The most up-to-date drivers and manuals are available from: http://www.okiprintingsolutions.com Trademark Information ____________________________________________________ Oki and Oki Data are registered trademarks of Oki Electric Industry Company Ltd. Apple, Macintosh and Mac OS are registered trademarks of Apple Computers Inc. Hewlett-Packard, HP, and LaserJet are registered trademarks of Hewlett-Packard Company.
If it gets into the eyes, flush with large amounts of water for at least 15 minutes keeping eyelids open. Seek medical attention. Spillages should be treated with cold water and soap to help reduce risk of staining skin or clothing. ANUFACTURER Oki Data Corporation, 4-11-22 Shibaura, Minato-ku, Tokyo 108-8551, Japan Emergency first aid > 3...
OTES CAUTIONS AND WARNINGS NOTE A note provides additional information to supplement the main text. A caution provides additional information which, if ignored, may result in equipment malfunction or damage. A warning provides additional information which, if ignored, may result in a risk of personal injury. For the protection of your product, and in order to ensure that you benefit from its full functionality, this model has been designed to operate only with genuine original toner cartridges.
NTRODUCTION Congratulations on buying this Oki Printing Solutions color printer. Your new printer is designed with advanced features to give you clear, vibrant color prints and crisp black and white pages at high speed on a range of print media for the office.
RINTER OVERVIEW RONT VIEW 1. Output stacker (face down). Standard printed copy delivery point. Holds up to 250 sheets at 80g/m². 2. Operator panel. Menu driven operator controls and LCD display panel. 3. Paper tray. Standard blank paper tray. Holds up to 300 sheets of 80g/m²...
* The Network Interface may have a protective “plug” which must be removed before connection can be made. When the rear paper stacker is folded down paper exits the printer through the rear of the printer and is stacked here face up. This is mainly used for heavy print media. When used in conjunction with the multi purpose feed tray, the paper path through the printer is essentially straight.
APER RECOMMENDATIONS Your printer will handle a variety of print media, including a range of paper weights and sizes, transparencies and envelopes. This section provides general advice on choice of media, and explains how to use each type. The best performance will be obtained when using standard 20 to 24 lb (75~90g/m²) paper designed for use in copiers and laser printers.
(two-sided printing) function. ACE DOWN STACKER The face down stacker on the top of the printer can hold up to 250 sheets of 80g/m² standard paper, and can handle paper stocks up to 176g/m². Pages printed in reading order (page 1 first) will be sorted in reading order (last page on top, facing down).
Load paper long edge feed (LEF) (letter headed paper - face down and top edge towards the right of the printer) (1) up to mark (a). Adjust the rear stopper, paper guides (2) and cassette tray roller (3) to the size and orientation of paper being used.
Page 13
IMPORTANT: Set paper size dial (3) to the size and orientation of paper being used (A4 LEF in the above example). > C810 only: GDI printers use the printer settings defined by the host (PC). If the paper is oriented long-edge, the Long Edge Feed (LEF) checkbox must be enabled in the printer driver.
Page 14
To prevent paper jams: > Do not leave space between the paper and the guides and rear stopper. > Do not overfill the paper tray. Capacity depends on the type of paper stock. > Do not load damaged paper. > Do not load paper of different sizes or types at the same time.
For two-sided (duplex) printing on A4 headed paper load the paper with pre- printed side down and left hand edge (LEF), top edge (SEF) away from the printer. (Optional duplex unit must be installed for this function.) > Envelopes should be loaded face up with top edge to the left and short edge into the printer.
The document does not print until a PIN (Personal Identification Number) is entered through the Printer Control Panel. You must go to the machine and enter the PIN. This feature requires the hard disk drive option to be fitted to your machine and enabled in the printer driver.
Print your document. The print job will be sent to the machine, but will not print at this time. RINTING THE DOCUMENT Your secure print job is printed using the Printer Control Panel on the front of the machine. EADY ESTART...
