Page 1 Wireless Hot Spot Gateway WAS-103R User Manual Version 1.03...
Page 2 2.4 Installation Steps ..........................5 2.5 Instruction to Web Management Interface ..................6 Chapter 3. AP Mode Configuration ..................... 8 3.1 Connect WAS-103R to the external Network ................9 3.1.1 Network Requirement ......................... 9 3.1.2 Configure LAN IP ........................9 3.2 Create your Wireless LAN Network ....................
Page 3 4.4.3 Configure SNMP ........................69 4.4.4 Backup / Restore and Reset to Factory ..................71 4.4.5 Firmware Upgrade ........................72 4.4.6 Network Utility ......................... 73 4.4.7 Reboot ............................74 4.5 Access To External Network With HotZONE ................75 4.5.1 Generate Access Ticket ......................75 4.5.2 Verify Access Ticket .........................
Page 4 Nowadays, Wireless Internet Access is almost a kind of value added service. By taking the advantages of PheeNet WAS-103R, front desk operator does not have to have IT technology background, they just need to identify the customer grade, offer the appropriate Pre-set ticket, and then charge the money (or not).
Page 5 PheeNet WAS-103R is the most economical yet feature-rich Wireless Hotspot Gateway, targeting mini-size stores who want to provide small, single-point Wireless Internet access service. WAS-103R is a perfect choice for beginners to run hotspot businesses. It does not cost a fortune to buy pile of equipment, nor does it take the skills of an expert to glue multiple applications out of multiple freeware.
Page 6 ADSL, or the port of a Cable Modem. The port will be used by WAN port. Console : The Serial RS-232 DB9 cable attaches here. Rear Panel WAS-103R supports 1 RF Interface with 2 SMA connectors for Antenna connection. LED Panel...
Page 7 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WLAN : Green LED FLASH indicates Wireless ON, and FLASH quickly indicates Wireless Transmit quickly. LAN1/LAN2 : Green LED ON indicates connection, OFF indicates no connection, and FLASH indicates the Port Transmit PWR :...
Page 8 Connect WAS-103R to your network device. Connect one end of the Ethernet cable to LAN2 port of WAS-103R on the front panel. Connect the other end of cable to a PC for configuring the system. The LAN2 LED indicator should be ON to indicate a proper connection.
Page 9 IP Segment Set-up for Administrator's PC Set the IP segment of the administrator's computer to be in the same range as WAS-103R for accessing the system. Do not duplicate the IP Address used here with IP Address of WAS-103R or any other device within...
Page 10 WAS-103R Wireless Hotspot Gateway ENGLISH Login Success When administrator login successfully, the WAS-103R web management UI should be viewed at the Status section under the System Overview page This section only used on AP Mode. If you access to system on Hotspot Mode, you need configure VLAN tag(ID) on your PC/NB.
Page 11 When AP mode is activated, the system can be configured as an Access Point. This section provides information in configuring the AP mode with graphical illustrations. WAS-103R provides functions as stated below where it can be configured via a user-friendly web based interface.
Page 12 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Basically, in general network environment, the main role of WAS-103R is an Access Point,. It manages the network from internal network to Gateway. The first step is to get a Default Gateway IP Address from system manager and connect it to the LAN1 / LAN2 port of WAS-103R Below is the instruction for setting up the local IP Address and Netmask.
Page 13 This can be a DSL modem, Cable modem, or a WISP gateway router. WAS-103R will direct all the packets to the gateway if the destination host is not within the local network. Default Gateway is 192.168.2.1 Gateway IP address should be from the same address space (on the same network segment) as the WAS-103R's external network interface.
Page 14 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Change these settings as described and click Save button to save your changes. Click Reboot button to activate your changes...
Page 15 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The system manager can configure related wireless settings, General Settings, Advanced Settings, Virtual AP Setting, Security Settings, and Access Control Settings. The administrator can change the data transmission, channel and output power settings for the system. Please click on Wireless ->...
