page 34 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 35: Chapter 3. Operating The Drive

    This section describes the SCD in the front panel of the drive. The SCD (see “Front panel of the drive” on page 2) presents a single-character code for: v Error conditions and informational messages v Diagnostic or maintenance functions (while in Maintenance mode only) © Copyright IBM Corp. 2013...

  • Page 36: Status Lights

    Table 6 on page 19 lists the conditions of the status lights and Single-character display (SCD) and provides an explanation of what each condition means. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 37: Meaning Of Status Lights And Single-Character Display (Scd)

    Table 6. Meaning of status lights and single-character display (SCD) Ready Fault status Encryption SCD dot Meaning status light light status light The drive has no power or is powered off. Green and On or off The drive is powered on and in an idle solid state.
  • Page 38 The drive is ready for a cartridge to be Flashing solid loaded. Flashing There is a drive dump in flash memory. amber (twice per second) IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 39: Unload Button

    Table 6. Meaning of status lights and single-character display (SCD) (continued) Ready Fault status Encryption SCD dot Meaning status light light status light Power should not be disconnected from the drive until the microcode update is complete. The drive indicates that the update is complete by resetting and performing POST.

  • Page 40: Inserting A Tape Cartridge

    Do not attempt to load a cartridge when the drive is in Maintenance mode until the drive requests it. Figure 4. Inserting a cartridge into the drive IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 41: Removing A Tape Cartridge

    Removing a tape cartridge Use this information to remove a tape cartridge. Attention: To clean the tape drive, use only an IBM LTO Ultrium Cleaning Cartridge. The use of cleaning methods other than an LTO cleaning cartridge might cause damage to the drive.

  • Page 42: Cleaning The Tape Drive

    The web page is divided into sections by topic. The topics are: v Drive Information v Host Information v Ethernet Settings v VPD Encryption Settings v Drive Statistics IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 43: Diagnostic And Maintenance Functions

    v Tape Statistics (if a cartridge is loaded in the tape drive) v Engineering Error Log Click in the box by the title of the section to see the topic details. Figure 6. Drive status web page - Topic details The web page format can be changed to text mode by selecting the “Text Only version”...

  • Page 44: Diagnostic And Maintenance Functions

    Clear Error Code Log: Erases the contents of the “Function code A: Clear error code error code log. log” on page 34 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 45: Entering Maintenance Mode

    Table 8. Diagnostic and maintenance functions (continued) Function code Diagnostic or maintenance function Instructions location Insert Cartridge into Tape Drive: This function “Function code C: Insert cartridge into cannot be selected by itself, but is a part of other tape drive” on page 35 maintenance functions (such as Run Tape Drive Diagnostics and Create FMR Tape) that require a tape cartridge to be loaded.

  • Page 46: Function Code 0: Maintenance Mode

    SCD. In either case, the tape drive unloads the cartridge and exits Maintenance mode after the cartridge is removed. To execute Function code 1: Run drive diagnostics, complete the following steps: IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 47: Function Code 2: Update Drive Firmware From Fmr Tape

    1. Put the drive in Maintenance mode. For instructions, see “Entering Maintenance mode” on page 27. 2. Press the Unload button once per second until appears in the SCD. (If you cycle past the desired code, press the Unload button once per second until the code reappears.) 3.

  • Page 48: Function Code 3: Create Fmr Tape

    2. Press the Unload button once per second until appears in the SCD. (If you cycle past the desired code, press the Unload button once per second until the code reappears.) IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 49: Function Code 5: Copy Drive Dump

    3. Press and hold the Unload button for 3 or more seconds, then release it to select the function. The drive performs the dump. The SCD shows , then goes blank, and the drive exits Maintenance mode. To access the contents of the dump, see “Function code 5: Copy drive dump.”...

  • Page 50: Function Code 6: Run Host Interface Wrap Test

    Unload button for one second and release. When the diagnostic ends, temporarily appears in the SCD, and the tape drive exits Maintenance mode. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 51: Function Code 7: Run Rs-422 Wrap Test

    v If an error is detected, the Fault light flashes and the drive posts an error code to the SCD. To determine the error, locate the code in Appendix C, “Error codes and messages,” on page 63. To clear the error either turn the power off and then on again, or reboot the drive by pressing and holding the Unload button for 10 seconds.

  • Page 52: Function Code 9: Display Error Code Log

    To execute Function code A: Clear error code log, complete the following steps: 1. Put the drive in Maintenance mode. For instructions, see “Entering Maintenance mode” on page 27. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 53: Function Code C: Insert Cartridge Into Tape Drive

    2. Press the Unload button once per second until appears in the SCD. (If you cycle past the desired code, press the Unload button once per second until the code reappears.) 3. Press and hold the Unload button for 3 or more seconds, then release it to select the function.

