SECTION 5.
[CHASSIS PARTS]
REF ORDER
NO. NO.
W1** 8900016290 OPC-1706
W3** 8970025620 1.5D 150MM (SX3615 CH 6G3)
W5** 8970025590 1.5D 130MM (SX3615 CH 6G4)
W7** 8970025600 1.5D 110MM (SX3615 CH 6G2)
W9** 8970025211 1.5DCOAXIAL250MM-1 C31/C31
W11** 8970024982 1.5DCOAXIAL200MM-2 C31/C31
W13** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W15** 8970025630 1.5D 420MM (SX3615 CH 6G5)
W17** 8970025640 1.5D 570MM (SX3615 CH 6G6)
W19** 8970024083 1.5DCOAXIAL180MM-3 C31/C31
W21** 8970024762 1.5DCOAXIAL130MM-2 C31/C31
W23** 8970025610 1.5DCOAXIAL1100MM C31/C31
W25** 8970024232 1.5DCOAXIAL390MM-2 (F/I)C31/C31
W27** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W29** 8970025211 1.5DCOAXIAL250MM-1 C31/C31
W31** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W33** 8970025211 1.5DCOAXIAL250MM-1 C31/C31
W35** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W37** 8970024461 1.5DCOAXIAL570MM-1 (J) C31/C31
W39** 8970024992 1.5DCOAXIAL650MM-2 C31/C31
W41** 8970024461 1.5DCOAXIAL570MM-1 (J) C31/C31
W43** 8970024412 1.5DCOAXIAL330MM-2 (T) C31/C31
W45** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W47** 8970024442 1.5DCOAXIAL510MM-2 (B) C31/C31
W49** 8970024202 1.5DCOAXIAL300MM-2 C31/C31
W51** 8970024232 1.5DCOAXIAL390MM-2 (F/I)C31/C31
W61** 8900013032 OPC-1346R-1
W62** 8900013042 OPC-1347R-1
W63** 8900013052 OPC-1348R-1
W81** 8910000390 FFC-1040 (P0.5N30L150)
W82** 8910000360 FFC-1034 (P1.0N12L50)
W83** 8900016150 OPC-1679 (P0.5N30L80)
W84** 8900018010 OPC-994A (P0.5N30L220)
W85** 8910000390 FFC-1040 (P0.5N30L150)
W86** 8900009231 OPC-908A (P1N10L60)
W87** 8910000410 FFC-1043 (P1.0N10L190)
W88** 8910000350 FFC-1033 (P0.5N30L270)
W89** 8910000350 FFC-1033 (P0.5N30L270)
W90** 8900018010 OPC-994A (P0.5N30L220)
W91** 8900018010 OPC-994A (P0.5N30L220)
W92** 8910000440 FFC-1047 (P0.5N40L120)
W93** 8900016150 OPC-1679 (P0.5N30L80)
W94** 8900017510 OPC-1851 (P1N24L380)
W95** 8900017090 OPC-1826 (P1N10L120)
W96** 8910000430 FFC-1046 (P0.5N50L190)
W97** 8910000420 FFC-1044 (P0.5N20L190)
W101 8900021920 OPC-2351 <SSC>
W102 8900021920 OPC-2351 <SSC>
W103 8900021920 OPC-2351 <SSC>
W104 8900021920 OPC-2351 <SSC>
W105 8900021920 OPC-2351 <SSC>
W106 8900021920 OPC-2351 <SSC>
W111** 8920001190 CAB-1153 (SX3615 NO.1)
W121** 8600037470 SX3615 P121*P122CH (6G1) NO.2
W131** 8600037480 SX3615 P131*P132CH NO.3
W141** 8600037490 SX3615 P141*P142CH NO.4
W151** 8600037500 SX3615 P151*P152CH NO.5
W161** 8600037510 SX3615 P161*P162*P163CH NO.6
W171** 8600037520 SX3615 P171*P172CH NO.7
W181** 8600037530 SX3615 P181*P182*P183CH NO.8
W191** 8600037540 SX3615 P191*P192CH NO.9
W211** 8920001310 CAB-1168 <GBE>
W221** 8600037570 SX3615 P221*P222CH NO.12
W231** 8600037580 SX3615 P231*P232CH NO.13
W241** 8600037060 SX2590 P119*P120CH
W251** 8900013060 OPC-1349
SP1 2510001390 2844 SP BOX
MF1 2710000520 SB0812H-ICOM-00
EP1 6910016052 FP2212B-2 FCC ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016062 FP2212C-2 RTTE ROHS
6910016052 FP2212B-2 FCC ROHS
6910016062 FP2212C-2 RTTE ROHS
EP2 6910011941 ZCAT2436-1330A-BK
EP7 6910011941 ZCAT2436-1330A-BK
EP8 6910011960 ZCAT1518-0730
MP1 8010023200 3615 CHASSIS
MP2 8210030220 3615 REAR PANEL
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#22]
[#23]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CHASSIS PARTS]
REF ORDER
QTY.
NO. NO.