Page 16 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can change the Slot Time, ACK/CTS Timeout, RTS threshold and fragmentation threshold settings for the system. Please click on Wireless -> Advanced Setup and follow the below setting. Slot Time : Enter the desired slot time for the AP.
Page 17 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH network. DTIM Interval : Input the DTIM Interval that is generated within the periodic beacon at a specified frequency. Higher DTIM will let wireless client save more energy, but the throughput will decrease consecutively.
Page 18: Create Virtual Ap
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can create Virtual AP via this page. Please click on Wireless -> Virtual AP Setup and follow the below setting. Enable : Click Enable button and Save button for creating Virtual AP VAP : Display number of system's Virtual AP.
Page 19 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH For each Virtual AP, administrators can configure general settings and security type. Click Wireless -> Virtual AP, click “Edit” of Virtual AP List and then Virtual AP Configuration page appears. ESSID : Extended Service Set ID indicates the SSID which the clients used to connect to the VAP. ESSID will determine the service type of a client which is assigned to the specified VAP.
Page 20 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH VLAN Tag(ID) : Virtual LAN, the system supports tagged VLAN. To enable VLAN function; valid values are from 0 to 4094. Security Type : Select the desired security type from the drop-down list; the options are WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise and WEP 802.1X.
Page 21 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Cipher Suite : Check on the respected button to enable either AES or TKIP cipher suites; default is TKIP. Group Key Update Period : This time interval for re-keying GTK (broadcast/multicast encryption keys) in seconds. Enter the time-length required; the default time is 600 seconds.
Page 22 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Authentication RADIUS Server Settings : • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 23 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Accounting Server : Enter the IP address of the Accounting RADIUS server. • Port : The port number used by Accounting RADIUS server. Use the default 1813 or enter port number specified.
Page 24 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete the configuration. Dynamic WEP Settings : • WEP Key length : Check on the respected button to enable either 64bits or 128bits key length.
Page 25 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 26 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 27 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH In this function, the administrator can be allow or reject clients to access Virtual AP. Please click on Wireless -> Virtual AP Setup -> ACL Setup , click “Setup” of Virtual AP List and then ACL List Configuration page appears.
Page 28 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can create WDS Links for expanding wireless network via this page. Please click on Wireless -> WDS Setup and follow the below setting. MAC address : The MAC address of the Wireless interface is displayed here.
Page 29 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WDS Peer's MAC Address : Enter the MAC address of WDS peer. VLAN Tag(ID) : Virtual LAN, the system supports tagged VLAN with WDS. To enable VLAN function; valid values are from 0 to 4094; space is disabled.
Page 30 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH System time can be configured via this page where manual setting and NTP server configuration are both supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current time of the system.
Page 31 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can later obtain the geographical location of the system via the information configured here. The administrator also can change system password and configure system login methods. Please click System -> Management and follow the below settings.
Page 32 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH New Password : Please input the new password of administrator. Check New Password : Please input again the new password of administrator. Admin Login Methods : The admin manager can enable or disable system login methods, it also can change services port.
Page 33 Change these settings as described here and click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access WAS-103R's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats WAS-103R as an illegal website.
Page 34 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH SNMP is an application-layer protocol that provides a message of format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting.
Page 35 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH information. SNMP ro password : Enter the password that allows read-only access to the system's SNMP information. SNMP rw user : Enter the community strings that allows read/write access to the system's SNMP information.
Page 36 Upload button to upload the settings; the system will then be configured to the same settings as specified by the backup file. Restore To Factory Default : Click Restore button to load the factory default settings of WAS-103R, and then Success Message page appears. Click Reboot button to set default configuration.
Page 37: Firmware Upgrade
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can download the latest firmware from website and upgrade the system. Click “Browser...” button to search for the firmware file and click “Upgrade” for firmware upgrade. It might take a few minutes before upgrade process completes and the system needs to be restarted to activate the new firmware.
Page 38: Network Utility
ICMP packets. Packet loss statistics and latency time evaluation is provided after the test is completed. Trace Route : Allows tracing the hops from the WAS-103R to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host.
