14. Reinstall the base cover assembly
15. Reinstall the removable battery. See "Replacing the removable battery" on page 115.
16. Turn the computer over again. Connect the ac power adapter and all cables to the computer.

Replacing the internal-storage-drive cable and cable bracket

Before you start, print these instructions. Read the important safety information first. See "Important
safety information" on page vi.
To replace the internal-storage-drive cable and cable bracket, do the following:
Note: Depending on the computer model, the internal storage drive and drive cable that come with your
computer might look different from the illustrations in this topic.
1. Disable the built-in battery. See "Disabling the built-in battery" on page 113.
2. Turn off the computer and disconnect the ac power adapter and all cables from the computer.
3. Close the computer display and turn the computer over.
4. Remove the removable battery. See "Replacing the removable battery" on page 115.
5. Loosen the screws that secure the base cover assembly
124
ThinkPad X260 User Guide
1 and tighten the screws
1 . Then remove the base cover assembly
2 .
2 .
