Summary of Contents for Rosewill RNX-N150RT

  • Page 1 Wireless Router RNX-N150RT User Manual...

  • Page 2: Fcc Statement

    Specifications are subject to change without notice. is a registered trademark of Rosewill Limited. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Rosewill Limited.

  • Page 3: Ce Mark Warning

    FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations.

  • Page 4: Table Of Contents

    CONTENTS Package Contents ..........................1 Chapter 1. Introduction ........................2 Overview of the Router ....................... 2 Conventions ........................3 Main Features ........................3 Panel Layout ........................4 1.4.1 The Front Panel ...................... 4 1.4.2 The Rear Panel ...................... 5 Chapter 2. Connecting the Router ..................... 6 System Requirements ......................
  • Page 5 4.6.5 Wireless Statistics ....................46 DHCP ..........................47 4.7.1 DHCP Settings ......................47 4.7.2 DHCP Clients List ....................48 4.7.3 Address Reservation ....................49 Forwarding ........................50 4.8.1 Virtual Servers ......................50 4.8.2 Port Triggering ......................52 4.8.3 DMZ ........................54 4.8.4 UPnP ........................54 Security ..........................55 4.9.1 Basic Security .......................55 4.9.2 Advanced Security ....................57 4.9.3...
  • Page 6 4.15.2 No-ip.com DDNS ....................79 4.16 System Tools ........................80 4.16.1 Time Settings ......................80 4.16.2 Diagnostic ......................81 4.16.3 Firmware Upgrade ....................83 4.16.4 Factory Defaults ....................84 4.16.5 Backup & Restore ....................84 4.16.6 Reboot ........................85 4.16.7 Password ......................86 4.16.8 System log ......................86 4.16.9 Statistics .......................89 Appendix A: FAQ ..........................91 Appendix B: Configuring the PC .......................98 Appendix C: Specifications ......................102...

  • Page 7: Package Contents

     RNX-N150RT 150Mbps Wireless Lite-N Router  Power Adapter for RNX-N150RT 150Mbps Wireless Lite-N Router  Quick Installation Guide  Resource CD for RNX-N150RT 150Mbps Wireless Lite-N Router, including:  This Guide  Other Helpful Information  Note: Make sure that the package contains the above items. If any of the listed items are damaged or missing, please contact with your distributor.

  • Page 8: Chapter 1. Introduction

    Flexible Access Control AccessontroInstallation The RNX-N150RT 150Mbps Wireless Lite-N Router provides flexible access control, so that parents or network administrators can establish restricted access policies for children or staff. It also supports Virtual Server and DMZ host for Port Triggering, and then the network administrators can manage and monitor the network in real time with the remote management function.

  • Page 9: Main Features

    Wireless Router RNX-N150RT User Manual Main Features  Make use of IEEE 802.11n wireless technology to provide a wireless data rate of up to 150Mbps.  One 10/100M Auto-Negotiation RJ45 WAN port, four 10/100M Auto-Negotiation RJ45 LAN ports, supporting Auto MDI/MDIX.

  • Page 10: Panel Layout

    Wireless Router RNX-N150RT User Manual Panel Layout 1.3.1 The Front Panel Figure 1-1 Front Panel sketch The Router’s LEDs and the WPS/Reset Button are located on the front panel (View from left to right). Name Status Indication Power is off.

  • Page 11: The Rear Panel

     POWER: The Power socket is where you will connect the power adapter. Please use the power adapter provided with this RNX-N150RT 150Mbps Wireless Lite-N Router.  WAN: This WAN port is where you will connect the DSL/cable Modem, or Ethernet.

  • Page 12: Chapter 2. Connecting The Router

    Wireless Router RNX-N150RT User Manual Chapter 2. Connecting the Router System Requirements  Broadband Internet Access Service (DSL/Cable/Ethernet) One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the Router is  connected directly to the Ethernet.) PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors ...
  • Page 13 Connect the power adapter to the power socket on the Router, and the other end into an electrical outlet. Press the power switch, and then the router will start to work. Power on your PC and Cable/DSL Modem. Figure 2-1 Hardware Installation of the RNX-N150RT 150Mbps Wireless Lite-N Router - 7 -...

