Page 1: Setup Guide
Color Scanner Setup Guide ZDLH001E.eps Read this manual carefully before you use this product and keep it handy for future reference. For safety, please follow the instructions in this manual. 7,19 ... - Page 2 Printed in the Japan G412-6661 7,19 ...
- Page 3 Ricoh shall not be responsible for any damage or expense that might result from the use of parts other than genuine Ricoh parts in your Ricoh office product.
- Page 4 “The Product complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC.” In accordance with IEC 60417, this machine uses the following symbols for the main power switch: a means POWER ON. b means POWER OFF. Ricoh Aficio Color Scanner IS330DC Copyright © 2000 7,19 ...
- Page 5 Trademarks ® ® ® Microsoft , Windows and Windows NT are registered trademarks of Mi- crosoft Corporation in the United States and/or other countries. Other product names used herein are for identification purposes only and might be trademarks of their respective companies. We disclaim any and all rights in those marks.
-
Page 6: Safety Information
Safety Information When using your scanner, the following safety precautions should always be followed. Safety During Operation In this manual, the following important symbols are used: R WARNING: Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. R CAUTION: Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to... - Page 7 R CAUTION: • Protect the equipment from dampness or wet weather, such as rain, snow, and so on. • Unplug the Power Cord from the wall outlet before you move the equipment. While moving the equipment, you should take care that the Power Cord will not be dam- aged under the equipment.
-
Page 8: Energy Star Program
Energy Star Program As an ENERGY STAR Partner, we have determined that this machine model meets the ENERGY STAR Guidelines for energy efficiency. The ENERGY STAR Guidelines intend to establish an international energy-saving system for developing and introducing energy-efficient office equipment to deal with environmental is- sues, such as global warming. -
Page 9: Manuals For This Scanner
Manuals for This Scanner Manuals for This Scanner The following manuals describe the operational and maintenance procedures of this machine. To enhance safe and efficient operation of this scanner, all users should read and follow the instructions carefully. Quick Installation Guide Describes how to install the scanner. -
Page 10: How To Read This Manual
How to Read This Manual Symbols In this manual, the following symbols are used: R WARNING: This symbol indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. R CAUTION: This symbol indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property. -
Page 11: Table Of Contents
TABLE OF CONTENTS 1. Getting Started Features of This Scanner................1 Guide to This Scanner ................2 Understanding the Indicators..............4 Confirmations Prior to Installation ............6 Confirming the Installation Environment ............6 Connecting the Power Cord ..............8 Connecting to the PC ................9 Connecting to the SCSI Interface.............. - Page 12 viii 7,19 ...
-
Page 13: Getting Started
1. Getting Started Features of This Scanner High-speed Scanning Scanning can be performed at 30ppm in monochrome and 10ppm in color. (at A4L, 8.5” × 11”L/200dpi, when using SCSI-2/3 (Ultra-SCSI) connection) High-quality Images, Color Compatible Compatible for full color scanning, as well as for color matching output, in- cluding sRGB, ICM, and others. -
Page 14: Guide To This Scanner
Getting Started Guide to This Scanner ZDLH010E Document Tray Rotary Switch Set the document to be scanned by the Used for setting the SCSI ID. Automatic Document Feeder (ADF). DIP Switches Automatic Document Feeder These switches are for setting the opera- (ADF) tion mode. - Page 15 Guide to This Scanner ZDLH020E White Sheet This holds documents against the Con- tact Glass. ADF Contact Glass Place the documents set at the Automatic Document Feeder (ADF) to be scanned here. Contact Glass Place the documents to be scanned here. Lock Switch Use to lock the internal scanning equip- ment when transporting the scanner.
-
Page 16: Understanding The Indicators
Getting Started Understanding the Indicators This unit is equipped with the following indicators. ZDLH030E Power On Machine Busy Document in Place Error Under normal circumstances, the indicators of this unit are as follows. Under other circumstances, an error reading will occur. Refer to resolve the error. Description When switching on the power or when performing a hard reset... - Page 17 Understanding the Indicators When manual scan is in the standby mode during the Low Power mode. :Flashing -:Off 7,19 ...
-
Page 18: Confirmations Prior To Installation
Getting Started Confirmations Prior to Installation Installation space Confirming the Installation Install on a location that guaran- tees a space as shown in the illus- Environment tration. R WARNING: • Confirm that the wall outlet is near the • machine and freely accessible, so that in event of an emergency, it can be un- plugged easily. - Page 19 Confirmations Prior to Installation Optimum Environmental Conditions Recommended temperature and humidity 10 C 80% 27 C 80% 15 C 25 C 32 C 25 C 15 C 10 C 15% 32 C 15% 50 F80% 80.6 F 80% 59 F 77 F 89.6 F 77 F...
