- Page 1 00_CV_3P098587-1_1.fm Page 1 Wednesday, October 23, 2002 4:15 PM DAIKIN ROOM AIR CONDITIONER MODELS FVXS25BVMB FVKS25BVMB Operation Manual FVXS35BVMB FVKS35BVMB FVXS50BVMB FVKS50BVMB English Deutsch Français Nederlands Español Italiano ÅëëçíéêÜ Portugues Russian...
- Page 2 00_CV_3P098587-1_1.fm Page 2 Wednesday, October 23, 2002 4:15 PM 3P098587-1 M02B053 (0212) HT...
-
Page 3: Table Of Contents
01_EN_3P098587-1_1.book Page 1 Thursday, December 5, 2002 6:01 PM CONTENTS READ BEFORE OPERATION Safety precautions ......... 2 Names of parts..........4 Preparation Before Operation ......7 OPERATION AUTO · DRY · COOL · HEAT · FAN Operation ............. 10 Adjusting the Air Flow Direction ....12 POWERFUL Operation ........ -
Page 4: Safety Precautions
• Do not attempt to repair, relocate, modify or reinstall the air conditioner by yourself. Incorrect work will cause electric shocks, fire etc. For repairs and reinstallation, consult your Daikin dealer for advice and information. • The refrigerant used in the air conditioner is safe. Although leaks should not occur, if for some reason any refrigerant happens to leak into the room, make sure it does not come in contact with any flame as of gas heaters, kerosene heaters or gas range. -
Page 5: Installation Site
01_EN_3P098587-1_1.book Page 3 Thursday, December 5, 2002 6:01 PM • Do not stand or sit on the outdoor unit. Do not place any object on the unit to avoid injury, do not remove the fan guard. • Do not place anything under the indoor or outdoor unit that must be kept away from moisture. In certain conditions, moisture in the air may condense and drip. -
Page 6: Names Of Parts
01_EN_3P098587-1_1.book Page 4 Thursday, December 5, 2002 6:01 PM Names of parts I Indoor Unit OF F I Opening the front grille How to open the grille: (page 22) Air outlet selection switch 12 13 • This setting blows air from upper outlet only. This setting automatically decides a blow •... -
Page 7: I Outdoor Unit
01_EN_3P098587-1_1.book Page 5 Thursday, December 5, 2002 6:01 PM I Outdoor Unit I I I I Indoor Unit 1. Photocatalytic deodorizing filter and • The operation mode refers to the following Air purifying filter: table. • These filters are attached to the inside of the air Temperature Air flow Mode... -
Page 8: Remote Controller
01_EN_3P098587-1_1.book Page 6 Thursday, December 5, 2002 6:01 PM I Remote Controller HOME LEAVE ON/OFF TEMP POWERFUL MODE SWING SILENT CANCEL TIMER < > ARC433A5, A6 1. Signal transmitter: • It selects the operation mode. • It sends signals to the indoor unit. (AUTO/DRY/COOL/HEAT/FAN) (page 10.) 2. -
Page 9: Preparation Before Operation
01_EN_3P098587-1_1.book Page 7 Thursday, December 5, 2002 6:01 PM Preparation Before Operation I To set the batteries Position + and – correctly! 1. Press with a finger and slide the front cover to take it off. 2. Set two dry batteries (AAA). 3. - Page 10 01_EN_3P098587-1_1.book Page 8 Thursday, December 5, 2002 6:01 PM Preparation Before Operation I To operate the remote controller • To use the remote controller, aim the transmitter at the indoor unit. If there is anything to block signals between the unit and the remote control- ler, such as a curtain, the unit will not operate.
-
Page 11: Operation
01_EN_3P098587-1_1.book Page 9 Thursday, December 5, 2002 6:01 PM I To set the clock 1. Press “CLOCK button”. is displayed. blinks. 2. Press “TIMER setting button” to set the clock to the present time. HOME LEAVE ON/OFF Holding down “ ”... -
Page 12: Auto · Dry · Cool · Heat · Fan Operation
01_EN_3P098587-1_1.book Page 10 Thursday, December 5, 2002 6:01 PM OPERATION AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. -
Page 13: To Change Airflow Rate Setting
01_EN_3P098587-1_1.book Page 11 Thursday, December 5, 2002 6:01 PM I To change the air flow rate setting 5. Press “FAN setting button”. DRY mode AUTO or COOL or HEAT or FAN mode Five levels of air flow rate setting from “ ”... -
Page 14: Adjusting The Air Flow Direction
01_EN_3P098587-1_1.book Page 12 Thursday, December 5, 2002 6:01 PM Adjusting the Air Flow Direction You can adjust the air flow direction to increase your com- fort. I To adjust the horizontal blade (flap) 1. Press “SWING button”. The display will light up and the flaps will begin to swing. -
Page 15: Air Flow Selection
01_EN_3P098587-1_1.book Page 13 Thursday, December 5, 2002 6:01 PM I Air flow selection • Make air flow selection according to what suits you. When setting the air flow selection switch to • Air conditioner automatically decides the appropriate blowing pattern depending on the operating mode/situation. -
Page 16: Powerful Operation
01_EN_3P098587-1_1.book Page 14 Thursday, December 5, 2002 6:01 PM POWERFUL Operation POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. You can get the maximum capacity . I To start POWERFUL operation 1. Press “POWERFUL button”. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the settings which were used HOME LEAVE... -
Page 17: Outdoor Unit Silent Operation
01_EN_3P098587-1_1.book Page 15 Thursday, December 5, 2002 6:01 PM OUTDOOR UNIT SILENT Operation OUTDOOR UNIT SILENT operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is conve- nient during night. -
Page 18: Home Leave Operation
01_EN_3P098587-1_1.book Page 16 Thursday, December 5, 2002 6:01 PM HOME LEAVE Operation HOME LEAVE operation is a function which allows you to record your preferred temperature and air flow rate settings. I To start HOME LEAVE operation 1. Press “HOME LEAVE button” . •... -
Page 19: Use As Energy-Saving Mode
01_EN_3P098587-1_1.book Page 17 Thursday, December 5, 2002 6:01 PM I What’s the HOME LEAVE operation Is there a set temperature and air flow rate which is most comfortable, a set temperature and air flow rate which you use the most? HOME LEAVE operation is a function that allows you to record your favorite set tem- perature and air flow rate. -
Page 20: Timer Operation
01_EN_3P098587-1_1.book Page 18 Thursday, December 5, 2002 6:01 PM TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER in combination. I To use OFF TIMER opera- tion •... - Page 21 01_EN_3P098587-1_1.book Page 19 Thursday, December 5, 2002 6:01 PM I To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time (page 9.). 1. Press “ON TIMER button”. is displayed. blinks.