Page 39: Reboot
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH This function allows the administrator to safely restart the WAS-103R. Click Reboot to restart the system immediately, and the whole process will take about three minutes to complete. The Restart page as displayed below appears during the rebooting period. If turning off the power is necessary, please allow the restart process to be completed before turning off the system.
Page 40 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Detailed information on System and LAN Information can be reviewed via this page. System : Display the information of the system. System Name : The name of the system. Operating Mode : The mode currently in service.
Page 41 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Primary DNS : The current primary DNS server of the system. Secondary DNS : The current secondary DNS server of the system. Receive bytes :The current receive bytes of the LAN port. Receive packets : The current receive packets of the LAN port.
Page 42 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can obtain detailed wireless information and all associated clients status via this page. Wireless Information : Display the Virtual AP configuration information of the system. VAP : Display number of system's Virtual AP.
Page 43 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can obtain detailed Information such as WDS, Status, MAC Address, RSSI, and Last Tx Time of all WDS link via this page. WDS: WDS which the device is linked with. Status: Display WDS status.
Page 44 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The reported system events can be reviewed here. Date/ Time: The date and time when the event occurred. Hostname: The name of the host which records the event. It helps the administrator identify the source of the reported events.
Page 45: Wireless Status
When Hotspot mode is activated, the system can be configured as a Wireless Hotspot Gateway. This section provides information in configuring the Hotspot mode with graphical illustrations. WAS-103R provides functions as stated below where they can be configured via a user-friendly web based interface.
Page 46 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Basically, in general network environment, the main role of WAS-103R is a Gateway. It manages all the network from internal network to Internet. Then, the first step is to prepare an Internet connection from your ISP and connect it to the LAN1 or LAN2 port of WAS-103R Here is instruction for how to setup the WAN.
Page 47 This can be a DSL modem, Cable modem, or a WISP gateway router. WAS-103R will direct all the packets to the gateway if the destination host is not within the local network. Default Gateway is 192.168.1.1 Gateway IP address should be from the same address space (on the same network segment) as the WAS-103R's external network interface.
Page 48 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Password : Enter Password for PPPoE connection MTU : MTU stands for Maximum Transmission Unit. For PPPoE connections, you may need to set the MTU setting in order to work correctly with your ISP. Default is 1492 bytes.
Page 49 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Manual Address : Enter the MAC address registered with your ISP. WAN Connection WatchDog : The administrator can enable this function, the system will try to access remote IP Address. If the system can not reach these IP Address, system will be “Login Out” online users automatically with HotZONE authentication Enable Detection : Click on “Enable Detection”...
Page 50 Service Provider: Select the correct Service Provider from the drop-down list, here included are dyndns, dhs, ods and tzo embedded in the WAS-103R. Hostname: This field represents the Host Name you register to Dynamic-DNS service and expect to export to the world.
Page 51 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Here is the instruction for how to setup the local VLAN IP Address and Netmask. Please click on System -> VLAN , the VLAN List should be appear. Click “Edit” button on this page, the setup page should be appear. Follow the below setting.
Page 52 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH names to IP addresses. These fields identify the server IP addresses where the DNS requests are forwarded by the WAS-103R. DNS1 server IP is mandatory. It is used by the DNS Proxy and for the device management purpose.
Page 53 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The system manager can configure related wireless settings, General Settings, Advanced Settings, Virtual AP Setting, Security Settings, and Access Control Settings. The administrator can change the data transmission, channel and output power settings for the system. Please click on Wireless ->...
Page 54 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can change the Slot Time, ACK/CTS Timeout, RTS threshold and fragmentation threshold settings for the system. Please click on Wireless -> Advanced Setup and follow the below setting. Slot Time : Enter the desired slot time for the AP.
Page 55 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH network. DTIM Interval : Input the DTIM Interval that is generated within the periodic beacon at a specified frequency. Higher DTIM will let the wireless client save energy more, but the throughput will be growing worse.
Page 56 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can create Virtual AP via this page. Please click on Wireless -> Virtual AP Setup and follow the below setting. Enable : Click Enable button and Save button for creating Virtual AP VAP : Display number of system's Virtual AP.
