Kyocera ECOSYS M6026cidn Servise Manual

Hide thumbs Also See for ECOSYS M6026cidn:

Operation manual (397 pages)

Service manual (375 pages)

Quick installation manual (31 pages)

page of 16

/ 16
Bookmarks

Quick Links

Download this manual See also: Service Manual, Operating Manual

ECOSYS M6026cidn

ECOSYS M6526 idn

SERVICE

MANUAL

Published in March 2014

842PY112

2PYSM062

Rev.2

Need help?

Do you have a question about the ECOSYS M6026cidn and is the answer not in the manual?

Questions and answers

Summary of Contents for Kyocera ECOSYS M6026cidn

Page 1 ECOSYS M6026cidn ECOSYS M6526 idn SERVICE MANUAL Published in March 2014 842PY112 2PYSM062 Rev.2...
Page 2 2PX/2PY-1 CONTENTS 1-1 Specifications 1-1-1 Specifications ........................1-1-1 1-1-2 Parts names .......................... 1-1-6 (1) Machine (front side)......................1-1-6 (2) Machine (rear side)......................1-1-7 (3) Document processor ......................1-1-8 (4) Operation panel ........................ 1-1-9 1-1-3 Machine cross section ......................1-1-10 1-2 Installation 1-2-1 Installation environment......................
Page 3 ....1-5-1 (2) Drum......................... 1-5-1 (3) Toner ........................ 1-5-1 (4) How to tell a genuine Kyocera toner container..........1-5-2 1-5-2 Outer covers ......................1-5-3 (1) Detaching and refitting the rear upper cover, right upper cover, left upper cover and front cover..................1-5-3 (2) Detaching and refitting the right rear cover, right cover and right lower cover ....
Page 4 2PX/2PY-1 1-5-10 Optical section ........................1-5-45 (1) Detaching and refitting the laser scanner unit ..............1-5-45 (2) Detaching and refitting the scanner unit ................. 1-5-48 (3) Detaching and refitting the image scanner unit .............. 1-5-52 1-5-11 Document processor ......................1-5-78 (1) Detaching and refitting the document processor ............
Page 5 2PX/2PY-1 2-3 Operation of the PWBs 2-3-1 Power source PWB ....................2-3-1 2-3-2 Engine PWB .......................... 2-3-3 2-3-3 Main PWB..........................2-3-13 2-3-4 Drum relay PWB ........................2-3-21 2-3-5 DP drive PWB........................2-3-24 2-4 Appendixes 2-4-1 Appendixes ..........................2-4-1 (1) Maintenance kits....................... 2-4-1 (2) Repetitive defects gauge ....................
Page 6 2PX/2PY 1-1-1 Specifications Machine Specifications Item 3 in 1 model (without FAX) 4 in 1 model (with FAX) Type Desktop Printing method Electrophotography by semiconductor laser, tandem (4) drum system Originals Sheet, Book, 3-dimensional objects (maximum original size: Folio/Legal) Original feed system Fixed Cassette 60 to 163 g/m...
Page 7 2PX/2PY-2 Specifications Item 3 in 1 model (without FAX) 4 in 1 model (with FAX) Scanning system Flat bed scanning by CCD image sensor Photoconductor OPC drum (diameter 30 mm) Image write system Semiconductor laser Charging system Charger roller Touch down developing system Developing system Developer: 2-component Toner replenishing: Automatic from the toner container...
Page 8 2PX/2PY Document processor Item Specifications Original feed method Automatic feed Supported original types Sheet originals Maximum: A4/Legal Original sizes Minimum : A5/Statement Simplex: 50 to 120 g/m Original weights Duplex : 50 to 110 g/m Loading capacity 50 sheets (50 to 80 g/m ) or less 490 ×...
Page 9 2PX/2PY Scanner Item Specifications Windows XP (32bit/64bit), Windows Vista (32bit/64bit), Windows 7 (32bit/64bit), Windows 8 (32bit/64bit), Operating system Windows Server 2003 (32bit/64bit), Windows Server 2008 (32bit/64bit), Windows Server 2008 R2, Windows Server 2012 IBM PC/AT compatible CPU: Celeron 600 MHz or higher System requirements RAM: 128 MB or more HDD free space: 20 MB or more...
Page 10 2PX/2PY FAX (4 in 1 model (with FAX) only) Item Specifications Compatibility Communication line Subscriber telephone line Transmission time 3 s or less (33600 bps, JBIG, ITU-T A4 #1 chart) 33600/31200/28800/26400/24000/21600/19200/16800/14400/12000/9600/ Transmission speed 7200/4800/2400 bps Coding scheme JBIG/MMR/MR/MH Error correction Max.
Page 11 2PX/2PY 1-1-2 Parts names (1) Machine (front side) 1 1 1 1. Do 2. Contact glass 11. Main power switch 3. Original size Indicator plate 12. Toner container K 4. Operation panel 13. Toner container M 5. Inner tray lever 14.
Page 12 2PX/2PY (2) Machine (rear side) Figure 1-1-2 19. Rear cover 26. USB memory slot 20 Rear cover lever 27. USB interface connector 28. Network interface connector 29. LINE connector* 30. TEL connector* 24. Paper conveying unit 25. Power cord connector *: 4 in 1 model (with FAX) only 1-1-7...
Page 13 FS-C2526MFP FS-C2626MFP ECOSYS M6026cidn ECOSYS M6526cidn ECOSYS M6026cidn Type B ECOSYS M6526cidn Type B PARTS LIST Published in April 2014 2M8PL076 842M8126 Rev.6...
Page 14 For the purpose of this parts list, products are identified as following. FS-C2526MFP : (A) FS-C2626MFP : (AF) ECOSYS M6026cidn : (B) ECOSYS M6526cidn : (BF) ECOSYS M6026cidn Type B : (C) ECOSYS M6526cidn Type B : (CF) - 1 -...
Page 15 FIG. 1 Covers 2M8/2M9 (AF) (B),(C) (BF),(BC) (C),(CF) - 2 -...
Page 16 Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual Kyocera-Mita ECOSYS M6026cidn, M6526cidn service manual...

This manual is also suitable for:

Ecosys m6526 idn
