Nobles SpeedGleam Operator And Parts Manual

36 volt dust control burnisher
Hide thumbs Also See for SpeedGleam:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual, Operator and Parts Manual
SpeedGleam
Model No.:
608525 – SpeedGleam
609251 – SpeedGleam Can. Pac
608344 – SpeedGleam Plus
609252 – SpeedGleam Plus Can. Pac
NOBLES
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
CUSTOMER SERVICE: 1-800-365-6625
FAX: 1–800–678–4240
/Plus
R
36 Volt Dust Control Burnisher
Operator and Parts Manual
608382
Rev. 00 (09-99)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpeedGleam and is the answer not in the manual?

Questions and answers

Related Manuals for Nobles SpeedGleam

Summary of Contents for Nobles SpeedGleam

  • Page 1 36 Volt Dust Control Burnisher Model No.: Operator and Parts Manual 608525 – SpeedGleam 609251 – SpeedGleam Can. Pac 608344 – SpeedGleam Plus 609252 – SpeedGleam Plus Can. Pac NOBLES 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 608382 CUSTOMER SERVICE: 1-800-365-6625 FAX: 1–800–678–4240...

  • Page 2: Electrical Diagrams

    ELECTRICAL DIAGRAMS SpeedGleamR Wiring BATTERY AMMETER OPTIONAL EMERGENCY STOP DOWN MAIN ACTUATOR OPTIONAL KEY SWITCH HARNESS CONNECTOR OPTIONAL ACTUATOR MOTOR HOUR METER FLASHER (OPTIONAL) MAIN CIRCUIT BREAKER OPTIONAL CHARGER RELAY CUTOFF OPTIONAL SWITCH LOW VOLTAGE NEGATIVE CUT-OFF STANDOFF MOTOR PAD MOTOR CONTACTOR PAD MOTOR SAFETY SWITCH...
  • Page 3 ELECTRICAL DIAGRAMS SpeedGleamR Ladder (3) 12 VOLT BATTERIES 36 VDC -44- -RED- -31- -BLK- MASTER CIRCUIT BREAKER -15- -BLK- -50- -34- -10- -14- -RED- EMERGENCY MAIN -13- -BLK- SWITCH -32- -GRN- STOP SWITCH OPTIONAL OPTIONAL CHARGER BATTERY CUT-OFF METER SWITCH OPTIONAL -9- -BLK- -23- -BLK-...
  • Page 4 ELECTRICAL DIAGRAMS SpeedGleamR Plus Wiring AMMETER BATTERY OPTIONAL EMERGENCY STOP 4.7K ADJUSTABLE FORWARD BLU BRN BRUSH/ SOLUTION DOWN MAIN DIRECTION ACTUATOR SWITCH OPTIONAL KEY SWITCH HARNESS LOCKABLE CONNECTOR REVERSE ACTUATOR MOTOR HOUR METER (OPTIONAL) FLASHER ROLL SWITCHES MAIN MAIN CIRCUIT BREAKER DRIVE MOTOR...
  • Page 5 ELECTRICAL DIAGRAMS SpeedGleamR Plus Ladder (3) 12 VOLT BATTERIES 36 VDC -44- -RED- MASTER -31- -BLK- CIRCUIT BREAKER -34- -10- -14- -15- -BLK- -50- -RED- MAIN SWITCH -13- -BLK- -32- -GRN- BATTERY -24- METER -7- -BLK- -GRN- MAIN -6- RED -ORG- -12- -20- -RED- -21- -BLK-...

  • Page 6: Parts List

    PARTS LIST MAIN HOUSING GROUP 19 20 SpeedGleamR/Plus (03–98)
  • Page 7 900210 DBAG, CLOTH (OPTION) 578 187 000 SCREW, M6X1.0X12 604237 DBAG, PAPER FILTER PK=10 606684 STOP, MOTOR 608383 DECAL, SPEEDGLEAM PLUS 608523 DECAL, SPEEDGLEAM 604276 BRACKET, MOTOR STOP 608379 CHASSIS, GREEN 630450 WHEEL, RUBBER DIA 76 X 23 WD 140932...

  • Page 8: Pad Driver Group

    PARTS LIST PAD DRIVER GROUP 11 12 SpeedGleamR/Plus (03–98)
  • Page 9 PARTS LIST PAD DRIVER GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 604278 BRACKET, MOTOR 140201 SCREW, 3/8-16X3/4 HXHDCP 604333 SPRING, EXT 1X.095X5 069 760 023 WASHER, FLAT .77X1.26X.03 140284 NUT, M6X1.0 NYLOCK 27073 ASM., DRIVER PAD 630431 SCREW, M6X1.0X40 HXHDCP 27900 HUB, PAD DRIVER 140890...

  • Page 10: Drive Group (Plus Model)

    PARTS LIST DRIVE GROUP (Plus Model) PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 603277 FRAME WELDMENT 140431 SPRING, EXT 1X.095X5 640013 WHEEL, 8"DIA, 2"WIDE NEOPRENE 603272 BRACKET, SPRING 604293 SPACER, 3/4X4X1/8 600952 ACTUATOR 602881 BRACKET, TRANSAXLE MTG 604076 PIN, CLEVIS 10X28MM 140333 WASHER, M10 SPLITLOCK 578421...

  • Page 11: Wheel Group (Standard Model)

    PARTS LIST WHEEL GROUP (Standard Model) PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 603277 FRAME WELDMENT 578421 PIN, COTTER 25656 WHEEL, 8X1-5/8 130133 TERMINAL 103071 BEARING, WHEEL REPLACEMENT 603267 PLATE, PIVOT ARM 069 762 098 SCREW, M6X1.0X16 FLTPHL 602883 SPACER, 3/4X4X1/8 603275 AXLE WELDMENT...
  • Page 12 PARTS LIST CONTROL CONSOLE GROUP (Plus Model) ELECTRICAL GROUP Wire Harnesses SpeedGleamR/Plus (06–99)
  • Page 13 PARTS LIST CONTROL CONSOLE GROUP (Plus Model) PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 200823 GRIP, HANDLE TUBE 140155 BUSHING 27099 BUSHING 606550 KNOB, SPEED CONTROL 604402 HANDLE, TUBE 140024 WASHER, LOCK 1/2 603848 GAUGE, PAD PRESSURE 602886 PIN, SPRING RETURN 578 141 000 SCREW, M5X10MM 601118...
  • Page 14 PARTS LIST CONTROL CONSOLE GROUP (Standard Model) ELECTRICAL GROUP Wire Harnesses SpeedGleamR/Plus (03–98)
  • Page 15 PARTS LIST CONTROL CONSOLE GROUP (Standard Model) PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 200823 GRIP, HANDLE TUBE 140024 WASHER, LOCK 1/2 27099 BUSHING 602886 PIN, SPRING RETURN 604402 HANDLE, TUBE 601118 SPRING, EXTENSION 603848 GAUGE, PAD PRESSURE 140829 SCREW, 6-32X1 578 141 000 SCREW, M5X10MM...

  • Page 16: Electrical/Battery Group

    PARTS LIST ELECTRICAL/BATTERY GROUP SpeedGleamR/Plus (06–99)
  • Page 17 PARTS LIST ELECTRICAL/BATTERY GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 604939 PANEL, CONTROL HOUSING 604298 TRAY, BATTERY 222519 PLUG 600394 BATTERY, 12V 215A (OPTIONAL) 069 762 009 GROMMET, DIA 25.4X03 611 116 000 CABLE, BATTERY #6 BLACKX15" 130175 PLUG, DOME .750 578 141 000 SCREW, M5X10...