  • Page 14: Chapter 3. Quick Installation Guide

    RNX-N150RT User Manual Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your RNX-N150RT 150Mbps Wireless Lite-N Router using Quick Setup Wizard within minutes. TCP/IP Configuration The default IP address of the RNX-N150RT 150Mbps Wireless Lite-N Router is 192.168.1.1. And the default Subnet Mask is 255.255.255.0.
  • Page 15 Wireless Router RNX-N150RT User Manual Figure 3-1 Success result of Ping command  If the result displayed is similar to the Figure 3-2, it means the connection between your PC and the Router is failed. Figure 3-2 Failure result of Ping command...

  • Page 16: Quick Installation Guide

    192.168.1.2 ~ 192.168.1.254. Please keep in mind that if this is the second layer of your network (eg. Cable RNX-N150RT's WAN port plug into another router's LAN port, you may need to manually adjust the default IP for RNX-N150RT to avoid IP address conflict. Eg. Your current router's IP is already 192.168.1.1, then you will need to change to 192.168.x.1;...
  • Page 17 Wireless Router RNX-N150RT User Manual  Note: If the above screen does not pop-up, it means that your Web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it.
  • Page 18 Wireless Router RNX-N150RT User Manual Figure 3-7 Quick Setup - PPPoE  User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case sensitive. If you have difficulty with this process, please contact your ISP.
  • Page 19 Wireless Router RNX-N150RT User Manual Figure 3-9 Quick Setup – Wireless  Wireless Radio - Enable or disable the wireless radio choosing from the pull-down list. SSID - Enter a value of up to 32 characters. The same name of SSID (Service Set ...
  • Page 20 Wireless Router RNX-N150RT User Manual  WPA-PSK/WPA2-PSK - Select WPA based on pre-shared passphrase. PSK Password - You can enter ASCII or Hexadecimal characters.  For ASCII, the key can be made up of any numbers 0 to 9 and any letters A to Z, the length should be between 8 and 63 characters.

  • Page 21: Chapter 4. Configuring The Router

    Wireless Router RNX-N150RT User Manual Chapter 4. Configuring the Router This chapter will show each Web page's key functions and the configuration way. Login After your successful login, you will see the fifteen main menus on the left of the Web-based utility.

  • Page 22: Quick Setup

    Wireless Router RNX-N150RT User Manual Figure 4-2 Router Status Quick Setup Please refer to Section 3.2: "Quick Installation Guide". - 16 -...

  • Page 23: Wps

    Wireless Router RNX-N150RT User Manual This section will guide you to add a new wireless device to an existing network quickly by WPS (Wifi Protect Setup) function. Choose menu “WPS”, you will see the next screen (shown in Figure 4-3 ).
  • Page 24 Wireless Router RNX-N150RT User Manual  Note: When press and hold the WPS/Reset Button for more than 5 seconds, you will reset the router. Step 2: Press and hold the WPS Button of the adapter directly for 2 or 3 seconds.
  • Page 25 Wireless Router RNX-N150RT User Manual Step 2: For the configuration of the wireless adapter, please choose “Push the button on my access point” in the configuration utility of the WPS as below, and click Next. The WPS Configuration Screen of Wireless Adapter Step 3: Wait for a while until the next screen appears.
  • Page 26 Wireless Router RNX-N150RT User Manual Method Three: Step 1: Keep the default WPS Status as Enabled and click the Add device button in Figure 4-3, then the following screen will appear. Figure 4-4 Add A New Device Choose “Press the button of the new device in two minutes” and click Connect.
  • Page 27 Wireless Router RNX-N150RT User Manual The WPS Configuration Screen of Wireless Adapter II. By PIN If the new device supports Wi-Fi Protected Setup and the PIN method, you can add it to the network by PIN with the following two methods.
  • Page 28 Wireless Router RNX-N150RT User Manual Step 3: For the configuration of the wireless adapter, please choose “Enter a PIN into my access point or a registrar” in the configuration utility of the WPS as below, and click Next. The WPS Configuration Screen of Wireless Adapter ...
  • Page 29 Wireless Router RNX-N150RT User Manual The WPS Configuration Screen of Wireless Adapter  Note: The default PIN code of the Router can be found in its label or the WPS configuration screen as Figure 4-3. You will see the following screen when the new device successfully connected to the network.

