Page 1: Operation Manual
DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS FVXS25KV1A FVXS35KV1A FVXS50KV1A FVXS35LV1A... -
Page 2: Table Of Contents
CONTENTS READ BEFORE OPERATION Safety Precautions ......... 2 Names of Parts ..........4 Preparation before Operation......7 OPERATION AUTO · DRY · COOL · HEAT · FAN Operation ............. 10 Adjusting the Airflow Direction ..... 12 POWERFUL Operation ........ 14 OUTDOOR UNIT QUIET Operation..... -
Page 3: Safety Precautions
READ BEFORE OPERATION Safety Precautions • Keep this manual where the operator can easily find it. • Read the precautions in this manual carefully before operating the unit. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. -
Page 4: Installation Site
• Do not place appliances that produce naked flames in places exposed to the airflow from the unit as this may impair combustion of the burner. • Do not block air inlets nor outlets. Impaired airflow may result in insufficient performance or trouble. •... -
Page 5: Names Of Parts
Names of Parts ■ Indoor Unit ■ Opening the Front Panel How to open the front panel: (page 26.) Air outlet selection switch • This setting blows air from upper outlet only. This setting automatically decides a blow • pattern depending on mode and conditions. •... -
Page 6: Outdoor Unit
■ Outdoor Unit ■ Indoor Unit 1. Titanium apatite photocatalytic • The operation mode refers to the following air-purifying filter: table. • These filters are attached to the inside of Temperature Mode Airflow rate the air filters. setting 2. Air outlet 22°C COOL AUTO... -
Page 7: Remote Controller
Names of Parts ■ Remote Controller <Open the lid> <ARC452A2> 1. Signal transmitter: 8. QUIET button: • It sends signals to the indoor unit. OUTDOOR UNIT QUIET operation (page 15.) 2. Display: 9. ECONO button: • It displays the current settings. ECONO operation (page 16.) (In this illustration, each section is shown 10. -
Page 8: Preparation Before Operation
Preparation before Operation ■ To set the batteries 1. Slide the front cover to take it off. Position + and – correctly! 2. Set two dry batteries AAA.LR03 (alkaline). 3. Set the front cover as before. ■ To operate the remote controller •... -
Page 9: To Set The Clock
Preparation before Operation ■ To set the clock 1. Press “CLOCK button”. “ ” is displayed. “ ” and “ ” blink. 2. Press “SELECT button” to set the current day of the week. 3. Press “CLOCK button”. “ ” blinks. 4. -
Page 10: Tips For Saving Energy
■ Turn the breaker on • After the power is turned on, the flap of the indoor unit opens and closes once to set the reference position. NOTE ■ Tips for saving energy • Be careful not to cool (heat) the room too much. Recommended temperature setting Keeping the temperature setting at a moderate level helps save energy. -
Page 11: Auto · Dry · Cool · Heat · Fan Operation
OPERATION AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. ■ To start operation 1. -
Page 12: To Change The Airflow Rate Setting
■ To change the airflow rate setting 5. Press “FAN setting button”. DRY operation AUTO or COOL or HEAT or FAN operation Five levels of airflow rate setting from “ ” to “ ” plus “ ” “ ” are available. The airflow rate setting is not variable. -
Page 13: Adjusting The Airflow Direction
Adjusting the Airflow Direction You can adjust the airflow direction to increase your comfort. ■ To adjust the flap (horizontal blade) 1. Press “SWING button”. • “ ” is displayed on the LCD and the flap will begin to swing. 2. - Page 14 ■ Airflow selection • Make airflow selection according to what suits you. When setting the airflow selection switch to • Air conditioner automatically decides the appropriate blowing pattern depending on the operating mode/situation. Operating mode Situation Blowing pattern • When the room has become fully •...
