FUNCTION
4 FUNCTION
DZOOM 0
AWB AUTO
PRIVACY OFF
DNR MIDDLE
MOTION OFF
RETURN
MWB
KELVIN MIDDLE
R-GAIN
B-GAIN
RETURN
18
DZOOM
0~112
AWB
AUTO
AUTO_H
AUTO_L
PRESET
MANUAL
AUTO-ext
If MANUAL mode is selected, define the following menu options:
KELVIN
10
R-GAIN
10
B-GAIN
Digital Zoom function zooms to the center of the
image by default. set the zoom level from 0~112.
White Balance is automatically adjusted.
White Balance is automatically adjusted when
the Color temperature is high.
White Balance is automatically adjusted when
the Color temperature is low.
White Balance is fixed with current setting.
White Balance is manually adjusted.
Select AUTO-ext mode when using external
lighting like a hallogen.
The color temperature level that will trigger the AWB.
Select from LOW / MIDDLE / HIGH
Adjusts the amount of red in the image.
Select from 0~20. The higher the number, the
image will appear red.
The lower the number, the image will appear
green.
Adjusts the amount of blue in the image.
Select from 0~20. The higher the number, the
image will appear blue.
The lower the number, the image will appear
yellow.