  • Page 30: Network

    Wireless Router RNX-N150RT User Manual Network Figure 4-5 the Network menu There are three submenus under the Network menu (shown in Figure 4-5): LAN, WAN and MAC Clone. Click any of them, and you will be able to configure the corresponding function.

  • Page 31: Wan

    If your ISP provides the DHCP service, please choose Dynamic IP type, and the Router will automatically get IP parameters from your ISP. You can see the page as follows (Figure 4-7): 請修改為 RNX-N150RT WAN – Dynamic IP Figure 4-7 This page displays the WAN IP parameters assigned dynamically by your ISP, including IP address, Subnet Mask, Default Gateway, etc.
  • Page 32 Wireless Router RNX-N150RT User Manual  Use These DNS Servers - If your ISP gives you one or two DNS addresses, select Use These DNS Servers and enter the primary and secondary addresses into the correct fields. Otherwise, the DNS servers will be assigned dynamically from your ISP.
  • Page 33 Wireless Router RNX-N150RT User Manual  MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes. It is not recommended that you change the default MTU Size unless required by your ISP. ...
  • Page 34 Wireless Router RNX-N150RT User Manual  Dynamic IP - You can check this radio button to use Dynamic IP as the secondary connection to connect to the local area network provided by ISP. Static IP - You can check this radio button to use Static IP as the secondary connection ...
  • Page 35 Wireless Router RNX-N150RT User Manual Figure 4-10 PPPoE Advanced Settings MTU Size - The default MTU size is “1480” bytes, which is usually fine. It is not recommended  that you change the default MTU Size unless required by your ISP.
  • Page 36 Wireless Router RNX-N150RT User Manual If your ISP provides BigPond Cable (or Heart Beat Signal) connection, please select BigPond Cable. And you should enter the following parameters (Figure 4-11): Figure 4-11  User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive.
  • Page 37 Wireless Router RNX-N150RT User Manual access the Internet again. If you want your Internet connection keeps active all the time, please enter “0” in the Max Idle Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access disconnects.
  • Page 38 Wireless Router RNX-N150RT User Manual Figure 4-12 L2TP Settings User Name/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive.  Dynamic IP/ Static IP - Choose either as you are given by your ISP. Click the Connect button to connect immediately.
  • Page 39 Wireless Router RNX-N150RT User Manual automatically re-establish your connection as soon as you attempt to access the Internet again. If you wish to activate Connect on Demand, check the radio button. If you want your Internet connection to remain active at all times, enter 0 in the Max Idle Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet connection terminates.
  • Page 40 Wireless Router RNX-N150RT User Manual Figure 4-13 PPTP Settings User Name/Password - Enter the User Name and Password provided by your ISP. These  fields are case-sensitive. Dynamic IP/ Static IP - Choose either as you are given by your ISP and enter the ISP’s IP ...
  • Page 41 Wireless Router RNX-N150RT User Manual Click the Connect button to connect immediately. Click the Disconnect button to disconnect immediately.  Connect on Demand - You can configure the Router to disconnect from your Internet connection after a specified period of inactivity (Max Idle Time). If your Internet connection...

  • Page 42: Mac Clone

    Wireless Router RNX-N150RT User Manual 4.5.3 MAC Clone Choose menu “Network → MAC Clone”, you can configure the MAC address of the WAN on the screen below, Figure 4-14: Figure 4-14 MAC Address Clone Some ISPs require that you register the MAC Address of your adapter. Changes are rarely needed here.

