Summary of Contents for Rosewill RNX-G400
- Page 1 54M Wireless AP Router RNX-G400 User Manual...
- Page 2 54M Wireless AP Router RNX-G400 Connecting the Broadband Router Prior to connecting the hardware, make sure to power off your Ethernet device, Cable/ADSL modem and Broadband Router. Then follow the steps below to connect the related devices. Connect your computer to the LAN port.
- Page 3 54M Wireless AP Router RNX-G400 1.1 Windows 2000 Please follow the steps below to setup your computer: 1. Go to Start Settings Control Panel 2. Double click the icon Network and Dial-up Connections 3. Highlight the icon Local Area Connection, right click your mouse, Click Properties...
- Page 4 54M Wireless AP Router RNX-G400 4. Highlight Internet Protocol (TCP/IP), then press Properties button 5. Choose Obtain an IP address automatically and Obtain DNS server address automatically, then press OK to close the Internet Protocol (TCP/IP) Properties window Figure 2-3...
- Page 5 54M Wireless AP Router RNX-G400 6. Press OK to close the Local Area Connection Properties window 1.2 Windows XP/2003 Please follow the steps below to setup your computer: 1. Go to Start Settings Control Panel 2. Click Network and Internet Connections...
- Page 6 54M Wireless AP Router RNX-G400 3. Click Network Connections 4. Highlight the icon Local Area Connection, right click your mouse, Click Properties Figure 2-7 Figure 2-8 User Manual...
- Page 7 54M Wireless AP Router RNX-G400 User Manual 5. Highlight Internet Protocol (TCP/IP), then press Properties button Figure 2-9 6. Choose Obtain an IP address automatically and Obtain DNS server address automatically, then press OK to close the Internet Protocol (TCP/IP) Properties window...
- Page 8 54M Wireless AP Router RNX-G400 User Manual 7. Press OK to close the Local Area Connection Properties window Figure 2-11...
- Page 9 54M Wireless AP Router RNX-G400 Connection the Router After configuring the TCP/IP protocol, use the ping command to verify if the computer can communicate with the Router. To execute the ping command, open the DOS window and ping the IP address of the Broadband Router at the DOS prompt : To execute ping command, open the DOS window by clicking on Start ->...
-
Page 10: Accessing The Web-Based Configuration Utility
54M Wireless AP Router RNX-G400 Accessing the Web-Based Configuration Utility Launch the Web browser and type http://192.168.1.1 in the Address field and click Enter. After connected to the device, you will be prompted to enter the username and password. Type “guest” in the User Name field, the default password is “guest”. - Page 11 54M Wireless AP Router RNX-G400 PPPoE Input your PPPoE Account and Password you get from your ISP. Static IP Figure 5-2 Figure 4-3 User Manual...
- Page 12 System Overview page of the router’s Web -based configuration utility. The WAN Interface group will display the current connection information. Congratulations! You’ve successfully configured your Router. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product. User Manual...
- Page 13 54M Wireless AP Router RNX-G400 User Manual...
