Annex A
Operation frequencies
Channel Number RX Frequency (MHz)
1 446.00625
2 446.01875
3 446.03125
4 446.04375
5 446.05625
6 446.06875
7 446.08125
8 446.09375
Annex B
Sub - channel codes
CTCSS Code Chart
Code Freq (Hz) Code Freq (Hz)
1 67 11 97.4
2 71.9 12 100
3 74.4 13 103.5
4 77 14 107.2
5 79.7 15 110.9
6 82.5 16 114.8
7 85.4 17 118.8
8 88.5 18 123
9 91.5 19 127.3
10 94.8 20 131.8
DCS Code Chart
Code DCS Code Code DCS Code
39 023 60 143
40 025 61 152
41 026 62 155
42 031 63 156
43 032 64 162
44 043 65 165
45 047 66 172
46 051 67 174
47 054 68 205
48 065 69 223
49 071 70 226
50 072 71 243
51 073 72 244
52 074 73 245
53 114 74 251
54 115 75 261
55 116 76 263
56 125 77 265
57 131 78 271
58 132 79 306
59 134 80 311
TX Frequency (MHz)
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
446.09375
Code Freq (Hz) Code Freq (Hz)
21 136.5 31 192.8
22 141.3 32 203.5
23 146.2 33 210.7
24 151.4 34 218.1
25 156.7 35 225.7
26 162.2 36 233.6
27 167.9 37 241.8
28 173.8 38 250.3
29 179.9
30 186.2
Code DCS Code Code DCS Code
81 315 102 532
82 331 103 546
83 343 104 565
84 346 105 606
85 351 106 612
86 364 107 624
87 365 108 627
88 371 109 631
89 411 110 632
90 412 111 654
91 413 112 662
92 423 113 664
93 431 114 703
94 432 115 712
95 445 116 723
96 464 117 731
97 465 118 732
98 466 119 734
99 503 120 743
100 506 121 754
101 516
Annex C
Technical specifications
Frequency range : 446.00625 ... 446.09375 MHz
Channel spacing : 12.5 KHz
Radio Channels : 8
121 Sub-channels : 38 CTCSS / 83 DCS
Maximum RF output power : 0.5 W
Modulation : FM – F3E
Antenna type : Fixed
Battery type : 4.8V (Ni-MH pack)
Power adapter : 9V 210mA
IP-standard : IPX7 (submersible)
This product is in compliance with the essential requirements and other relevant provisions of the R & TTE directive
1999/5/EC.
The Declaration of conformity can be found on :
www.tristar.eu
Protalker PT-1078 (RC-6420)
