(9) Power supply
(10) Fuseholder
(11) Housing screws
(12) DIP-switches
(13) Control LED
(14) DMX-Out socket
(15) DMX-In socket
(16) Lamp system

INSTALLATION

Installing/Replacing the lamp

For the installation, you need one of the following lamps:
OMNILUX OSD 90V/250W GX-9,5 2000h 6700K
OSRAM HSD250 90V/250W GY-9,5 2000h
PHILIPS MSD250 90V/250W GY-9,5 2000h
OSRAM HSD250/2 90V/250W GY9,5 3000h 7800K
PHILIPS MSD250/2 90V/250W GY-9,5 2000h
SYLVANIA BA250/2 SE D 90V/250W GY-9,5
The lamp must only be changed when wearing appropriate protective clothing (protection glasses, protection
gloves, helmet with sight, leather apron).
DANGER TO LIFE!
Only install the lamp with the device switched off!
Unplug from mains before!
No. 89106005
No. 89106010
No. 89106015
No. 89106110
No. 89106115
No. 89106120
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
