- Page 2 Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. The installation instructions do not apply to all types of vehicles, and are written as guidelines to assist in installing the system. Please consult an experienced technician if you are not comfortable installing the product.
- Page 3 System Installation and Wiring Note: Camera System installation on diesel vehicles may require a slightly different wiring install. Caution: This unit is designed to operate on a 12V/24V DC NEGATIVE GROUND electrical systems. Connecting to other types of electrical systems will cause damage to your vehicle. Please contact the manufacturer if you are unaware of the system type in your vehicle. Quick Installation: The 2.4 G wireless modules come in two parts, one is the “Transmitter”, the other is the “Receiver”, when installing, the “Transmitter”...
-
Page 4: Specifications
Receiver: DC 12V Output for Monitor DC 12V Input Video Input for Additional Monitor Installation Transcript: 1. Locate the reverse taillight wiring behind your vehicle's reverse light. You may need to remove an interior panel, or other cover, in order to locate the wiring. Connect the transmitter to the reverse light, then the camera to the transmitter. 2.