  • Page 54: Function Code F: Write Performance Test

    “Error codes and messages,” on page 63. To clear the error either turn the power off and then on again, or reboot the drive by pressing and holding the Unload button for 10 seconds. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 55: Function Code H: Test Head

    Function code H: Test head Approximate Run Time = 10 minutes per loop Total Number of Loops = 10 Function code performs tests to make sure that the tape drive head and tape-carriage mechanics work correctly. Once you begin this test, the diagnostic begins the loop sequence. Time the first loop by pressing the Unload button once to stop the diagnostic after the completion of the first loop, then record the time it takes for the test to complete.

  • Page 56: Function Code J: Fast Read/Write Test

    Unload button for one second and release. When the diagnostic ends, temporarily appears in the SCD, and the tape drive exits Maintenance mode. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 57: Function Code L: Load/Unload Test

    v If an error is detected, the Fault light flashes and the drive posts an error code to the SCD. To determine the error, locate the code in Appendix C, “Error codes and messages,” on page 63. To clear the error either turn the power off and then on again, or reboot the drive by pressing and holding the Unload button for 10 seconds.

  • Page 58: Function Code U: Disable Post Error Reporting

    Unload button on the drive’s front panel. Refer to the “Diagnostic and maintenance functions” on page 25 section in this User’s Guide for information about these maintenance functions. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 59: Tape Drive Diagnostic Page

    1. Connect the host computer or a laptop to the tape drive’s Ethernet port (RJ45 connector) using an Ethernet patch cable. 2. Using a web browser, connect to http://169.254.0.3/service.html to access the tape drive maintenance function menu on an HTML web page. Note: If the drive’s IP address has been changed, use that address instead.
  • Page 60 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 61: Chapter 4. Using Ultrium Media

    Chapter 4. Using Ultrium media Use this information for the usage of Ultrium media. To make sure that your IBM Ultrium Tape Drive conforms to IBM's specifications for reliability, use only IBM LTO Ultrium tape cartridges. You may use other LTO-certified data cartridges, but they may not meet the standards of reliability that are established by IBM.

  • Page 62: Types Of Cartridges

    WRITE command is issued, enables the drive to quickly locate the recording area and begin recording. The LTO-CM also aids in IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 63: Worm (Write Once, Read Many) Cartridge

    To control the capacity of the cartridge (for example, to obtain a faster seek time) issue the SCSI command SET CAPACITY. For information about this command, refer to the IBM TotalStorage LTO Ultrium Tape DriveSCSI Reference in the IBM Support portal.

  • Page 64: Ultrium Data Cartridge On The Left; Worm

    Ultrium 5 1,500 GB WORM tape cartridges or Ultrium 6 2500 GB WORM tape cartridges. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 65: Cleaning Cartridge

    SCD will be blank. Note: The drive will automatically eject an expired cleaning cartridge. IBM cleaning cartridges are valid for 50 uses. The cartridge LTO-CM chip tracks the number of times that the cartridge is used. Important: After 50 uses, the cleaning cartridge expires. It is no longer usable, and must be replaced.

  • Page 66: Provide Training

    Do not drop the cartridge. If the cartridge is dropped, slide the cartridge door back and make sure that the leader pin is properly seated in the pin-retaining IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 67: Tape Cartridge Packaging

    spring clips (see“Repositioning a leader pin” on page 69). If the leader pin has become dislodged, see Appendix D, “Repairing a cartridge,” on page 69. v Do not handle tape that is outside the cartridge. Handling the tape can damage the tape surface or edges, which might interfere with read or write reliability.

  • Page 68: Environmental And Shipping Specifications For Tape Cartridges

    Table 10 gives the environment for operating, storing, and shipping LTO Ultrium Tape Cartridges. Table 10. Environment for operating, storing, and shipping LTO media Environmental specifications Environmental factor Operating Operational storage Archival storage Shipping IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 69: Disposing Of Tape Cartridges

    Table 10. Environment for operating, storing, and shipping LTO media (continued) 10 to 45°C (50 to 16 to 32°C (61 to 16 to 25°C (61 to -23 to 49°C (-9 to Temperature 113°F) 90°F) 77°F) 120°F) Relative humidity 10 to 80% 20 to 80% 20 to 50% 5 to 80%...
  • Page 70 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 71: Chapter 5. Resolving Problems

    For explanations of codes on the Single-character Display (SCD), see “Single-character display (SCD)” on page 17. See Appendix A, Getting help and technical assistance before you call IBM Technical Support. Figure 12. Flowchart for analyzing maintenance problems Procedure 1: Inspecting a cartridge for damage Use this information to inspect a cartridge for damage.