-
Page 15: Powerful Operation
POWERFUL Operation POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. You can get the maximum capacity. ■ To start POWERFUL operation 1. Press “POWERFUL button”. • POWERFUL operation ends in 20minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. -
Page 16: Outdoor Unit Quiet Operation
OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. ■ To start OUTDOOR UNIT QUIET operation 1. -
Page 17: Econo Operation
ECONO Operation ECONO operation is a function which enables efficient operation by limiting the maximum power consumption value. This function is useful for cases in which attention should be paid to ensure a circuit breaker will not trip when the product runs alongside other appliances. -
Page 18: Timer Operation
TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER in combination. ■ To use OFF TIMER operation • Check that the clock is correct. If not, set the clock to the present time. -
Page 19: To Combine On Timer And Off Timer
TIMER Operation ■ To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time. (page 8.) 1. Press “ON TIMER button”. “ ” is displayed. “ ” blinks. 2. Press “SELECT button” until the time setting reaches the point you like. -
Page 20: Weekly Timer Operation
WEEKLY TIMER Operation Up to 4 timer settings can be saved for each day of the week. It is convenient if the WEEKLY TIMER is set according to the family’s life style. ■ Using in these cases of WEEKLY TIMER An example of WEEKLY TIMER settings is shown below. - Page 21 WEEKLY TIMER Operation ■ To use WEEKLY TIMER operation Setting mode • Make sure the day of the week and time are set. If not, set the day of the week and time. (page 8.) Program 1 Program 2 Program 3 Program 4 [Monday] 25˚C...
- Page 22 8. Press “SELECT button” to select the desired temperature. • The temperature can be set between 10°C and 32°C. Cooling: The unit operates at 18°C even if it is set at 10 to 17°C. Heating: The unit operates at 30°C even if it is set at 31 to 32°C.
- Page 23 WEEKLY TIMER Operation Copy mode • A reservation made once can be copied another day of the week. The whole reservation of the selected day of the week will be copied. Program 1 Program 2 Program 3 Program 4 [Monday] 25˚C 27˚C 6:00...
- Page 24 ■ Confirming a reservation • The reservation can be confirmed. Press “ button”. • The day of the week and the reservation number of the current day will be displayed. Press “SELECT button” to select the day of the week and the reservation number to be confirmed.
-
Page 25: Note For Multi System
Note for Multi System This system has one outdoor unit connected to multiple indoor units. ■ Selecting the operation mode room B room 1. With the priority room setting present but inactive or not present. When more than 1 indoor unit is operating, priority is C room D room given to the first unit that was turned on. - Page 26 ■ OUTDOOR UNIT QUIET operation (page 15.) 1. With the priority room setting present but inactive or not present. When using the OUTDOOR UNIT QUIET operation feature with the multi system, set all indoor units to OUTDOOR UNIT QUIET operation using their remote controllers. When clearing OUTDOOR UNIT QUIET operation, clear one of the operating indoor units using their remote controller.
-
Page 27: Care And Cleaning
CARE Care and Cleaning Before cleaning, be sure to stop the operation and CAUTION turn the breaker off. Units ■ Indoor unit and remote controller 1. Wipe them with dry soft cloth. ■ Front panel 1. Open the front panel. •... -
Page 28: Air Filter
Filters 1. Open the front panel. (page 26.) 2. Remove the air filter. • Press the claws on the right and left of the air filter down slightly, then pull upward. 3. Take off the titanium apatite photocatalytic air-purifying filter. •... -
Page 29: Before A Long Idle Period
NOTE • Operation with dirty filters: (1) cannot deodorize the air. (2) cannot clean the air. (3) results in poor heating or cooling. (4) may cause odour. • To order titanium apatite photocatalytic air-purifying filter contact to the service shop there you bought the air conditioner. -
Page 30: Troubleshooting
TROUBLESHOOTING Troubleshooting These cases are not troubles. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. • This is to protect the air conditioner. •... -
Page 31: Check Again
Case Explanation ■ After operation is stopped: The outdoor fan rotates while the air conditioner is not in • The outdoor fan continues rotating for another 60 seconds operation. for system protection. ■ While the air conditioner is not in operation: •... -
Page 32: Call The Service Shop Immediately
Call the service shop immediately. WARNING ■ When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker off. Continued operation in an abnormal condition may result in troubles, electric shocks or fire. Consult the service shop where you bought the air conditioner. ■... -
Page 33: Fault Diagnosis
Fault diagnosis. FAULT DIAGNOSIS BY REMOTE CONTROLLER In the ARC452A series, the temperature display sections on the main unit indicate corresponding codes. 1. When the TIMER CANCEL button is held down for 5 seconds, a “ ” indication flashes on the temperature display section. - Page 34 Two-dimensional bar code is a code for manufacturing. 3P278434-1A M10B241A (1111) HT...
