Remote Control Channel Mapping

The channel arrangement of the PPM output to the RF module is dependant on the kind of flight controller
that is hooked-up on the receiver side.
In the configuration menu, you can change the mapping by changing the model type to match your particular
setup.
PPM
DJI
Channel
1 AIL
2 ELE
3 THR
4 RUD
5 Tuner L (E)
6 Tuner R (F)
7 3-Pos Right (D)
8 2-Pos Right (C)
9 3-Pos Left (B)
10 2-Pos Left (A)
Flight Control Model
3DR BLADE
AIL THR
ELE AIL
THR ELE
RUD RUD
3-Pos Right (D) 3-Pos Right (D)
Tuner R (F) 2-Pos Right (C)
2-Pos Right (C) 2-Pos Left (A)
2-Pos Left (A) 3-Pos Left (B)
Tuner L (E) Tuner L (E)
3-Pos Left (B) Tuner R (F)
8
CROSSFIRE TAULABS
AIL AIL
ELE ELE
THR THR
RUD RUD
3-Pos Right (D) 3-Pos Right (D)
2-Pos Right (C) 2-Pos Right (C)
2-Pos Left (A) 2-Pos Left (A)
3-Pos Left (B) 3-Pos Left (B)
Tuner L (E) Tuner L (E)
Tuner R (F) Tuner R (F)