  • Page 72: Procedure 2: Checking Sas Host Connections

    SAS interface bus from the host to the drive and back. A utility to perform this test is the IBM TotalStorage Tape Diagnostic Tool (ITDT). ITDT is available on the IBM website at http://www.ibm.com/storage/lto. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 73: Resolving Problems Reported By The Server

    1. If the ITDT utility is not installed on your server, download the applicable version for your operating system from the IBM website into a directory on your server. 2. When installation is complete, run the SCAN (s) option to determine if your server can detect all of the Ultrium tape drive devices (including any libraries or autoloaders that might be on the bus).

  • Page 74: Replacing The Tape Drive

    Use this information to replace the tape drive. The drive is a Tier 1 customer replaceable unit (CRU). Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for the installation.

  • Page 75: Appendix A. Getting Help And Technical Assistance

    Appendix A. Getting help and technical assistance If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you. Use this information to obtain additional information about IBM and IBM products, determine what to do if you experience a problem with your IBM system or optional device, and determine whom to call for service, if it is necessary.

  • Page 76: Using The Documentation

    Wide Web. On the World Wide Web, up-to-date information about IBM systems, optional devices, services, and support is available at . IBM System x information is at . IBM BladeCenter information is at . IBM IntelliStation information is at .

  • Page 77: Hardware Service And Support

    You can receive hardware service through your IBM reseller or IBM Services. To locate a reseller authorized by IBM to provide warranty service, go to and click Find Business Partners on the right side of the page. For IBM support telephone numbers, see .
  • Page 78 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 79: Appendix B. Tapealert Flags

    The server reads the flags from Log Sense Page 0x2E. See the IBM LTO Ultrium Tape Drive SCSI Reference document for the list of TapeAlert flags that are supported by this tape drive. To download the IBM LTO Ultrium Tape Drive SCSI Reference document (PDF), go to http://www-01.ibm.com/support/docview.wss?uid=ssg1S7001045&aid=1.
  • Page 80 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 81: Appendix C. Error Codes And Messages

    4. If the proper voltages are being applied, turn off and turn on the tape drive power to see if the problem repeats. 5. Replace the tape drive if the problem persists. The error code clears when you place the tape drive in Maintenance mode. © Copyright IBM Corp. 2013...

  • Page 82: Error Codes On The Scd

    3. If the problem persists, download new firmware and retry the operation. 4. If the problem persists, send the drive dump that you collected in step 1 to IBM Support. The error code clears when you place the tape drive in Maintenance mode.
  • Page 83 Table 12. Error codes on the SCD (continued) Error code Cause and action For Problems with Writing Data: If the problem occurred while the tape drive was writing data to the tape, retry the operation with a different cartridge: v If the operation succeeds, the original cartridge was defective. Copy the data from the defective cartridge and discard it according to the security policy for your organization.
  • Page 84 RS-422 connection. See “Function code 7: Run RS-422 wrap test” on page 33 or see the Library procedures to isolate the problem to the drive. The error code clears when you place the tape drive in Maintenance mode. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 85 Table 12. Error codes on the SCD (continued) Error code Cause and action Degraded operation. The tape drive determined that a problem occurred which degraded the operation of the tape drive, but it did not restrict continued use. If the problem persists, determine whether the problem is with the drive or the media.
  • Page 86 The error code clears when you remove the tape cartridge or place the tape drive in Maintenance mode. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 87: Appendix D. Repairing A Cartridge

    If the leader pin in your cartridge becomes dislodged from its pin-retaining spring clips or detaches from the tape, you must use the IBM Leader Pin Reattachment Kit (part number 08L9129) to reposition or reattach it. Important: Do not reattach the pin if you must remove more than 7 m (23 ft) of leader tape.

  • Page 88: Leader Pin In The Incorrect And Correct

    5. Make sure that there are no gaps in the seam of the cartridge Figure 14. Placing the dislodged leader pin into the correct position IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 89: Reattaching A Leader Pin

    To rewind the tape, see “Repositioning a leader pin” on page 69 and perform the steps below. 1. Insert the cartridge manual rewind tool into the cartridge hub and turn it clockwise until the tape becomes taut. 2. Remove the rewind tool by pulling it away from the cartridge. 3.

  • Page 90: Leader Pin Reattachment Kit

    A device that fits into the cartridge hub and lets you wind the tape into and out of the cartridge. Leader pins Extra leader pins are included. C-clips Extra C-clips are included. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 91: Attaching The Leader Pin Attach Tool To The Cartridge

    To reattach a leader pin by using the IBM Leader Pin Reattachment Kit, see Figure 17 and perform the steps below. 1. Attach the leader pin attach tool to the cartridge so that the hook latches into the cartridge door.