-
Page 22: Note For Multi System
01_EN_3P098587-1_1.book Page 20 Thursday, December 5, 2002 6:01 PM Note for Multi System 〈〈 〈〈 〈〈 〈〈 〉〉 〉〉 〉〉 〉〉 What is a “Multi System”? This system has one outdoor unit connected to multiple indoor units. room Outdoor unit I Selecting the Operation Mode room Living... - Page 23 01_EN_3P098587-1_1.book Page 21 Thursday, December 5, 2002 6:01 PM I Priority Room Setting The Priority Room Setting requires initial programming during installation. Please consult your retailer or dealer for assistance. The room designated as the Priority Room takes priority in the following situations; 1.
-
Page 24: Care And Cleaning
01_EN_3P098587-1_1.book Page 22 Thursday, December 5, 2002 6:01 PM CARE Care and Cleaning Before cleaning, be sure to stop the operation and CAUTION turn the breaker OFF. Units I Indoor unit, Outdoor unit and Remote controller 1. Wipe them with dry soft cloth. I Front grille 1. -
Page 25: I Air Filter
01_EN_3P098587-1_1.book Page 23 Thursday, December 5, 2002 6:01 PM Filters 1. Open the front grille. (page 22) 2. Remove the air filter. • Press the claws on the right and left of the air filter down slightly, then pull upward. 3. -
Page 26: Before A Long Idle Period
01_EN_3P098587-1_1.book Page 24 Thursday, December 5, 2002 6:01 PM Check Check that the base, stand and other fittings of the outdoor unit are not decayed or corroded. Check that nothing blocks the air inlets and the outlets of the indoor unit and the outdoor unit. Check that the earth wire is not disconnected or broken. -
Page 27: Trouble Shooting
01_EN_3P098587-1_1.book Page 25 Thursday, December 5, 2002 6:01 PM TROUBLE SHOOTING Trouble Shooting These cases are not troubles. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. •... -
Page 28: Check Again
01_EN_3P098587-1_1.book Page 26 Thursday, December 5, 2002 6:01 PM Check again. Please check again before calling a repair person. Case Check The air conditioner does not • Hasn’t a breaker turned OFF or a fuse blown? operate. • Isn’t it a power failure? (OPERATION lamp is off) •... -
Page 29: Call The Service Shop Immediately
01_EN_3P098587-1_1.book Page 27 Thursday, December 5, 2002 6:01 PM Call the service shop immediately. WARNING I I I I When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker OFF. Continued operation in an abnormal condition may result in troubles, electric shocks or fire. Consult the service shop where you bought the air conditioner. -
Page 30: Fault Diagnosis
01_EN_3P098587-1_1.book Page 28 Thursday, December 5, 2002 6:01 PM Fault diagnosis FAULT DIAGNOSIS BY REMOTE CONTROLLER In the ARC433A series, the temperature display sections on the main unit indicate corresponding codes. 1. When the TIMER CANCEL button is held down for 5 seconds, a “ ”... - Page 31 01_EN_3P098587-1_1.book Page 29 Thursday, December 5, 2002 6:01 PM LED ON OUTDOOR UNIT PCB 3MXS, 3MKS, 4MXS, 4MKS series GREEN MICROCOMPUTER MALFUNCTION NORMAL DETECTION LED-A LED1 LED2 LED3 LED4 DIAGNOSIS NORMAL CHECK INDOOR UNIT HIGH PRESSURE PROTECTOR WORKED OR FREEZE-UP IN OPERATING UNIT OR STAND-BY UNIT ∗...
- Page 32 01_EN_3P098587-1_1.book Page 30 Thursday, December 5, 2002 6:01 PM MEMO...