Page 57 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH For each Virtual AP, administrators can configure general settings and security type. Click Wireless -> Virtual AP, click “Edit” of Virtual AP List and then Virtual AP Configuration page appears. ESSID : Extended Service Set ID indicates the SSID which the clients used to connect to the VAP. ESSID will determine the service type of a client which is assigned to the specified VAP.
Page 58: Configure Vlan Ip
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH VLAN Port : Select the desired VLAN Port from the drop-down list; the options are VLAN0 to VLAN7. The detailed VLAN Port setting need combine with section 4.1.3 Configure VLAN IP. Security Type : Select the desired security type from the drop-down list; the options are WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise and WEP 802.1X.
Page 59 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Cipher Suite : Check on the respected button to enable either AES or TKIP cipher suites; default is TKIP. Group Key Update Period : This time interval for re-keying GTK (broadcast/multicast encryption keys) in seconds. Enter the time-length required; the default time is 600 seconds.
Page 60 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Authentication RADIUS Server Settings : • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 61 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Accounting Server : Enter the IP address of the Accounting RADIUS server. • Port : The port number used by Accounting RADIUS server. Use the default 1813 or enter port number specified.
Page 62 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete the configuration. Dynamic WEP Settings : • WEP Key length : Check on the respected button to enable either 64bits or 128bits key length.
Page 63 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 64 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH • Authentication Server : Enter the IP address of the Authentication RADIUS server. • Port : The port number used by Authentication RADIUS server. Use the default 1812 or enter port number specified.
Page 65 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH In this function, the administrator can be allow or reject clients to access Virtual AP. Please click on Wireless -> Virtual AP Setup -> ACL Setup , click “Setup” of Virtual AP List and then ACL List Configuration page appears.
Page 66 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can create WDS Links for expanding wireless network via this page. Please click on Wireless -> WDS Setup and follow the below setting. Address : The MAC address of the Wireless interface is displayed here.
Page 67 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WDS Peer's MAC Address : Enter the MAC address of WDS peer. VLAN Port : Select the desired VLAN Port from the drop-down list; the options are VLAN0 to VLAN7. The detailed VLAN Port setting need combine with section 4.1.3 Configure VLAN IP.
Page 68 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH System time can be configured via this page where manual setting and NTP server configuration are both supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current time of the system.
Page 69 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can later obtain the geographical location of the system via the information configured here. The administrator also can change system password and configure system login methods. Please click System -> Management and follow the below settings.
Page 70 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH New Password : Please input the new password of administrator. Check New Password : Please input again the new password of administrator. Admin Login Methods : The admin manager can enable or disable system login methods, it also can change services port.
Page 71 Change these settings as described here and click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access WAS-103R's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats WAS-103R as an illegal website.
Page 72 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH SNMP is an application-layer protocol that provides a message of format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting.
Page 73 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH information. SNMP ro password : Enter the password that allows read-only access to the system's SNMP information. SNMP rw user : Enter the community strings that allows read/write access to the system's SNMP information.
Page 74 Upload button to upload the settings; the system will then be configured to the same settings as specified by the backup file. Restore To Factory Default : Click Restore button to load the factory default settings of WAS-103R, and then Success Message page appears. Click Reboot button to set default configuration.
Page 75: Firmware Upgrade
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can download the latest firmware from website and upgrade the system here. Click “Browser...” button to search for the firmware file and click “Upgrade” for the firmware upgrade. It might take a few minutes before the upgrade process completes and the system needs to be restarted to activate the new firmware.
Page 76: Network Utility
Trace Route : Allows tracing the hops from the WAS-103R device to a selected outgoing IP address. It should be used for finding the route taken by ICMP packets across the network to the destination host.
Page 77: Reboot
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH This function allows the administrator to safely restart the WAS-103R. Click Reboot to restart the system immediately, and the whole process will take about three minutes to complete. The Restart page as displayed below appears during the rebooting period. If turning off the power is necessary, please allow the restart process to be completed before turning off the system.