-
Page 20: Connecting The Power Cord
Getting Started Connecting the Power Cord The following explains the order for Important connecting the Power Cord to this Always make sure that the lock- unit. ing switch is in the {Unlock} po- R WARNING: sition. Switching on the power •... -
Page 21: Connecting To The Pc
Connecting to the PC Connecting to the PC This unit has an interface that com- Setting the SCSI ID plies with SCSI-2/3 standards and an interface that complies with IEEE1394 standards (option). This explanation Open the cover at the lower left of the main unit. -
Page 22: Connecting To The Ieee1394 Interface (Optional)
Getting Started When connecting multiple Connect the SCSI Connector of IEEE1394 compatible devices to this unit to the SCSI board of the multiple PC's, the operation may PC using the SCSI cable. become unstable. Please make sure proper operation when connecting multiple IEEE1394 compatible de- vices. - Page 23 Connecting to the PC Note When changing settings while the power is switched on, be sure to perform a hard reset by pressing the Hard Reset Switch. Use a cable to connect the IEEE1394 connector of this unit to the IEEE1394 connector of the PC. Connect the side of the cable that has a core to the IEEE1394 connec- tor of this unit.
-
Page 24: Installing Options
Getting Started Installing Options Pull and slide the scanner control Installing the IEEE 1394 Board unit out. (IEEE 1394 Interface Board Type S) Important Before touching the IEEE 1394 Board, make sure to first touch a metal object to discharge any static electricity accumulated in your body. -
Page 25: Installation Of Image Processing Unit (Image Processing Unit Type A)
Installing Options Attach the IEEE 1394 Board to the Check the contents of the box for scanner control unit, and then fas- the following items: ten in place with the screws re- • Image Processing Unit Type A moved in step and the screws •... - Page 26 Getting Started Attach the image processing unit to the scanner control unit and fasten with the enclosed screw. ZDLH170E After confirming that the image processing unit is securely at- tached, check to make sure that there are no metal or other foreign objects on the scanner control unit.
-
Page 27: Installing The Scanner Drivers
2. Installing the Scanner drivers This chapter assumes that the reader has sufficient understanding of the Win- dows operating system. Refer to the Windows operation manual for details about its functions and operation. The ways for installing the scanner driver on your computer vary depending on your operating system. -
Page 28: Installing The Scanner Driver By Auto Run
Installing the Scanner drivers Note If the [Add New Hardware Wizard] does not appear after starting up the PC, click the [Device Manager] tab on [System] in the [Control Panel], select the scanner name and click [Remove]. The [Confirm Device Removal] dialog box will be displayed, click [OK] and restart the system. - Page 29 Using Windows98/ME, Windows2000 If you want to cancel Auto Run, hold down the {SHIFT} key (when your sys- tem is Windows 2000, hold down the left {SHIFT} key) while inserting the CD- ROM. Keep the {SHIFT} key held down until the computer has finished ac- cessing the CD-ROM.
-
Page 30: Using Windows95, Windowsnt4.0
Installing the Scanner drivers Using Windows95, WindowsNT4.0 To install the scanner driver for Win- dows 95, WindowsNT4.0, refer to P.16 “Installing the Scanner Driver by Auto Run”. Limitation To install the driver when using WindowsNT4.0, log-on as a mem- ber of the Administrator group. 7,19 ... -
Page 31: Using Windowsnt3.51
Using WindowsNT3.51 Using WindowsNT3.51 Limitation To install the driver when using Windows NT3.51, log-on as a member of the Administrator group. The ISIS Driver does not work with Windows NT3.51. Installing the TWAIN driver Place the CD-ROM included with this product into the CD-ROM drive. -
Page 32: About The Software On The Cd-Rom
Installing the Scanner drivers About the Software on the CD-ROM List of Files The CD-ROM includes the software below. TWAIN driver for Windows95/98/Me, SCSI Japa- Windows2000, WindowsNT3.51/4.0 VERS nese DRIVE TWAIN driver for Windows95/98/Me, Oth- Windows2000, WindowsNT3.51/4.0 STI driver for Windows98/Me INF9 STI driver for Windows2000 INF2... -
Page 33: Isis Driver
About the Software on the CD-ROM Microsoft Windows 98, 98SE Windows Millenium Edition Windows 2000 Professional Windows 2000 Server Windows NT WorkStation 4.0 Service Pack 5.0 or higher Windows NT Server 4.0 Service Pack 5.0 or higher Windows NT 3.51- Service Pack 5.0 or higher •... -
Page 34: Index
INDEX Power Switch , 2 About the Software on the CD-ROM , 20 ADF Contact Glass , 3 Quick Installation Guide , v Automatic Document Feeder (ADF) , 2 Auto Run , 16 {Reset} key , 2 Rotary Switch , 2 Caution , ii Confirming the Installation Environment , Connection...
