User Manual
GETTING
STARTED?
EASY.
ZDF21001WA
ZDF21001XA
ZDF21001NA
EN User Manual
Dishwasher

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Zanussi ZDF21001WA

  • Page 1 User Manual GETTING STARTED? EASY. ZDF21001WA ZDF21001XA ZDF21001NA EN User Manual Dishwasher...
  • Page 2: Safety Information

    SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. CHILDREN AND VULNERABLE PEOPLE SAFETY This appliance can be used by children aged from 8 years and •...
  • Page 3: Safety Instructions

    Do not keep the appliance door open without supervision to • prevent to fall on it. Before maintenance, deactivate the appliance and disconnect • the mains plug from the mains socket. Do not use water spray and steam to clean the appliance. •...
  • Page 4 DISPOSAL WARNING! Risk of injury or suffocation. • Disconnect the appliance from the mains supply. • Cut off the mains cable and discard it. • Remove the door catch to prevent children and pets to get closed in the appliance.
  • Page 5: Easy Start

    EASY START On/off indicator Delay button Programme marker Programme knob Indicators Start button INDICATORS End indicator. Salt indicator. It is always off while the programme operates. Rinse aid indicator. It is always off while the programme operates.
  • Page 6: Information For Test Institutes

    PROGRAMMES Consumption values Degree of soil Programme Programme phases Type of load Duration Energy Water (min) (kWh) Normal soil • Prewash 1.039 Crockery and • Wash 50 °C cutlery • Rinses • Heavy soil • Prewash 140 - 1.3 - 1.5 13 - 15 Crockery, cut- •...
  • Page 7: The Water Hardness Table

    Do not use detergent and do not load the baskets. THE WATER HARDNESS TABLE German degrees French degrees Water softener mmol/l Clarke degrees (°dH) (°fH) level 47 -50 84 - 90 8.4 - 9.0 58 - 63 43 - 46 76 - 83 7.6 - 8.3 53 - 57...
  • Page 8: Daily Use

    • Release when Delay and start to flash. • Press . Indicators , Delay and flash. The current setting is indicated by the intermittent flashing of the indicator : e.g. 5 intermittent flashes + pause + 5 intermittent flashes = level 5. •...
  • Page 9: Adding Detergent

    ADDING DETERGENT If the programme has a prewash phase, put a small quantity of detergent also in compartment B. ADDING MULTI-TABLETS PROGRAMME SELECTION MODE The appliance must be in Programme selection mode to start a programme. If the control panel does not show this condition, do the Reset.
  • Page 10: Starting A Programme

    STARTING A PROGRAMME Open the water tap, close the door, select a programme, press OPTION DELAY With this option you can postpone the start of a programme of 3 hours. Set the programme, press Delay. Press to start the countdown. At the end of the countdown, the programme starts.
  • Page 11: Hints And Tips

    AT THE END OF THE PROGRAMME 5 min The indicator comes on. If you do not deactivate the appliance within 5 minutes all indicators goes off. This helps to decrease energy consumption. Turn the knob to . Close the tap. HINTS AND TIPS GENERAL THE WATER SOFTENER...
  • Page 12: Unloading The Baskets

    • If you use multi-tablets you can select the • Put hollow items (cups, glasses and pans) with Multitab option (if available). This option the opening down. increases the cleaning and drying results with • Make sure that cutlery and dishes do not bond the use of multi-tablets.
  • Page 13: Troubleshooting

    CLEANING THE FILTERS • Make sure that there are no residues of food or soil in or around the edge of the sump. • Put back in place the flat filter (C). Make sure that it is correctly positioned under the 2 guides. •...
  • Page 14: The Washing And Drying Results Are Not Satisfactory

    Problem and alarm code Possible solution You cannot activate the appliance. • Make sure that the mains plug is connected to the mains socket. • Make sure that there is no a damage fuse in the fuse box. The programme does not start. •...
  • Page 15: Technical Information

    Problem Possible solution The dishes are wet. • The programme does not have a drying phase or has a drying phase with low temperature. • The rinse aid dispenser is empty. • The quality of the rinse aid can be the cause. Refer to "Hints and tips"...
  • Page 16 WWW.ZANUSSI.COM/SHOP...

This manual is also suitable for:

Zdf21001xaZdf21001na