  • Page 43: Wireless Settings

    Wireless Router RNX-N150RT User Manual 4.6.1 Wireless Settings Choose menu “Wireless → Wireless Settings”, you can configure the basic settings for the wireless network on this page. Figure 4-16 Wireless Settings SSID - Enter a value of up to 32 characters. The same name of SSID (Service Set ...
  • Page 44 Wireless Router RNX-N150RT User Manual Note Dialog  Note: Limited by local law regulations, version for North America does not have region selection option. Channel - This field determines which operating frequency will be used. The default channel  is set to Auto. so the AP will choose the best channel automatically. It is not necessary to change the wireless channel unless you notice interference problems with another nearby access point.

  • Page 45: Wireless Security

    Wireless Router RNX-N150RT User Manual  Enable WDS - Check this box to enable WDS. With this function, the Router can bridge two or more Wlans. If this checkbox is selected, you will have to set the following parameters as shown in Figure 4-17.
  • Page 46 Wireless Router RNX-N150RT User Manual Figure 4-18 Wireless Security  Disable Security - If you do not want to use wireless security, check this radio button. But it’s strongly recommended to choose one of the following modes to enable security.
  • Page 47 Wireless Router RNX-N150RT User Manual  Type - you can choose the type for the WEP security on the pull-down list. The default setting is Automatic, which can select Shared Key or Open System authentication type automatically based on the wireless station's capability and request.

  • Page 48: Wireless Mac Filtering

    Wireless Router RNX-N150RT User Manual  Radius Server IP - Enter the IP address of the Radius server.  Radius Port - Enter the port number of the Radius server.  Radius Password - Enter the password for the Radius server.
  • Page 49 Wireless Router RNX-N150RT User Manual Figure 4-22 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. The default setting is Disable.  MAC Address - The wireless station's MAC address that you want to filter.  Status - The status of this entry, either Enabled or Disabled.
  • Page 50 Wireless Router RNX-N150RT User Manual Click the Save button to save this entry. To modify or delete an existing entry: Click the Modify in the entry you want to modify. If you want to delete the entry, click the Delete.

  • Page 51: Wireless Advanced

    Wireless Router RNX-N150RT User Manual 4.6.4 Wireless Advanced Choose menu “Wireless → Wireless Advanced”, you can configure the advanced settings of your wireless network. Figure 4-24 Wireless Advanced  Transmit Power - Here you can specify the transmit power of Router. You can select High, Middle or Low which you would like.

  • Page 52: Wireless Statistics

    Wireless Router RNX-N150RT User Manual  Enable WMM - WMM function can guarantee the packets with high-priority messages being transmitted preferentially. It is strongly recommended.  Enable Short GI - This function is recommended for it will increase the data capacity by reducing the guard interval time ...

  • Page 53: Dhcp

    Wireless Router RNX-N150RT User Manual DHCP Figure 4-26 The DHCP menu There are three submenus under the DHCP menu (shown in Figure 4-26), DHCP Settings, DHCP Clients List and Address Reservation. Click any of them, and you will be able to configure the corresponding function.

  • Page 54: Dhcp Clients List

    Wireless Router RNX-N150RT User Manual  Address Lease Time - The Address Lease Time is the amount of time a network user will be allowed connection to the Router with their current dynamic IP Address. Enter the amount of time in minutes and the user will be "leased" this dynamic IP Address. After the time is up, the user will be automatically assigned a new dynamic IP address.

  • Page 55: Address Reservation

    Wireless Router RNX-N150RT User Manual 4.7.3 Address Reservation Choose menu “DHCP → Address Reservation”, you can view and add a reserved address for clients via the next screen (shown in Figure 4-29).When you specify a reserved IP address for a PC on the LAN, that PC will always receive the same IP address each time when it accesses the DHCP server.