Page 78 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH This section is for administrators to pre-built authentication ticket for entire external Network. There are three types of time policy ticket can be generated (One Time, Multiple Times and Unlimited Until Lifetime). Please click on HotZONE ->...
Page 79 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Passcode Length: Specify desired passcode length between 8 to 32 for the ticket databases Time Policy: There are different timing policy of ticket for the ticket databases: One Time, Multiple Times and Unlimited Until Lifetime. Select One Time or Multiple Times, the sub-item should be shown-up. Fill desired service time on this blank field for the ticket databases.
Page 80 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH After generating access tickets databases, the administrator can verify information of ticket databases on “Ticket List” page. Click on HotZONE -> Ticket List, the Ticket List Page should be appear. Below depicts an example for Ticket List.
Page 81 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH File ID: Identifying ticket databases Description: Denote information of the ticket databases Effective Starting Time: Denote effective starting time of the ticket databases Effective Ending Time: Denote effective ending time of the ticket databases...
Page 82 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH After generating the ticket databases, the administrator can configure HotZONE authentication with ticket databases. Click HotZONE, the HotZONE Management Page should be appear. VLAN Port: Here should show VLAN0 to VLAN7. It indicates the system bind HotZONE to VLAN setting.
Page 83 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can create HotZONE with authentication. The default HotZONE is without authentication. Auth Type: Select “Auth Type” in “HotZONE With Tickets DB”, the “Ticket DB“ setting should show-up Tickets DB: This field should be display “Generate Ticket” setting link and ticket databases.
Page 84: Generate Access Ticket
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH If administrator select “HotZONE with Tickets DB” in “Auth Type” and without ticket DB selected. The users can not connect this HotZONE, because the passcode of ticket databases is not on this HotZONE.
Page 85 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Here are several user's login and logout pages that can be customized by administrator. Administrator can select Template Page or Upload Customize Page. Template Page: Choose Template Page to make a customized login page. Click select to pick up a color and then fill in all of the banks.
Page 86 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH If administrator select “Upload Page” in “Login Page Setting”, the Login.html and Logout.html must included in File List. The errormsg.html is optional The User-defined Login and Logout page must include the following HTML codes with red light to provide the necessary fields for Passcode, Effective Time Informations and ERROR Messages.
Page 87 Open an Internet browser and try to connect to any website. When the system enable secure HTTPS for Web server. A.) For the first time, if the WAS-103R is not using trusted SSL Certificate, there will be a “Certificate Error”, because the browser treats WAS-103R as an illegal website.
Page 88 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH If HotZONE Login Page doesn't appear in the browser, please “Turn Off Pop On Blocker”. More detailed see Appendix D Allowing Pop-Up Window When the system disable secure HTTPS for Web server, the HotZONE Login Page will appear in the browser.
Page 89 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can setting IP Filter via this page, Please click on Advance -> IP Filter and follow the below setting. Source Address/Mask : Enter the desired source IP address and netmask; the mask must be a plain number, i.e.
Page 90 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH In/Out : This option used for specialized packet alteration. The system support In (INPUT : for packets coming into the interface itself) or Out (FORWARD : for altering packets being routed through the interface) Protocol : This option allows you to select protocol type.
Page 91 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can setting MAC Filter via this page, Please click on Advance -> MAC Filter and follow the below setting. Action : Select the desired access control rule; the options are “Deny list” or “Disable”. Select “Deny list”, all of the MAC Address will be controlled in the MAC Filter List.
Page 92 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can set Static Routing Table via this page, Please click on Advance -> Routing and follow the below setting. Mode: Select desired status in “Enable” or “Disable” for routing rule Destination Net/Mask: Specify the destination network or IP address with netmask; the mask must be a plain number, i.e.
Page 93 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH A certain area in the network can be exposed to the Internet in a limited and controlled way for on-line game or video conferencing via this page. Please ensure the internal port to be used is not occupied by other applications.
Page 94 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The Private Port and Public Port can be different, but the port range need the same. example : Public Port is 10 to 20, the Private Port can be 30 to 40 or other 10 ports range.