This feature requires the hard disk drive in your machine, this device must be enabled in the printer driver. The encrypted secure printing feature may not be available from within some PC applications.
HDD. When this period expires, the print job is automatically erased from the HDD. Click [OK] to accept your changes. Click [OK] to close the Printer Properties window. Print your document. RINTING THE DOCUMENT Follow the same procedures as described in the section for printing a secure document.
- C810 ENU FUNCTIONS This section lists the menus accessed via the controls on the printer’s operator panel and displayed in the LCD window. PERATOR ANEL EADY TTENTION 1. Ready LED ON:Ready to receive data. Blinking:Processing data. OFF: Offline. 3. Menu Button Enters the Menu mode.
> Press ON LINE to exit from the menu system and return to standby. NOTE: When you have changed any settings in the USB MENU, turn the printer OFF, then ON again. OW TO CHANGE THE SETTINGS You can set whether to ENABLE or DISABLE each category in the user menu.
ENUS NFORMATION MENU This menu provides a quick method of listing various items stored within the printer. ITEM ACTION PRINT MENU MAP EXECUTE NETWORK EXECUTE DEMO1 EXECUTE USAGE REPORT EXECUTE HUTDOWN ITEM ACTION SHUTDOWN START EXECUTE RINT MENU This menu provides adjustment of various print job related functions.
The printer runs at 30ppm for all print jobs. This setting is most appropriate when the majority of print jobs are in color. The printer runs at 26 ppm for color pages and 30 ppm for mono pages. EXPLANATION Selects the size of paper loaded in Tray 1 (upper tray if both trays installed).
Page 25
Selects the media weight to be fed from the multi purpose tray. Selects the unit of measure for the next two items. Menu functions - C810 > 25...
C REG FINE ADJ -3~0~+3 M REG FINE ADJ -3~0~+3 Y REG FINE ADJ -3~0~+3 YSTEM CONFIGURATION MENU This menu adjusts general printer settings to suit the way you prefer to work. ITEMS SETTINGS POW SAVE DELAY CLRABLE WARNING ONLINE MANUAL TIMEOUT...
12 / 480 Mps SERIAL NUMBER ENABLE / DISABLE NOTE: When you have changed any settings in the USB MENU, turn the printer OFF, then ON again. ETWORK MENU This menu controls the operation of the printer’s 10Base-T/100Base-TX network interface.
–3~0~+3 SAGE MENU This menu is for information only, and provides an indication of total usage of the printer and the expected life left in its consumable items. This is particularly useful if you do not have a full set of replacement consumables to hand and you need to know how soon you will need them.
After the setting change, exit from the menu, and mode change to ONLINE, the printer will restart. * C810 standard printers do not display this menu. C DRUM CHECK Switches ENABLE/DISABLE of installation check for a CYAN/MAGENTA or YELLOW image drum.
Page 30
If NO is selected, the printer will go back to the source menu. If YES is selected, the printer will be automatically rebooted and initialize the flash memory. YES/NO If YES is selected ADMIN MENU will not appear - FILE SYS MAINT ! Menu functions - C810 > 30...
When executing this menu, resets the main counter to zero and exits from the menu. Enable must be selected in Functions/Print Statistics/ Usage Report. Resets the Supplies counter to zero. Changes the password. Enable must be selected in Functions/Print Statistics/ Usage Report Menu functions - C810 > 31...
Page 32
ITEM SETTINGS xxxx Password Verify xxxx Password EXPLANATION Sets a new password to enter Print Statistics menu. Re-enter new password set to enter Print Statistics set in New Password for confirmation. Menu functions - C810 > 32...
- C830 ENU FUNCTIONS This section lists the menus accessed via the controls on the printer’s operator panel and displayed in the LCD window. PERATOR ANEL EADY ESTART TTENTION ON: Ready to receive data. 1. R EADY BLINKING: Processing data.
