  • Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Valor 3000 Series Instruction Manual...

  • Page 3: Safety Precautions

    Valor 3000 Series Scales EN-1 1. INTRODUCTION This manual contains installation, operation and maintenance instructions for the Valor 3000 Series Scales. Please read the manual completely before using the scale. 1.1 Safety Precautions Please follow these safety precautions: • Verify that the AC Adapter input voltage matches the local AC power supply.

  • Page 4: Installation

    EN-2 Valor 3000 Series Scales TABLE 1-1. CONTROL FUNCTIONS. Button Functions Short Press: (when off) Turns scale on O/T On/Off (when on) Sets display to zero Tares weight of item on pan Long Press: Turns the scale off Short Press...

  • Page 5: Transport Lock

    Valor 3000 Series Scales EN-3 Figure 2-1. Leveling the Scale. 2.3. Transport lock Open the battery cover. Move the transport lock switch to “Unlock” position. Install 4 C (LR14) batteries, if desired. Reinstall the battery cover Figure 2-2. Battery Installation.

  • Page 6: Initial Calibration

    EN-4 Valor 3000 Series Scales Figure 2-3. Power Connection and Sealing 2.5 Initial Calibration When the scale is first installed, it should be calibrated to ensure accurate weighing results. Press and hold the ENTER/Cal button until CAL is displayed. When the button is again pressed and released, the display shows -C- while zero reading is stored.

  • Page 7: Percent Mode

    Valor 3000 Series Scales EN-5 3.2 Percent Mode Use this mode to measure the weight of a sample as a percentage of a reference weight. 1. Press MODE/UNIT/Menu until Set.rEF and the % icon are displayed. 2. Press No to use the reference weight in memory and proceed to step 6.

  • Page 8: Menu Navigation

    EN-6 Valor 3000 Series Scales 4. SETTINGS The Menu allows the user to customize scale settings. 4.1 Menu Navigation Press and hold MODE/UNIT/Menu button until SEtUP is displayed, then release it. Press Yes to enter the displayed menu. or press No to advance to the next menu.

  • Page 9: Power On Unit

    Valor 3000 Series Scales EN-7 POWER ON UNIT Set the unit of measure displayed at startup to g, kg, lb, oz or lb:oz. GLOBAL RESET Select YES (reset menus to factory defaults) or NO (do not reset). Units will be set to factory defaults.

  • Page 10: Pound Ounce Unit

    EN-8 Valor 3000 Series Scales Advance to the Unit/Mode menu (Yes) or back to Setup (No). 4.3 Unit/Mode Menu GRAM UNIT Set grams ON or OFF. KILOGRAM UNIT Set kilograms ON or OFF. POUND UNIT Set pounds ON or OFF.

  • Page 11: Legal For Trade

    Valor 3000 Series Scales EN-9 5. LEGAL FOR TRADE When model V31XW301, V31XW3, V31XW6, V31X3N or V31X6N is used in trade or a legally controlled application it must be set up, verified and sealed in accordance with local weights and measures regulations. It is the responsibility of the purchaser to ensure that all pertinent legal requirements are met.
  • Page 12 EN-10 Valor 3000 Series Scales 5.3 Sealing The local weights and measures official or authorized service agent must apply a security seal to prevent tampering with the settings. Refer to the illustrations below for sealing methods. Wire Seal Paper Seal...

  • Page 13: Maintenance

    United States call toll-free 1-800-526-0659 between 8.00 AM and 5:00 PM EST. An Ohaus product service specialist will be available to provide assistance. Outside the USA, please visit our web site, www.ohaus.com to locate the Ohaus office nearest you.

  • Page 14: Technical Data

    EN-12 Valor 3000 Series Scales 7. TECHNICAL DATA The technical data is valid under the following ambient conditions: Ambient temperature: 0°C to 40°C Relative humidity: 10% to 95% relative humidity, non-condensing Height above sea level: Up to 4000 m Operability is assured at ambient temperatures between 0°C and 40°C Power: AC adapter 9VDC @ 1.2A max.
  • Page 15 Valor 3000 Series Scales EN-13 TABLE 7-1. SPECIFICATIONS V31XW3/ V31XW6/ Model V31X3 V31X6 V31XW301 V31X3N V31X6N Capacity 3000 6000 3000 6000 Repeatability (g) ±1 ±0.2 ±1 ±2 Linearity (g) Approval Class Ingress Protection IP65 / * Weighing Units g, kg, lb, oz, lb:oz...

  • Page 16: Capacity And Readability

    EN-14 Valor 3000 Series Scales 7.2. Capacity and Readability TABLE 7-2. CAPACITY AND READABILITY SECURITY MODELS UNITS SWITCH V31XH202 V31XH402 V31XH2 V31XH4 V31X501 200.00 400.00 2000.0 4000.0 500.0 x 0.01 x 0.01 x 0.1 x 0.1 x 0.1 0.20000 0.40000 2.0000...
  • Page 17 Valor 3000 Series Scales EN-15 TABLE 7-2. CAPACITY AND READABILITY MODELS SECURITY UNITS V31XW3 / V31XW6 / SWITCH V31X3 V31X6 V31XW301 V31X3N V31X6N 300.0 3000 6000 x 0.2 3000 6000 300.0 3000.0 6000 x 0.1 x 0.5 0.3000 3.000 6.000 x 0.0002...
  • Page 18 EN-16 Valor 3000 Series Scales 7.3 Drawings Figure 7-1. All Models except V31XH202, V31XH402, V31X501 Figure 7-2. Models V31XH202, V31XH402, V31X501...
  • Page 19 Valor 3000 Series Scales EN-17 Accessories Slide accessories over the rear of the pan assembly and position them as shown in the illustration below. Figure 7-3. Sandwich pan Figure 7-4. French fries holder Figure 7-5. Ice cream cone holder...
  • Page 20 This product conforms to the EMC directive 2004/108/EC, the Low Voltage Directive 2006/95/EC and the Non-automatic Weighing Instruments Directive 90/384/EEC. The complete Declaration of Conformity is available from Ohaus Corporation. AS/NZS4251.1 Emission, AS/NZS4252.1 Immunity NSF/ANSI 169 – 2005 NSF/ANSI /3-A 14159-1 - 2002...
  • Page 21 This Class B digital apparatus complies with Canadian ICES-003. ISO 9001 Registration In 1994, Ohaus Corporation, USA, was awarded a certificate of registration to ISO 9001 by Bureau Veritus Quality International (BVQI), confirming that the Ohaus quality management system is compliant with the ISO 9001 standard’s requirements.

  • Page 22: Limited Warranty

    During the warranty period Ohaus will repair, or, at its option, replace any component(s) that proves to be defective at no charge, provided that the product is returned, freight prepaid, to Ohaus.