Page 95 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The Demilitarized zone (DMZ) can be enabled and used as a place where services can be placed such as Web Servers, Proxy Servers, and E-mail Servers such that these services can still serve the local network and are at the same time isolated from it for additional security.
Page 96 Export Tickets: There are three methods to backup your information of ticket databases Export Ticket: The administrator can backup ticket database or copy to other WAS-103R. Select desired export Ticket DB and click “Export” button, the ticket databases (FileID_passcode.bin) will be download from system Generate List: There are three type of file list: XML, CSV and TXT(only Passcode).
Page 97 Starting Time, Effective Ending Time, Price and Available SSID on the screen. Administrator can print ticket on the screen for customer. Below depicts an example for printable tickets Passcode Number Import Tickets: Administrator can import other WAS-103R's ticket databases to system. Click “Import” to upload ticket databases...
Page 98 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH If you import ticket databases to system, the system show “The FileID already exist” error message. Please check the FileID of ticket databases on your system, maybe this databases' FileID already on your...
Page 99 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH WAS-103R can automatically send the notification of Users Log to 3 particular E-mail addresses. A trial email is provided by the system for validation Enabled: Click Enabled option to enable Notification E-mail Receiver E-mail Address (es): Up to 3 E-mail address can be set up to receive the notification. These are the receiver's E-mail address.
Page 100 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH After clicking “Save” button, you need to click “Send” button for verify your setting correctly. The system will show correlation message. Below depicts an example for success sending test. After Sending Interval, the system will send E-mail to receiver's E-mail address. Below depicts an example for E- mail's content of user log Date: Display the date of user log.
Page 101 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH This function provides certain free services or advertisement web pages for users to access the websites listed before login and authentication. Up to 20 address or domain names of the websites can be defined in this list. User without the network access right can still have a chance to experience the actual network service free of charge.
Page 102 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can view status of all online HotZONE users. Click HotZONE -> Online User, the page of Online User Information will appear. Below depicts an example for Online User Information. There provided information...
Page 103 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Detailed information on System, WAN and VLAN Information can be reviewed via this page. System : Display the information of the system. System Name : The name of the system. Operating Mode : The mode currently in service.
Page 104 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH VLAN Port: Select the desired VLAN Port from the drop-down list MAC Address : The MAC address of the VLAN port. IP Address : The IP address of the VLAN port. IP Netmask : The IP netmask of the VLAN port.
Page 105 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH PPPoE : Click Connect button to assigned IP address from PPPoE server. Disconnect button to release IP address of WAN port. The PPPoE always enable auto-connection function. If you click “Disconnect” button, the system will automatically get IP address and connect to PPPoE server.
Page 106 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can obtain detailed wireless information and all associated clients status via this page. Wireless Information : Display the Virtual AP configuration information of the system. VAP : Display number of system's Virtual AP.
Page 107 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Shows the current status of the leased IP addresses by the WAS-103R's DHCP server of VLAN port. The VLAN DHCP Clients shows from which VLAN port DHCP client which has specified MAC Address is connected.
Page 108 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The administrator can obtain detailed Information such as WDS, Status, MAC Address, RSSI, and Last Tx Time of all WDS link via this page. WDS: WDS which the device is linked with. Status: Display WDS status.
Page 109 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Displays the current device usage statistics and status of the system components in text area Select “NetStatus Information” on the drop-down list, the connection track list should show-up, the list can be updated using the Refresh button.
Page 110 Select “Route Information” on the drop-down list, the route table should show-up, the list can be updated using the Refresh button. WAS-103R examines the destination IP address of each data packet traveling through the system and chooses the appropriate interface to forward the packet to. The system choice depends on static routing rules – entries, which are registered in system routing table.
Page 111 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Select “ARP Table Information” on the drop-down list, the ARP table should show-up, the list can be updated using the Refresh button. ARP is used to associate each IP address to the unique hardware address (MAC) the devices. It is important to...
