Mainboard Specification

Processor
Supports 462-pin SocketA for AMD Athlon XP and Barton processors
with 266/333/400MHz Front Side Bus
- Athlon XP (1500+ to 3000+) with 266/333MHz Front Side Bus,
- Barton (2500+ to 3200+) with 333/400MHz Front Side Bus
Chipset
nVidia AGPset : nForce2 Ultra 400 + RAID MCP
Main Memory
Three 184-pin DDR DIMM sockets for 64-bit, Unbuffered, Single/Double-
side and DDR-266/333/400 DIMMs
Supports 128-bit
Supports up to 3GB memory size
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 K/B, PS2 Mouse, Modem Ring-in COM#1...
Onboard PCI Devices
1394 -->
(Optional)
LAN -->
dual channel memory architecture
Integrated VIA VT6307
- IEEE-1394a compliant with up to 400Mbps bandwidth
10/100Mbps Fast Ethernet with onboard
LAN PHY

SPECIFICATION

1394 controller with 2 ports solution
Realtek RTL8201CL
Specification
Section 2
Page 2-1