  • Page 92: Winding The Tape Out Of The Cartridge

    2. Remove the C-clip from the leader pin by using your fingers to push the clip away from the pin. Set the pin aside and discard the clip. Figure 19. Removing the C-clip from the leader pin IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 93: Attaching The Leader Pin To The Tape

    To attach the leader pin to the tape, see Figure 20 and complete the following steps: 1. Position the tape in the alignment groove of the leader pin attach tool. 2. Place a new C-clip into the retention groove on the leader pin attachment tool and make sure that the open side of the clip faces up.
  • Page 94 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 95: Notices

    Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.

  • Page 96: Important Notes

    IBM is not responsible for replacement of a device that has exceeded its maximum guaranteed number of program/erase cycles, as documented in the Official Published Specifications for the device. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 97: Particulate Contamination

    IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. Some software might differ from its retail version (if available) and might not include user manuals or all program functionality.

  • Page 98: Documentation Format

    IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 99: Industry Canada Class A Emission Compliance Statement

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 100: Germany Class A Statement

    IBM-Allee 1, 71139 Ehningen, Germany Telephone: +49 7032 15 2941 Email: lugi@de.ibm.com Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 101: Japan Vcci Class A Statement

    Japan VCCI Class A statement This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case the user may be required to take corrective actions.

  • Page 102: People's Republic Of China Class A Electronic Emission Statement

    People's Republic of China Class A electronic emission statement Taiwan Class A compliance statement IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 103: Glossary

    A laser device specialized for scanning and reading bar codes and converting © Copyright IBM Corp. 2013...
  • Page 104 A word to call attention to possible lethal harm to people. Contrast with attention Customer engineer; field engineer; service and caution. representative. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 105 data Any representations such as characters or direct access storage analog quantities to which meaning is or A storage device in which the access time might be assigned. is independent of the location of the data. data buffer Directory Name System. This allows the The storage buffer in the control unit.
  • Page 106 The informal name for the System (BIOS) in read-only memory third-generation version of the IBM (ROM) on a PC motherboard. Ultrium Tape Drive. The Generation 3 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 107 IBM device that controls the movement of the Ultrium Tape Drive. The Generation 4 magnetic tape in an IBM LTO Ultrium drive has a native storage capacity of up Tape Cartridge. The drive houses the to 800 GB per cartridge and a native...
  • Page 108 In the Metric System, the basic unit of liquid crystal display (LCD) length; equal to approximately 39.37 A low-power display technology used in inches. computers and other I/O devices. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 109 micro One millionth of. node In a network, a point at which one or more functional units connect channels or microcode data circuits. (1) One or more micro instructions. (2) A code, representing the instructions of an Network Time Protocol. This allows the instruction set, implemented in a part of library to set its internal date and time storage that is not program-addressable.
  • Page 110 Small Computer Systems Interface (SCSI) An error condition that allows continued A standard used by computer execution of a program. manufacturers for attaching peripheral IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 111 devices (such as tape drives, hard disks, sync Synchronous, synchronize. Occurring with CD-ROM players, printers, and scanners) a regular or predictable time relationship. to computers (servers). Pronounced “scuzzy”. Variations of the SCSI interface provide for faster data transmission rates tachometer, tach than standard serial and parallel ports (up A device that emits pulses that are used to 160 megabytes per second).
  • Page 112 A character string that is convenient for some purpose to consider as an entity. Write Write command. world trade. External register. External register address register. IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...

  • Page 113: Index

    6 cleaning the drive 24 media 35 drive servicing 6 Configure drive Function code F: Write performance DSA, sending data to IBM 58 to hub 14 test 36 to server 14 Function code H: Test head 37 to switch 14...
  • Page 114 84 LTFS 6 disabling 40 tape drive enabling 39 installation 10 power tape drive status 24 button 17 tape drive status, web page 24 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 115 TapeAlert flags 61 telecommunication regulatory statement 80 telephone numbers 59 test drive head 37 trademarks 77 trained service technicians, guidelines x training media handling 48 turn off enclosure or server 11 United States FCC Class A notice 81 unload button 21 unpacking shipment 10 Unpacking shipment 10 unsafe conditions, inspecting for x...
  • Page 116 IBM Half High LTO Ultrium Gen 6 Internal SAS Tape Drive: Installation and User's Guide...
  • Page 118 Part Number: 00Y8026 Printed in USA (1P) P/N: 00Y8026...

Table of Contents