It should be noted that many of these settings can be, and often are, overridden by settings in the Windows printer drivers. However, several of the driver settings can be left at “Printer Setting”, which will then default to the settings entered in these printer menus.
Displays the IP Address Subnet of the network. Displays the Subnet Mask. Displays the Gateway of the network. Displays the Mac Address of the printer. Displays the Network firmware revision. Displays the Web remote version. Displays information for these items.
RINT INFORMATION MENU This menu provides a quick method of listing various items stored within the printer. ITEM ACTION Configuration Execute Network Execute Demo Page Demo 1 Execute File List Execute PS font List Execute PCL font List Execute IBM PPR Font List...
(Searching time increases in proportion to the number of jobs stored in HDD, and the printer may take up to 20 sec.) The search can be cancelled by holding down the Cancel button.
ENUS ITEM ACTION Tray Configuration Paper feed Tray 1/MPT Auto Tray Switch On/Off Tray Sequence Down/Up/Paperfeed Unit of Measurement Inch/millimeter Tray1 Configuration Default: Paper size: Media Type: Media Weight: Tray 2 Configuration (if fitted) Default: Paper size: Media Type: Media Weight: Tray 3 Configuration (if fitted) Default:...
Page 39
ITEM ACTION Tray Configuration MPT Tray Configuration (cont.) Paper size: Media Type: Media Weight: Tray usage: EXPLANATION Configure Paper Size/Media Type/Media Weight/Tray Usage. Defines default condition A3/A4 SEF/A4 LEF (indicated by *) Select by scroll and Enter A5/A6/B4/B5 SEF/ button. B5 LEF/Legal14/ *User type 1 to 5 are displayed only if Legal 13.5/...
Page 40
ITEM ACTION System Adjust Power Save Time Default: Clearable Warning Default: Auto Continue Default: Manual Timeout Default: Wait Timeout Default: Low Toner Default: Jam Rcovery Default: Error Report Default: Print Position Adjust Default: Paper Black Settings Default: Paper color Settings Default: Trans.
HUTDOWN MENU This menu only appears if the hard disk drive is installed. This item should always be selected before switching the printer off, to ensure that no hard disk data is lost. If using the Operator panel button instead, keep pressed for approximately 5 seconds...
DMIN ETUP ITEM SETTINGS Enter xxxxxxxxxxxx Password Network TCP/IP Enable Setup Disable IP Version IP v4 IP v4+v6 NetBEUI Enable Disable NetWare Enable Disable EtherTalk Enable Disable Frame Type Auto 802.2 802.3 Ethernet II SNAP TypeIP Auto Address Set Manual IP Address xxx.xxx.xxx.xxx Subnet Mask...
Page 43
When Normal is selected, the network can work effectively even when it is connected to a HUB that has a spanning tree feature. However, printer start up time gets longer when computers are connected with two or three small LANs.
Page 44
ITEM SETTINGS Print Setup Mono-Print Auto (cont.) Speed Mono 32ppm Color Speed Mixed Speed Default Portrait Orientation Landscape Form Length 5 lines 64 lines 128 lines Edit Size Cassette Size/ A3/A4 Short Edge/A4 Long Edge/A5/A6/B4/ B5 Short Edge/ B5 Longt Edge/ Legal14/ Legal13.5/ Legal13/Tabloid/...
Page 45
ITEM SETTINGS PCL Setup Font Source Resident Font I0 ~ I90 Number Font Pitch 99.9 CPI 10.00 CPI 0.44 CPI Symbol Set PC-8 A4 Print 78 column Width 80 column White Page On/Off skip CR Function CR/CR+LF LF Function LF/LF+CR Print Margin Normal 1/5 inch...
Page 46
ITEM SETTINGS PCL Setup True On/Off (cont.) Black Pen Width On/Off Adjust Tray 2 ID# 1 ~ 5 ~ 59 Tray 3 ID# 1 ~ 20 ~ 59 MPTray ID# 1 ~ 4 ~ 59 EXPLANATION Sets whether to use Composite Black (cmyk mixed) or Pure Black (K only) for the black (100%) in image data.
