NordicTrack NTC07940 User Manual

NordicTrack NTC07940 User Manual

Nordic track user's manual exercise cycle ntc07940
Hide thumbs Also See for NTC07940:
Table of Contents

Advertisement

Quick Links

Patent Pending
Model No. NTC07940
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
satisfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTC07940 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTC07940

Summary of Contents for NordicTrack NTC07940

  • Page 1 Patent Pending Model No. NTC07940 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee satisfaction through direct assis- tance from our factory.

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. .Back Cover NordicTrack is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the exercise cycle. 1. Read all instructions in this manual before using the exercise cycle. Use the exercise cycle only as described. 2.

  • Page 4: Before You Begin

    (excluding holidays). To help us assist you, mention the product model number and serial number when calling. The model number is NTC07940. The serial number can be found on a decal attached to the exer- cise cycle (see the front cover of this manual for the location of the decal).

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench Use the drawings below to identify the small parts used during assembly.
  • Page 6 2. While another person lifts the rear of the Frame (1), attach the Rear Stabilizer (16) to the Frame with four M8 x 40mm Button Screws (54) and four M8 Split Washers (55). 3. While another person holds the Upright (2) in the posi- tion shown, connect the Upper Wire Harness (97) to the Lower Wire Harness (43).
  • Page 7 5. Have another person hold the Console (4) near the Upright (2). Connect the Upper Wire Harness (97) to the wire har- ness on the Console (4). Connect the Pulse Wire (3) to the pulse wire on the Console. Next, locate the two ground wires that are connected with a screw to the Upright (2), and connect the ground wires to the two smallest wires on the Console.
  • Page 8 8. Attach the Backrest (62) and the Seat Back (98) to the Backrest Frame (42) with two M6 x 20mm Button Screws (20), an M6 x 45mm Button Screw (80), and an M6 Washer (60). Slide the Backrest Frame (42) onto the Seat Frame (7).
  • Page 9 INSTALLING THE RECEIVER FOR THE OPTIONAL CHEST PULSE SENSOR If you purchase the optional chest pulse sensor (see page 21), follow the steps below to install the receiver included with the chest pulse sensor. Remove the access door from the underside of the Console (4).

  • Page 10: How To Operate The Exercise Cycle

    HOW TO OPERATE THE EXERCISE CYCLE HOW TO MOVE AND LEVEL THE EXERCISE CYCLE Stand in back of the exercise cycle, and lift the exer- cise cycle until it can be moved on the front wheels. Move the exercise cycle to the desired location and carefully lower it.

  • Page 11: Console Diagram

    CONSOLE DIAGRAM Note: If there is a sheet of clear plastic on the face of the console, remove it before using the console. FEATURES OF THE CONSOLE The advanced console offers a selection of features designed to make your workouts more enjoyable and effective.

  • Page 12: How To Use The Manual Mode

    HOW TO USE THE MANUAL MODE Press any button on the console or begin pedaling to turn on the console. Note: The console requires four 1.5V “D” batteries (see assembly step 10 on page 8). Press any button on the console or begin pedal- ing to turn on the console.
  • Page 13 Note: The console can display speed and distance in either miles or kilometers. To find which unit of measurement is selected, you must select the console’s user mode. Hold down the Program Select button for about three seconds. The letter “E” for English miles or the letter “M” for metric kilometers will appear in the left display.
  • Page 14 HOW TO USE RESISTANCE AND PACE PROGRAMS Press any button on the console or begin pedaling to turn on the console. See step 1 on page 12. Select one of the six resistance and pace programs. When the power is turned on, the man- ual mode will be selected.
  • Page 15 Turn on the fan if desired. See step 6 on page 13. When the program is finished, the console will automatically turn off. See step 7 on page 13. HOW TO USE HEART RATE PROGRAMS Each heart rate program helps you to keep your heart rate near a certain percentage of your maximum heart rate during your workout.
  • Page 16 rate setting for the current segment. The lit indicators in the bar will show your actual pace. When you hold the handgrip pulse sensor or wear the optional chest pulse sen- sor, the console will periodically compare your heart rate to the target heart rate setting for the current segment;...
  • Page 17 HOW TO CONNECT YOUR CD PLAYER, VCR, OR COMPUTER To use iFIT.com CDs, the exercise cycle must be con- nected to your portable CD player, portable stereo, home stereo, or computer with CD player. See pages 17 and 18 for connecting instructions. To use iFIT.com videocassettes, the exercise cycle must be connected to your VCR.
  • Page 18 HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of the audio cable into the jack beneath the console.
  • Page 19 HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 18.
  • Page 20 HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS To use iFIT.com CDs or videocassettes, the exercise cycle must be connected to your portable CD player, portable stereo, home stereo, computer with CD play- er, or VCR. See HOW TO CONNECT YOUR CD PLAYER, VCR, OR COMPUTER on page 17.
  • Page 21 HOW TO USE PROGRAMS DIRECTLY FROM OUR WEB SITE Our Web site at www.iFIT.com allows you to play iFIT.com audio and video programs directly from the internet. To use programs from our Web site, the exer- cise cycle must be connected to your home computer. See HOW TO CONNECT YOUR COMPUTER on page 18.

  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the exercise cycle regularly. To clean the exercise cycle, use a soft, damp cloth. Keep liquids away from the console and keep the console out of direct sunlight. HOW TO ADJUST THE REED SWITCH If the console does not display correct feedback, the reed switch should be adjusted.

  • Page 23: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: • Before beginning this or any exercise pro- gram, consult your physician. This is espe- cially important for individuals over the age of 35 or individuals with pre-existing health problems. • The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.

  • Page 24: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 25: Part List

    PART LIST—Model No. NTC07940 Key No. Qty. Description Frame Upright Pulse Wire Console Seat Rail Pulse Sensor/Wire Seat Frame Seat Rail Endcap Seat Seat Knob Seat Carriage Seat Frame Endcap Front Stabilizer Cover Rear Stabilizer Cover Front Stabilizer Rear Stabilizer...

  • Page 26: Exploded Drawing

    EXPLODED DRAWING—Model No. NTC07940 R1203A...
  • Page 27 NTC07940 R1203A...

  • Page 28: How To Order Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • the MODEL NUMBER of the product (NTC07940) • the NAME of the product (NordicTrack •...
