  • Page 1 Wireless Hot Spot Gateway WAS-103R Quick Installation Guide Version 1.01...

  • Page 2: Package Contents

    For the time being, the Wireless Internet Access is almost a kind of value added service. By take advantage of PheeNet WAS-103R, the front desk operator does not have to have enough IT technology, just identify the customer grade, offer the appropriate Pre-set ticket, and then charge the money (or not).

  • Page 3: System Overview

    ADSL, or the port of a Cable Modem. The port will be used by WAN port. 4. Console : The Serial RS-232 DB9 cable attaches here. Rear Panel WAS-103R supports 1 RF Interface with 2 SMA connectors for Antenna connection.  LED Panel 1.

  • Page 4: Hardware Installation

    2. Connect WAS-103R to your outbound network device. Connect one end of the Ethernet cable to the LAN1 port of WAS-103R on the front panel. On your environment, connect the other end of the cable to the external Internet . The LAN1 LED indicator should be ON to indicate a proper connection.

  • Page 5: Getting Started

    Step 1. IP Segment Set-up for Administrator's PC Set the IP segment of the administrator's computer to be in the same range as WAS-103R for accessing the system. Do not duplicate the IP Address used here with IP Address of...

  • Page 6: Quick Setup

    Quick Installation Guide WAS-103R Wireless Hotspot Gateway Quick Setup WAS-103R is a two mode system which can be configured either as a Hotspot gateway or an access point as desired. This section provides a step-by-step configuration procedure for basic installation on AP Mode and Hotspot Mode Setup In AP Mode ...
  • Page 7 Quick Installation Guide WAS-103R Wireless Hotspot Gateway For security concern, it is strongly recommended to set up Security Type with WPA-SPK or WPA2-PSK for Virtual AP Step 6 : Restart System Click Reboot to activate all settings configured so far. The Reboot message will appear on the screen during the restarting process.
  • Page 8 Setup In Hotspot Mode  Step 0 : Access to WAS-103R The default VLAN IP Address is between  192.168.100.1 to 192.168.107.1 and the IP Netmask is 255.255.255.0 The administrator's PC need support VLAN.  Set VLAN ID 100 and set IP address automatically.
  • Page 9 Quick Installation Guide WAS-103R Wireless Hotspot Gateway Step 5 : Generate HotZONE Ticket 's Passcode Step 4 : Wireless Interface Click HotZONE -> Generate Ticket, and then Wireless General Setup  Generate Ticket Setup page appears. Select Click Wireless -> General Setup, and then desired Ticket Database for HotZONE.
  • Page 10 ESSID. 2. The client device will obtain an IP Address automatically via VLAN0's DHCP from WAS-103R. Open a WEB Browser on a client device, access any URL, and then the HotZONE 0 User Login Page will appears.