Page 47
11 inches (66 lines), in the LETTER-size printable area. Sets height of a character. SAME: Regardless of CPI, same height DIFF: According to CPI, character heights vary. Sets printer for using continous feed stationary. Menu functions - C830 > 47...
Page 48
11 inches (66 lines), in the LETTER-size printable area. Sets height of a character. SAME: Regardless of CPI, same height DIFF: According to CPI, character heights vary. Sets printer for using continous feed stationary. Menu functions - C830 > 48...
Page 49
16 megabyte EXPLANATION The machine has its own process simulation engine which simulates standard colors in the printer. This function is available only with PS language jobs. Selects limitation to the toner layer thickness. If paper curl occurs in dark printing, selecting MEDIUM or LIGHT sometimes helps reduce this curl.
Page 50
ITEM SETTINGS HDD Setup This item is displayed only if a HDD (option) is installed. Initialize Execute EXPLANATION Initializes the HDD to the factory default setting. Machine performs partition-division, and initializes each partition. When this menu is executed, the following confirmation message appears.
Page 51
ITEM SETTINGS HDD Setup Resize PCL nn%/ (cont.) Partition Common mm%/ PSll%/<Apply> Format Partition Common System Near Life Enable/Disable Setup Status Near Life Enable/Disable EXPLANATION Specifies the size of partition. Specifies a size by ratio to the whole HDD in % (1% unit). nn,mm,ll: 1 - 98 and nn+mm+ll=100 The sizes are displayed in the partition list and can be changed by selecting the partition size to be changed.
If Execute is selected, the printer will immediately adjust density and reflect it in TRC compensation. This adjustment must be executed when the printer is idling. It can become invalid if executed in any other state. Execute When this menu is selected, the printer performs AutoAdjust Registration.
Enable / Disable Serial Number Enable / Disable When you have changed any settings in the USB MENU, turn the printer OFF, then ON again. EXPLANATION Enter a password to gain entry to the Admin menu. Password should be from 6 to 12 digits of alpha/numeric characters (or mix) The default value is "aaaaaa"...
Page 54
After execution, the following confirmation messages will appear. Are You Sure? If No is selected, the display will return to the previous menu. If Yes is selected, the printer will be automatically rebooted and the resetting of the cipher key will be executed. EXPLANATION Resolves mismatch between actual memory and displayed memory available in a file system.
Page 55
ITEM SETTINGS Erase HDD Execute Enable initialization EXPLANATION Deletion of all data stored in the hard disk. DoD 5220.22-M sanitizing formula is used for clearing the desk. The machine will restart after changing setup. The following message appears after pressing the Enter switch.
"Print Statistics" category is not shown when Print Statistics function is not supported. Enables/Disables the printing of the Usage Report. When changing a setting value, the printer is rebooted. Specifies if the Group counter is displayed in the Usage Report Print.
Page 57
ITEM SETTINGS Supplies Report Enable/Disable Reset Main Counter Execute Reset Supplies Execute Counter Change Password Password xxxx Verify Password xxxx EXPLANATION Enebles/disables the Supplies Report. Enable must be selected in Functions/Print Statistics/ Usage Report. Resets the main counter to zero. When executing this menu, resets the main counter to zero and exits from the menu.
You can use PostScript overlays to generate all your special stationery and store it in the printer for use whenever you need it. If you have chosen to install the PCL driver, macros perform a similar function. You can create several overlays or macros, and combine them in any way you like to produce a variety of forms and other special stationery.
Navigate to the folder where the.PRN files are stored and select one or more of these to include in your overlay set. You can have more than one printer (.PRN) file in a project. For example, one for top pages and another for continuation pages. Use standard Windows techniques (Shift or Ctrl keys) to select multiple files simultaneously if you need to.
