FrSky XJT

Despite being one of the most popular R/C systems, FrSky's RF modules and even receivers are notorious for
interfering with 5.8GHz receivers, video transmitters or other 2.4GHz R/C systems. When designing the Tango
we have taken every precaution possible to ensure a interference-free operation also with FrSky's devices, but
it is all at the limits. This is a problem in the engineering and design of FrSky, and NOT a TBS problem. We can
assure the Tango can work problem-free with the FrSky XJT module, but a few things will need to be in place:
1) The internal 5.8GHz patch antenna needs to be as far away from the RF module as possible. From the
factory, the patch antenna will have been installed and secured in the proper location. If you do
experience video issues such as vertical "flashing" lines, please open up the front antenna cover and
ensure that the antenna is installed properly.
2) If despite proper antenna installation you are still seeing issues in the video, you can additionally
cover your FrSky XJT module with copper- or aluminum-tape. Be sure to leave plenty of space around
the pin holes. Grounding the tape is NOT necessary, or recommended! Alternatively you can also
cover the inside of the JR module bay with copper- or aluminum-tape, instead of placing tape on the
XJT module.
3) Should both the mods above fail, please contact our customer support. If possible, please document
the problem with a quick video so that we can assist you faster and better.