1 MP3 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030301 2590 SIDE PANEL (B)-1
1 8210030291 2590 SIDE PANEL (A)-1
1 8210030291 2590 SIDE PANEL (A)-1
1 MP4 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010701 3615 L-COVER (A)-1
1 8110010691 3615 L-COVER-1
1 8110010691 3615 L-COVER-1
1 MP5 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010711 3615 U-COVER-1
1 8110010681 3615 UA-COVER-1
1 8110010681 3615 UA-COVER-1
1 MP6 8510021350 3615 LOGIC COVER
1 MP7 8510021380 3615 SCOPE COVER Y2190
1 MP8 8510021360 3615 RF COVER
1 MP9 8510021390 3615 OSC COVER Y2188
MP10 8510021400 3615 LOCAL COVER
1
1 MP11 8510021340 3615 LOGIC CASE
1 MP12 8510021370 3615 SCOPE CASE Y2189
1 MP13 8510015851 2590 FILTER CASE-1
1 MP14 8930074921 3009 A-SP ANGLE-1 Y1075A
1 MP15 8930061281 2590 ANT ANGLE-1
1 MP16 8930090900 3615 CHA-PLATE Y2187
1 MP18 8310085770 3615 SERIAL PLATE M150X2
1 8310085770 3615 SERIAL PLATE M150X2
1 MP19 8930073900 3009 SPACER
1 MP20 8930011680 RUBBER LEG (G)
1 MP21 8930091360 2590 MAIN STAND (B) ASSEMBLY
1 8930091360 2590 MAIN STAND (B) ASSEMBLY
1 8930091360 2590 MAIN STAND (B) ASSEMBLY
1 8930091360 2590 MAIN STAND (B) ASSEMBLY
8930091360 2590 MAIN STAND (B) ASSEMBLY
1
1 8930091360 2590 MAIN STAND (B) ASSEMBLY
1 8930091360 2590 MAIN STAND (B) ASSEMBLY
1 8930091350 2590 MAIN STAND (A) ASSEMBLY
1 8930091350 2590 MAIN STAND (A) ASSEMBLY
1 MP23 8930090880 3615 A-NET
1 MP24 8930090890 3615 B-NET
1 MP29 8930075530 2590 RUBBER (A) (TOT)S
1 MP30* 8930035230 1546 TR-A CLIP
1 MP31 8930091200 71781-0001
1 MP101 8810008661 PHBT M3 X 8 NI-ZC3
1 MP102 8810008661 PHBT M3 X 8 NI-ZC3
1 MP103 8810008661 PHBT M3 X 8 NI-ZC3
1 MP104 8810008661 PHBT M3 X 8 NI-ZC3
1 MP105 8810008661 PHBT M3 X 8 NI-ZC3
1 MP106 8820001760 TAPPING SCREW WH B0 3X8 NI-ZC3 (BT)
1 MP107 8820001760 TAPPING SCREW WH B0 3X8 NI-ZC3 (BT)
MP108 8810008661 PHBT M3 X 8 NI-ZC3
1
1 MP109 8810008661 PHBT M3 X 8 NI-ZC3
1 MP110 8810008661 PHBT M3 X 8 NI-ZC3
MP111 8810008661 PHBT M3 X 8 NI-ZC3
1 MP112 8810008661 PHBT M3 X 8 NI-ZC3
MP113 8810008661 PHBT M3 X 8 NI-ZC3
1 MP114 8810008661 PHBT M3 X 8 NI-ZC3
MP115 8810008661 PHBT M3 X 8 NI-ZC3
1 MP116 8810008661 PHBT M3 X 8 NI-ZC3
1 MP117 8810008661 PHBT M3 X 8 NI-ZC3
1 MP118 8810008661 PHBT M3 X 8 NI-ZC3
1 MP119 8810009991 PHBT M3 X 8 NI-ZK3
1 MP120 8810008661 PHBT M3 X 8 NI-ZC3
1 MP121 8810008631 PHBT M3 X 6 NI-ZC3
1 MP122 8810008661 PHBT M3 X 8 NI-ZC3
MP123 8810008631 PHBT M3 X 6 NI-ZC3
1
1 MP124 8810009311 FLAT BT M3 X 6 NI-ZC3
1 MP125 8810009391 PHBT M3 X18 NI-ZC3
1 MP126 8810009991 PHBT M3 X 8 NI-ZK3
1 MP127 8810008661 PHBT M3 X 8 NI-ZC3
MP128 8810000391 PH M4 X12 ZC3
1 MP129 8810008451 BIND M4 X 8 ZK3
1 MP131 8810008451 BIND M4 X 8 ZK3
MP132 8810008451 BIND M4 X 8 ZK3
5-1
DESCRIPTION QTY.
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#22]
[#23]
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#22]
[#23]
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#22]
[#23]
[#22]
[#23]
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#22]
[#23]
17
19
12
12
18
11
11
13
14
2
2
2
2
2
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
2
2
2
2
2
2
2
2
2
2
1
3
3
2
2
5
7
7
8
8
4
9
5
2
4
4
4
4
2
2
8
4
3
1
2
2
8