Finally, in your application’s print dialogue, click OK to begin printing. PCL O REATING VERLAYS Three steps are required to create an overlay: Create the form data using your own application software and print it to a printer (.PRN) file. Overlays and Macros (Windows) > 60...
OK to clear the message. The project window will display one .BIN file for each printer file added. Make a careful note of the name and ID number for each of the files. You will need them later.
Storage Device Manager to view the project file, or the printer’s Information Menu to print a file list and identify them from there. The new overlays will now appear in the Defined Overlays list in the printer properties window.
Open your application’s Print… dialogue and choose any options you will require, ensuring that the target printer is your PCL printer driver in which the overlays have been defined. Click the Properties button to open the Printing Preferences window.
As a guide, the life expectancy of these items is: > Toner: Starter Cartridge: The printer is shipped with sufficient Cyan, Magenta, Yellow & Black toner for 2,000 images (ISO/IEC19798), of which 750 images are used to charge the image drum (1,250 images remaining at 5% coverage). Replacement Cartridge: Replacement cartridges (C, M, Y &...
Non-genuine original products may invalidate your warranty. The toner used in this printer is a very fine dry powder. It is contained in four cartridges: one each for cyan, magenta, yellow and black. Have a sheet of paper handy so that you have somewhere to place the used cartridge while you install the new one.
Page 66
Press the cover release and open the printer’s top cover fully. If the printer has been powered on, the fuser may be hot. This area is clearly labelled. Do not touch. Note the positions of the four toner cartridges (a) and image drums (b).It is essential that they go back in the same order.
Page 67
(b). Pressing gently down on the cartridge to ensure that it is firmly seated, push the colored lever (c) towards the rear of the printer. This will lock the cartridge into place and release toner into the image drum unit.
MAGE DRUM REPLACEMENT Static sensitive devices, handle with care. The printer contains four image drums: cyan, magenta, yellow and black. Press the cover release and open the printer’s top cover fully. WARNING! If the printer has been powered on, the fuser will be hot.
Page 69
5 minutes. If the drum unit needs to be out of the printer for longer than this, please wrap the cartridge inside a black plastic bag to keep it away from light. Never expose the drum to direct sunlight or very bright room lighting.
Page 70
Holding the complete assembly by its top centre, lower it into place in the printer, locating the pegs at each end into their slots in the sides of the printer cavity. Finally, close the top cover and press down firmly at both sides so that the cover latches closed.
Note the positions of the four toner cartridges (a) and image drums (b).It is essential that they go back in the same order. Lift each of the image drum units out of the printer and place them in a safe place away from direct sources of heat and light.
Page 72
Locate the drive gear into the gear inside the printer by the rear left corner of the unit, and lower the belt unit flat inside the printer. Turn the two fasteners (a) 90° to the right until they lock. This will secure the belt unit in place.
Pull the fuser retaining lever (b) towards the front of the printer so that it is fully upright. Holding the fuser by its handle (a), lift the fuser straight up and out of the printer. If the fuser is still warm, place it on a flat surface which will not be damaged by heat.
Push the retaining lever (b) towards the rear of the printer to lock the fuser in place. Finally, close the top cover and press down firmly at both sides so that the cover latches closed. Switch the printer ON. LEANING THE...
It also enables booklet printing, which uses even less paper and makes large documents even easier to handle. The duplex unit slides straight into the rear of the printer and requires no tools to install. Unpack the new unit and remove any transit material from it.
) securing the right-hand side cover. Lift the edge of the side cover slightly and pull the cover away from the printer at the top. Lift the cover slightly to detach it from the printer. Place it safely to one side.
Page 78
Locate the three retaining clips at the bottom of the side cover into their rectangular holes near the bottom of the printer. Close the top of the side cover up to the printer and refit the securing screw removed in step 4.
Page 79
When the printer is ready, print a menu map as follows: Press the Enter button. Press the Menu up button then the Enter button to select the Print Information menu. Select Configuration with the Enter button. Press the Enter button once more to execute the Configuration menu.