  • Page 56: Forwarding

    Wireless Router RNX-N150RT User Manual Modify the information. Click the Save button. Click the Enable/Disabled All button to make all entries enabled/disabled. Click the Delete All button to delete all entries. Click the Next button to go to the next page and Click the Previous button to return the previous page.
  • Page 57 Wireless Router RNX-N150RT User Manual  Service Port - The numbers of External Ports. You can type a service port or a range of service ports (in XXX – YYY format, XXX is the start port number, YYY is the end port number).

  • Page 58: Port Triggering

    Wireless Router RNX-N150RT User Manual Click the Save button. Click the Enable/Disabled All button to make all entries enabled/disabled. Click the Delete All button to delete all entries. Click the Next button to go to the next page and click the Previous button to return the previous page.
  • Page 59 Wireless Router RNX-N150RT User Manual Incoming Ports Range - The port or port range used by the remote system when it  responds to the outgoing request. A response using one of these ports will be forwarded to the PC that triggered this rule. You can input at most 5 groups of ports (or port sections).

  • Page 60: Dmz

    Wireless Router RNX-N150RT User Manual Click the Save button. Click the Enable All button to make all entries enabled. Click the Disabled All button to make all entries disabled. Click the Delete All button to delete all entries.  Note: When the trigger connection is released, the corresponding opening ports will be closed.

  • Page 61: Security

    Wireless Router RNX-N150RT User Manual Figure 4-37 UPnP  Current UPnP Status - UPnP can be enabled or disabled by clicking the Enable or Disable button.  Current UPnP Settings List - This table displays the current UPnP information. ...
  • Page 62 Wireless Router RNX-N150RT User Manual Figure 4-39 Basic Security Firewall - A firewall protects your network from the outside world. Here you can enable or  disable the Router’s firewall. SPI Firewall - SPI (Stateful Packet Inspection, also known as dynamic packet filtering) ...

  • Page 63: Advanced Security

    Wireless Router RNX-N150RT User Manual gateway to support address and port translation for certain application layer "control/data" protocols such as FTP, TFTP, H323 etc. FTP ALG - To allow FTP clients and servers to transfer data across NAT, keep the ...

  • Page 64: Local Management

    Wireless Router RNX-N150RT User Manual  DoS protection - Denial of Service protection. Check the Enable or Disable button to enable or disable the DoS protection function. Only when it is enabled, will the flood filters be enabled.  Note: Dos Protection will take effect only when the Traffic Statistics in “System Tool →...

  • Page 65: Remote Management

    Wireless Router RNX-N150RT User Manual Figure 4-41 Local Management By default, the radio button “All the PCs on the LAN are allowed to access the Router's Web-Based Utility” is checked. If you want to allow PCs with specific MAC Addresses to access the Setup page of the Router's Web-Based Utility locally from inside the network, check the radio button “Only the PCs listed can browse the built-in web pages to perform Administrator...
  • Page 66 Wireless Router RNX-N150RT User Manual Figure 4-42 Remote Management  Web Management Port - Web browser access normally uses the standard HTTP service port 80. This Router's default remote management web port number is 80. For greater security, you can change the remote management web port to a custom port by entering that number in the box provided.

  • Page 67: Parental Control

    Wireless Router RNX-N150RT User Manual 4.10 Parental Control Choose menu “Parental Control”, you can configure the parental control in the screen as shown in Figure 4-43. The Parental Control function can be used to control the internet activities of the child, limit the child to access certain websites and restrict the time of surfing.
  • Page 68 Wireless Router RNX-N150RT User Manual Enter the domain name of the website (e.g. www.google.com) in the Allowed Domain Name field. Select from the Effective Time drop-down list the schedule (e.g. Schedule_1) you want the entry to take effect. If there are not suitable schedules for you, click the Schedule in red below to go to the Advance Schedule Settings page and create the schedule you need.

  • Page 69: Access Control

    Wireless Router RNX-N150RT User Manual 1. Click “Parental Control” menu on the left to enter the Parental Control Settings page. Check Enable and enter the MAC address 00-11-22-33-44-BB in the MAC Address of Parental PC field. 2. Click “Access Control → Schedule” on the left to enter the Schedule Settings page.

