PheeNet WAS-101 Quick Start Manual

Network access control server gateway
Hide thumbs

Advertisement

Quick Links

Download this manual
Network Access Control
Server Gateway
QuickStart Guide WAS-101
Version 1.10

Advertisement

loading
Need help?

Need help?

Do you have a question about the WAS-101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PheeNet WAS-101

Summary of Contents for PheeNet WAS-101

  • Page 1 Network Access Control Server Gateway QuickStart Guide WAS-101 Version 1.10...
  • Page 2 Quick Installation Guide Copyright This document is protected by R.O.C. copyright laws and other laws and is the property of PheeNet Technology Corp. You may not copy, reproduce, distribute, publish, display, perform, or modify any part of this content in any form or by any means without prior written permission of PheeNet Technology Corp.

  • Page 3: Package Contents

    PheeNet WAS 101 Quick Installation Guide This Quick Installation Guide (QIG) provides instruction for installing the WAS 101. This guide also shows you how to connect WAS 101 with other Network equipments. 1. Package Contents The standard package of the WAS 101 includes: WAS 101 x 1 CD-ROM (Administrator’s Manual and Quick Installation Guide) x 1...
  • Page 4 PheeNet WAS 101 Quick Installation Guide (Back Side) Public LAN Port can be connected to the open network environment managed by the system, and requires RJ11 Port can be console authentication before logging interface or printer DC Power on to the Internet.

  • Page 5: Quick Installation

    PheeNet WAS 101 Quick Installation Guide be used to connect to a Server such as Web Server or a Mail Server, etc. Use the network cable of the 10/100BaseT to connect to the Switch or Hub of the Private LAN, and then use the network cable of the 10/100BaseT to connect to the Administrator’s PC.
  • Page 6 PheeNet WAS 101 Quick Installation Guide Keying in the Administrator’s Username and Password In the opened webpage, you will see the login screen. Please key in “admin” in the Username column, and then “admin” in the Password column. Click “Enter” to login.
  • Page 7 PheeNet WAS 101 Quick Installation Guide The wizard will guide you through the nine steps for completing the setup. Click “Next” to go to the next screen. Step 1. Change Administrator’s Password Please enter New Password and Verify Password. (twenty characters maximum and no spaces).
  • Page 8 PheeNet WAS 101 Quick Installation Guide Step 3. Set System Information The Home Page, NTP Server, and DNS Server will appear after the user login system successfully, click “Next” to go to the next screen. Step 4. Set WAN Port Connection Type Please choose one item.
  • Page 9 PheeNet WAS 101 Quick Installation Guide •Dynamic IP Address Click “Next” to go to the next screen. •PPPoE Connection Click “Next” to go to the next screen. Please enter the PPPoE Username and Password. After the setup is completed, click “Next”.
  • Page 10 PheeNet WAS 101 Quick Installation Guide Step 5. Set Related Information for Public LAN Configure the parameters of the Authentication interface including the IP address, subnet mask, and disable/enable DHCP Server, the default setting is to enable the DHCP Server. Click “Next” to go to next screen.
  • Page 11 PheeNet WAS 101 Quick Installation Guide You can enter your Username and password then click “ADD” to add users. After the user is added: Ex: Username: test, Password: test Click “Next” to go to the next screen. Step 7. Set Wireless-Acccess Point Connection Entry your SSID, select Channel and Transmission mode.
  • Page 12 PheeNet WAS 101 Quick Installation Guide Step9.Restart After the setup is completed, the basic configuration has been completed. Click “Restart” to restart the machine.
  • Page 13 PheeNet WAS 101 Quick Installation Guide 5. Accessing External Network from Authentication (Public LAN) If all the steps are set properly so far, we can further connect the WAS 101 to the managed network to experience the controlled network access environment. Firstly, connect a user-end device to the network at the WAS 101 Authentication, and set the dynamic access network.
  • Page 14 PheeNet WAS 101 Quick Installation Guide For On-demand user: The following is the successfully login page for on-demand user. There is an extra function, the “Redeem” buttom, that user can add credit in the current account if the remaining usage is considered to be insufficient.