Remove the screw (a) securing the right-hand side cover. Lift the edge of the side cover slightly and pull the cover away from the printer at the top. Lift the cover slightly to detach it from the printer. Place it safely to one side.
Page 81
Close the front cover and the top cover, pressing down firmly at each side to latch it closed. All that remains is to adjust the printer driver to make full use of the new features (“Adjusting printer drivers” on page Reconnect the AC power cable and switch the printer on.
(a), place printer on top of the additional paper tray(s). Re-connect the AC power cable and switch the printer ON. All that remains is to adjust the printer driver to make full use of the new features (“Adjusting printer drivers” on page 83).
The illustrations shown here are for Windows XP. Other Windows versions may appear slightly different, but the principles are the same. If you have installed a memory upgrade it is not necessary to change the printer driver, and you can ignore this section.
Page 84
Panther (Mac OS X 10.3) Open the Mac OS X Print & Fax Preferences. Select Printing. Select Set Up Printers... Ensure your machine is selected and select Show Info... Select the menu and choose Installable Options... Select any options appropriate to your hardware and click Apply Changes. Installing upgrades >...
Provided that you follow the recommendations in this guide on the use of print media, and you keep the media in good condition prior to use, your printer should give years of reliable service. However, paper jams occasionally do occur, and this section explains how to clear them quickly and simply.
CODE # If a sheet is well advanced out of the top of the printer, simply grip it and pull gently to draw it fully out. If it does not remove easily, do not use excessive force. It can be removed from the rear later.
Page 87
It will be necessary to remove the four image drums (b) to gain access to the paper path. Holding it by its top centre, lift the cyan image drum, complete with its toner cartridge, up and out of the printer. he assembly down gently onto a piece of paper to prevent toner from marking Put t your furniture and to avoid damaging the green drum surface, and cover.
Page 88
Repeat this removal procedure for each of the remaining image drum units. Look into the printer to check whether any sheets of paper are visible on any part of the belt unit. Do not use any sharp or abrasive objects to separate sheets from the belt.
Page 89
To remove a sheet in the fuser; pull the retaining lever (a) towards the front of the printer to release the fuser. Withdraw the fuser unit using the handle (b). Lift the fuser pressure release levers (c) up and press toward the rear to release the fuser’s grip on the sheet.
Page 90
Holding the complete assembly by its top centre, lower it into place in the printer, locating the pegs at each end into their slots in the sides of the printer cavity. Lower the top cover but do not press down to latch it closed yet. This will protect the drums from excessive exposure to room lighting while you check the remaining areas for jammed sheets.
Page 91
Finally, close the top cover and press down firmly so that the cover latches closed. When the jam has been cleared, if Jam Recovery is set to ON in the System Configuration Menu, the printer will attempt to reprint any pages lost due to paper jams. Clearing paper jams > 91...
PECIFICATIONS C810 - N34240A C830 - N34241A ITEM SPECIFICATION Dimensions 20 x 22 x 16 inches (485 x 556 x 345mm) (W x D x H) without Duplex unit Weight 79 lbs. (36Kg) approx. (without Duplex unit) Print method LED exposed light source electronic photographic...
Page 93
The printer has a “wake-up” feature which, when initiated from a host device or the operator panel, will revert the printer to its “running” mode. Specifications subject to change without notice. All trademarks acknowledged.
For more information, click “Tell me more” on the Optional Utilities screen. Windows Admin Manager For quick discovery and setup of the Oki network card in your printer. Runs directly off the CD. Direct Network Printing Utility (LPR) For printing on an Ethernet network without the need for a print server.
Storage Device Manager Requires the hard disk drive, optional on some models. Download PCL macros, Postscript forms and bar codes to the printer hard disk drive for use in print jobs. Job Accounting Utility Use to control printer access and to monitor consumables usage.