  • Page 70: Rule

    Wireless Router RNX-N150RT User Manual 4.11.1 Rule Choose menu “Access Control → Rule”, you can view and set Access Control rules in the screen as shown in Figure 4-47. Figure 4-47 Access Control Rule Management  Enable Internet Access Control - Select the check box to enable the Internet Access Control function, so the Default Filter Policy can take effect.
  • Page 71 Wireless Router RNX-N150RT User Manual 4. Select a target from the Target drop-sown list or choose “Click Here To Add New Target List”. 5. Select a schedule from the Schedule drop-down list or choose “Click Here To Add New Schedule”.

  • Page 72: Host

    Wireless Router RNX-N150RT User Manual 3. Click “Access Control → Schedule” in the left to enter the Schedule Settings page. Add a new entry with the Schedule Description is Schedule_1, Day is Sat and Sun, Start Time is 1800 and Stop Time is 2000.
  • Page 73 Wireless Router RNX-N150RT User Manual Click the Add New… button. In the Mode field, select IP Address or MAC Address.  If you select IP Address, the screen shown is Figure 4-50. 1) In Host Description field, create a unique description for the host (e.g. Host_1).

  • Page 74: Target

    Wireless Router RNX-N150RT User Manual In Host Description field, create a unique description for the host (e.g. Host_1). In MAC Address field, enter 00-11-22-33-44-AA. Click Save to complete the settings. Then you will go back to the Host Settings page and see the following list.
  • Page 75 Wireless Router RNX-N150RT User Manual 2) In Domain Name field, enter the domain name in the blank. You can enter 4 domain names. Click the Save button. Click the Delete All button to delete all the entries in the table.

  • Page 76: Schedule

    Wireless Router RNX-N150RT User Manual 1. Click Add New… button in Figure 4-52 to enter the Add or Modify an Access Target Entry page. 2. In Mode field, select Domain Name from the drop-down list. 3. In Target Description field, create a unique description for the target (e.g. Target_1).
  • Page 77 Wireless Router RNX-N150RT User Manual Click the Delete All button to delete all the entries in the table. Click the Next button to go to the next page, or click the Previous button return to the previous page. Figure 4-56 Advanced Schedule Settings For example: If you desire to restrict the internet activities of host with MAC address 00-11-22-33-44-AA to access www.google.com only from 18:00 to 20:00 on Saturday and...

  • Page 78: Static Routing

    Wireless Router RNX-N150RT User Manual 4.12 Static Routing Choose menu “Static Routing”, and you can configure the static route in the next screen, shown in Figure 4-57. A static route is a pre-determined path that network information must travel to reach a specific host or network.

  • Page 79: Bandwidth Control

    Wireless Router RNX-N150RT User Manual Click the Save button to make the entry take effect. Click the Delete button to delete the entry. Click the Enable All button to enable all the entries. Click the Disable All button to disable all the entries.

  • Page 80: Rules List

    Wireless Router RNX-N150RT User Manual 4.13.2 Rules List Choose menu “Bandwidth Control → Rules List”, you can view and configure the Bandwidth Control rules in the screen below. Figure 4-61 Bandwidth Control Rules List  Description - This is the information about the rules such as address range.

  • Page 81: Binding Settings

    Wireless Router RNX-N150RT User Manual Figure 4-62 Bandwidth Control Rule Settings Step 3: Click the Save button. 4.14 IP& MAC Binding Figure 4-63 the IP & MAC Binding menu There are two submenus under the IP &MAC Binding menu (shown in Figure 4-63): Binding Setting and ARP List.
  • Page 82 Wireless Router RNX-N150RT User Manual Figure 4-64 Binding Settings  MAC Address - The MAC address of the controlled computer in the LAN.  IP Address - The assigned IP address of the controlled computer in the LAN.  Bind - Check this option to enable ARP binding for a specific device.

