Summary of Contents for RedLeaf RLC-DF2011
-
Page 2: Table Of Contents
INDEX 1. GENERAL INTRODUCTION .................... 6 1.1. Overview ........................6 1.2. Features ........................6 1.3. SPECIFICATIONS ......................7 1.3.1. Performance ......................7 2. FRAMEWORK ......................13 2.1. DIMENSIONS ......................13 2.2. STRUCTURE ......................14 3. INSTALLATION ......................15 3.1. DEVICE INSTALLATION ..................... 15 3.2. - Page 3 WELCOME Thank you for purchasing our IP camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguards and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
- Page 4 IMPORTANT SAFEGUARDS AND WARNINGS 1. ELECTRICAL SAFETY All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC in the IEC1-60950. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
- Page 5 7. ACCESSORIES Be sure to use all the accessories recommended by manufacturer. Before installation, please open the package and check all the components are included. Contact your local retailer ASAP if something is broken in your package.
-
Page 6: General Introduction
1. GENERAL INTRODUCTION 1.1. Overview This series IP camera integrates the traditional camera and network video technology. It adopts audio and video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series RLC uses standard H.264 video compression technology and MJPEG audio compression technology, which maximally guarantee the audio and video quality. -
Page 7: Specifications
1.3. SPECIFICATIONS 1.3.1. Performance Please refer to the following sheet for Red Leaf performance specification. -
Page 13: Framework
2. FRAMEWORK 2.1. DIMENSIONS Please refer to the following figures for the dimension information. The unit is mm. See Figure 2-1 through Figure 2-3. -
Page 14: Structure
2.2. STRUCTURE Please refer to the following figure for detailed information. See Figure 2-4. Please refer to the following sheet for detailed information. -
Page 15: Installation
3. INSTALLATION 3.1. DEVICE INSTALLATION This series RLC can be put on the table to realize surveillance. Or you can use the bracket or the in-ceiling installation to realize the hang function. Please refer to the steps listed below. STEP 1 Use the inner hexagonal wrench (provided) to loose the three inner hexagon screws in the dome cover and then open the cover. - Page 16 Adjust the device installation pedestal to the proper position and then draw the cable through the cable exit you just dug in the ceiling (wall). Line up the TOP direction of the device to the installation position map and then line up the three screw holes in the device pedestal to the three plastic expansion bolt holes in the installation position.
-
Page 17: Sd Card Installation
3.2. SD CARD INSTALLATION Important Some product series do not support the SD card storage function. Please shut down the power and then turn off the device before you install the SD card. STEP 1 Please refer to the step 1 in chapter 2.1 to open the device. STEP 2 Find the “SD CARD”... -
Page 18: Quick Configuration Tool
4. QUICK CONFIGURATION TOOL 4.1. OVERVIEW Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2. - Page 19 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 4-3. If you use device background upgrade port 3800 to login, other setups are all invalid. If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
-
Page 20: Web Operation
5. WEB OPERATION This series RLC product support the Web access and management via PC. Web includes several modules includes monitor channel preview, PTZ control, system configuration, alarm and etc. IP camera factory default setup: . IP address: 192.168.1.108. . User name: admin . - Page 21 If it is your first time to login in, system pops up warning information to ask you whether install control webrec.cab or not after you logged in for one minute. Please click OK button, system can automatically install the control. When system is upgrading, it can overwrite the previous Web too.
-
Page 22: Faq
6. FAQ... -
Page 23: Appendix Toxic Or Hazardous Materials Or Elements
Appendix Toxic or Hazardous Materials or Elements Note O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is below the relevant threshold of the SJ/T11363-2006 standard. X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. - Page 24 About RedLeaf Company: RedLeaf is a Canadian-based IT company offering state-of-the-art network security products fulfilling customers’ needs for cutting edge security technologies. Founded in 2002, RedLeaf internationally provides professional IP based video security solutions for surveillance, remote monitoring other security...
