PheeNet WAS-105R Quick Installation Manual

902.11n wireless hotspot gateway
Hide thumbs

Advertisement

Quick Links

Download this manual
802.11n Wireless
Hotspot Gateway
Quick Installation Guide Ver 0.0.1
WAS-105R

Advertisement

loading
Need help?

Need help?

Do you have a question about the WAS-105R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PheeNet WAS-105R

Summary of Contents for PheeNet WAS-105R

  • Page 1 802.11n Wireless Hotspot Gateway Quick Installation Guide Ver 0.0.1 WAS-105R...
  • Page 2 Copyright This document is the property of PheeNet Technology Corp. You may not copy, reproduce, distribute, publish, display, perform, or modify any part of this publication in any form or by any means without prior written permission from PheeNet Technology Corp. You may not alter or remove any copyright or other notice from copies of the content.
  • Page 3 Table of Contents 1. Before Your Start ..................... 1 2. Hardware Installation....................4 3. Getting Started ......................5 4. Quick Configuration ....................7 5. User Login ......................11 1. Before Your Start It is highly recommended to use all the supplies in the package instead of substituting any components by other suppliers to guarantee best performance.
  • Page 4 The WAS-105R is the most economical yet feature-rich Wireless Hotspot Gateway, targeting mini-size stores who want to provide small, single-point wireless Internet access service. WAS-105R is a perfect choice for beginners to run hotspot businesses. It does not cost a fortune to buy a pile of equipment, nor does it take the skills of an expert to glue multiple applications out of multiple freeware.
  • Page 5 Press and hold the Reset button for more than 10 seconds to reset the system to default configurations. The SYSTEM LED will be ON. 7. USB : For 3G adapter (option) Rear Panel 1. WAS-105R supports 1 RF interface with 2 SMA connectors for Antenna connection.
  • Page 6 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide LED Panel 1. Power : LED ON indicates power on, OFF indicates power off. 2. WAN1/WAN2/LAN : LED ON indicates connection, OFF indicates disconnection, FLASH indicates packets transmitting. 3. WLAN : LED ON indicates Wireless ready.
  • Page 7 3. Connect WAS-105R to your network device. Connect one end of the Ethernet cable to LAN port of WAS-105R on the front panel. Connect the other end of cable to a PC for configuring the system. The LAN LED indicator should be ON to indicate a proper connection.
  • Page 8 Connect the PC to the LAN(PoE) port of WAS-105R. An IP address will be assigned to the PC automatically via the WAS-105R. 2. Launch a web browser to access the web GUI of WAS-105R by entering “http://192.168.2.254” in the address field.
  • Page 9 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide...

  • Page 10: Configuration Steps

    WAS-105R provides wireless and wired network service with authentication required for clients in Service Domain. Clients in the each Service Domain are isolated with each other. WAS-105R supports 8 Service Domains, Domain-0 to Domain-7. Administrator can select authentication type on each Service Domain. If Authentication Required is enabled, the clients are required to get authenticated successfully before access the Internet.
  • Page 11 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide Before Hotspot service active, make sure the Local Time is correctly.
  • Page 12 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide Step 3 : Select Connection Type for WAN1 Port and Set DNS Server Click System -> WAN, the WAN Setup page will appear. Select the appropriate Connection Type for WAN1 port, there are four types of WAN1 connections to be selected from: Static IP, Dynamic IP, PPPoE Client and PPTP Client.
  • Page 13 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide Move AP0 Icon to Domain 1 window and click, the VAP0 Setup page will appear. Select desired wireless ESSID and related settings. Click Tool Icon on Domain 1 window, the Service Domain1 Setup page will appear. For each Service Domain(by default, authentication is None), authentication type can be selected in None, Pregenerated Ticket, On-Demand, Local Radius, Remote Radius Server and LDAP Server.
  • Page 14 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide Click Save button.
  • Page 15 WAS-105R IEEE802.11n Wireless Hotspot Gateway Quick Installation Guide Step 6 : Add Local Radius Accounts Click Service Domain -> Authentication -> Local Radius Accounts, the Local Radius Accounts Management page will appear. A new account can be added into the Local Radius Database. To add a account here, enter the Username(e.g.
  • Page 16 105R (e.g. AP00) and get associated with this ESSID. 2. The client device will obtain an IP address automatically via DHCP from WAS-105R. Open a web browser on a client device, access any URL, and then the Domain1 User Login Page will appear.