  • Page 83: Arp List

    Wireless Router RNX-N150RT User Manual To find an existing entry, follow the steps below. Click the Find button as shown in Figure 4-64. Enter the MAC Address or IP Address. Click the Find button in the page as shown in Figure 4-66.

  • Page 84: Dynamic Dns

    Wireless Router RNX-N150RT User Manual  Configure - Load or delete an item. Load - Load the item to the IP & MAC Binding list.  Delete - Delete the item.  Click the Bind All button to bind all the current items, available after enable.
  • Page 85 Wireless Router RNX-N150RT User Manual Figure 4-68 Dyndns.org DDNS Settings To set up for DDNS, follow these instructions: Type the User Name for your DDNS account. Type the Password for your DDNS account. Type the Domain Name you received from dynamic DNS service provider here.

  • Page 86: No-Ip.com Ddns

    Wireless Router RNX-N150RT User Manual 4.15.2 No-ip.com DDNS If you select www.no-ip.com, the page will appear as shown in Figure 4-69. Figure 4-69 No-ip.com DDNS Settings To set up for DDNS, follow these instructions: Type the User Name for your DDNS account.

  • Page 87: System Tools

    Wireless Router RNX-N150RT User Manual 4.16 System Tools Figure 4-70 The System Tools menu Choose menu “System Tools”, you can see the submenus under the main menu: Time Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot, Password, System Log and Statistics. Click any of them, and you will be able to configure the corresponding function.

  • Page 88: Diagnostic

    Wireless Router RNX-N150RT User Manual  NTP Server Prior - Enter the address for the NTP Server, then the Router will get the time from the NTP Server preferentially. In addition, for some built-in common NTP Servers, the Router can get time automatically once it connects the Internet.
  • Page 89 Wireless Router RNX-N150RT User Manual Figure 4-72 Diagnostic Tools  Diagnostic Tool - Check the radio button to select one diagnostic too.  Ping - This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a given host or gateway.

  • Page 90: Firmware Upgrade

    Wireless Router RNX-N150RT User Manual  Ping Timeout - Set the waiting time for the reply of each Ping packet. If there is no reply in the specified time, the connection is overtime.  Traceroute Max TM - The max number of hops for a Traceroute connection.

  • Page 91: Factory Defaults

    Wireless Router RNX-N150RT User Manual 2. Type the path and file name of the update file into the File field. Or click the Browse button to locate the update file. 3. Click the Upgrade button.  Note: New firmware versions are posted at our website and can be downloaded for free. There is no need to upgrade the firmware unless the new firmware has a new feature you want to use.

  • Page 92: Backup & Restore

    Wireless Router RNX-N150RT User Manual 4.16.5 Backup & Restore Choose menu “System Tools → Backup & Restore”, you can save the current configuration of the Router as a backup file and restore the configuration via a backup file as shown in Figure 4-76.

  • Page 93: Password

    Wireless Router RNX-N150RT User Manual  Upgrade the firmware of the Router (system will reboot automatically).  Restore the Router's settings to factory defaults (system will reboot automatically).  Update the configuration with the file (system will reboot automatically. 4.16.7 Password Choose menu “System Tools →...
  • Page 94 Wireless Router RNX-N150RT User Manual Figure 4-79 System Log  Auto Mail Feature - Indicates whether auto mail feature is enabled or not.  Mail Settings - Set the receiving and sending mailbox address, server address, validation information as well as the timetable for Auto Mail Feature, as shown in Figure 4-80.
  • Page 95 Wireless Router RNX-N150RT User Manual Figure 4-80 Mail Account Settings From - Your mail box address. The Router would connect it to send logs.  To - Recipient’s address. The destination mailbox where the logs would be received.  SMTP Server - Your smtp server. It corresponds with the mailbox filled in the From ...