Page 112 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Select “Bridge Table Information” on the drop-down list, the bridge table should show-up, the list can be updated using the Refresh button. Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces. The Bridge Port always show “brv0”...
Page 113 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Select “Bridge MACs Information” on the drop-down list, all the list of MAC address should show-up on the bridge table, the list can be updated using the Refresh button. Bridge MACs shows to which Bridge Port the particular station is associated to - in other words from which Interface (Ethernet or wireless ) the network device (defined by MAC address) is reachable to the system while forwarding the packets to that port only (thus saving a lot of redundant copies and transmits).
Page 114 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH The reported system events can be reviewed here. Date/ Time: The date and time when the event occurred. Hostname: The name of the host which records the event. It helps the administrator identify the source of the reported events.
Page 115 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Windows XP Click Start -> Settings -> Control Panel, and then “Control Panel” window appears. Click on “Network Connections”, and then “Network Connections” window appears. Click right on “Local Area Connection”, and select Properties.
Page 116 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH In “Local Area Connection Properties” window, select “Internet Protocol (TCP/IP)” and click on Properties button. Select “Use the following IP address”, and type in IP address : 192.168.2.100 Subnet mask : 255.255.255.0...
Page 117 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Windows XP Repeater Step 1 to Step 2 on Appendix A Windows TCP/IP Setting, the “Local Area Connection Properties” window will appear. In “Local Area Connection Properties” window, click “Configure...” button on “Connect using” field.
Page 118 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Tag(ID) are 100 to 107 on WAS-103R) Not all of PC/NB support VLAN tag. If your PC/NB is not support VLAN tag, you must connect to WAS- 103R with VLAN switch. When your PC/NB configure VLAN tag setting and you connect to WAS-103Rwith...
Page 119 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Table C-1 Valid Characters for using WMI Block Field Valid Characters IP Address IP Format; 1-254 IP Netmask 128.0.0.0 ~ 255.255.255.252 IP Gateway IP Format; 1-254 Primary DNS IP Format; 1-254 Secondary DNS IP Format;...
Page 120 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH 0-9, A-Z, a-z Password ~ ! @ # $ % ^ * ( ) + - { } | : < > ? [ ] / ; ` , . = Table C-1...
Page 121 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Block Field Valid Characters 1 ~ 65535; Default is 80 HTTP Port 1 ~ 65535; Default is 443 HTTPS Port 1 ~ 65535; Default is 23 Telnet Port SSH Port 1 ~ 65535; Default is 22...
Page 122 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Block Field Valid Characters ACK Time 1 ~ 372 CTS Time 1 ~ 372 RSSI Threshold -128 ~ 127 Beacon Interval 10 ~ 5000 Date Beacon Rate 1 ~ 15 Fragment Threshold 256 ~ 2346...
Page 123: Hotzone Management
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Block Field Valid Characters WEP Key Update 0 ~ 99999999 ; default is 300, 0 is disable WDS Setup Peer's MAC Address 12 HEX chars VLAN Tag(ID) 0 ~ 4094 ; space is disable...
Page 124 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Block Field Valid Characters Effective From MM/DD/YYYY hh:mm Format MM : 1-12 DD: 1-31 YYYY: 1970-2500 Lifetime Time hh:0-23 mm: 0-59 Price 10 digital number Length : 64 0-9, A-Z, a-z Description space ~ ! @ # $ % ^ * ( ) _ + - { } | : <...
Page 125: Routing
User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Block Field Valid Characters Outgoing Port 1-65536; Default is 25 SMTP Auth Username Length : 1-32 0-9, A-Z, a-z SMTP Auth Password ~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . = IP Rule Setup Source/ Destination Address IP Format;...
Page 126 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH Popup is a window that opens automatically when you click on a link or visit/leave a web page. A pop-up blocker is a feature of a web browser (or one of its plugins) that blocks unwanted pop-up windows.
Page 127 User Manual WAS-103R Wireless Hotspot Gateway ENGLISH To disable popup blocking in Safari 4.x Launch Safari. From the Safari menu, ensure “Block Pop-Up Windows” is unchecked.