  • Page 96: Statistics

    Wireless Router RNX-N150RT User Manual Click Back to return to the previous page.  Log Type - By selecting the log type, only logs of this type will be shown.  Log Level - By selecting the log level, only logs of this level will be shown.
  • Page 97 Wireless Router RNX-N150RT User Manual Packets Statistics Interval （5-60） - The default value is 10. Select a value between 5 and  60 seconds in the pull-down list. The Packets Statistic interval indicates the time section of the packets statistic.

  • Page 98: Appendix A: Faq

    Wireless Router RNX-N150RT User Manual Appendix A: FAQ How do I configure the Router to access the Internet by ADSL users? First, configure the ADSL Modem configured in RFC1483 bridge model. Connect the Ethernet cable from your ADSL Modem to the WAN port on the Router. The telephone cord plugs into the Line port of the ADSL Modem.
  • Page 99 Wireless Router RNX-N150RT User Manual If you are a Cable user, please configure the Router following the above steps. How do I configure the Router to access the Internet by Ethernet users? Log in to the Router, click the “Network” menu on the left of your browser, and click "WAN"...
  • Page 100 Wireless Router RNX-N150RT User Manual Figure A-4 Virtual Servers - 94 -...
  • Page 101 Wireless Router RNX-N150RT User Manual Figure A-5 Add or Modify a Virtual server Entry  Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. How to enable DMZ Host: Log in to the Router, click the “Forwarding” menu on the left of your browser, and click "DMZ"...
  • Page 102 Wireless Router RNX-N150RT User Manual Figure A-7 Basic Security 4. I want to build a WEB Server on the LAN, what should I do? Because the WEB Server port 80 will interfere with the WEB management port 80 on the Router, you must change the WEB management port number to avoid interference.
  • Page 103 Wireless Router RNX-N150RT User Manual  Note: If the above configuration takes effect, configure to the Router by typing 192.168.1.1:88 (the Router’s LAN IP address: Web Management Port) in the address field of the Web browser. Log in to the Router, click the “Forwarding” menu on the left of your browser, and click the "Virtual Servers"...
  • Page 104 Wireless Router RNX-N150RT User Manual If the wireless connection is ready, but you can’t access the Router, check the IP Address of your wireless stations. - 98 -...

  • Page 105: Appendix B: Configuring The Pc

    Wireless Router RNX-N150RT User Manual Appendix B: Configuring the PC In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows XP. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if necessary.
  • Page 106 Wireless Router RNX-N150RT User Manual Figure B-2 The following TCP/IP Properties window will display and the IP Address tab is open on this window by default. Now you have two ways to configure the TCP/IP protocol below:  Setting IP address automatically...
  • Page 107 Wireless Router RNX-N150RT User Manual Figure B-3  Note: For Windows 98 OS or before, the PC and Router may need to be restarted.  Setting IP address manually Select Use the following IP address radio button. And the following items available.
  • Page 108 Wireless Router RNX-N150RT User Manual Figure B-4 Now, click OK to keep your settings. - 102 -...

  • Page 109: Appendix C: Specifications

    Wireless Router RNX-N150RT User Manual Appendix C: Specifications General IEEE 802.3, 802.3u, 802.11b, 802.11g Standards Compatible with 802.11n Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP One 10/100M Auto-Negotiation WAN RJ45 port, Four 10/100M Ports Auto-Negotiation LAN RJ45 ports supporting Auto MDI/MDIX 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω...

  • Page 110: Appendix D: Glossary

    Wireless Router RNX-N150RT User Manual Appendix D: Glossary 802.11b - The 802.11b standard specifies a wireless networking at 11 Mbps using  direct-sequence spread-spectrum (DSSS) technology and operating in the unlicensed radio spectrum at 2.4GHz, and WEP encryption for security. 802.11b networks are also referred to as Wi-Fi networks.
  • Page 111 Thank you for purchasing a quality Rosewill Product. Please register your product at: www.rosewill.com for complete warranty information and future support for your product. Rosewill Customer Service Hotline: 1-800-575-9885 Rosewill Customer Service Support: techsupport@rosewill.com...
