INTRODUCTION
Thank you for using NS1 for your access control application. NS1 is a powerful access control system
which can be used for single door access, as well as for connection to any type of on-line access control
system.
NS1 units can also be mounted in an RS485 network without the necessity of an external access control
system.
NS1 as a single door unit offers many possibilities such as:
Access control
Unlock option
Day/Nightlock option (manual or automatic switching)
Long range reader (up to 45cm)
Optional use of PIN keypad
Using an external relay (to prevent potential tampering)
NS1 Manage software for stand-alone PC programming, event logging and user database
maintenance
REFERENCES
Master card usage is described in the NS1 User Guide (TD1168).
CONNECTIONS
The NS1 uses 12 wire E111235 AWM STYLE 2560 60°C 30V low voltage computer cable. The
connections are indicated below.
Wire
Stand-alone
Brown
Extra Ground
Violet
Relay out (O.C)
Black
Ground
Red
Power (+11.5 ... +12.5V DC)
Yellow
RS-485B in +
Blue
RS-485B out -
White
RS-485A in +
Pink
RS-485A out -
Grey
IO-1 Door contact input
Green
IO-2 Ext. Night lock/Rex input
Grey/Pink
IO-3 Forced entry output
Red/Blue
IO-4 Night lock enabled output
TD1166 rev1003
NS1 Installation Guide
Magstripe (ABA)
\ RDP output
\ RCP output
\ CLS output
\ Access input
Wiegand
DATA 0
DATA 1
STROBE
\ LED
1 - 8

Advertisement

   Summary of Contents for Honeywell NS1

  • Page 1 NS1 units can also be mounted in an RS485 network without the necessity of an external access control system.
  • Page 2 Power supply 12V DC NOTES: 1. The relay output is a 1A / 30V open collector. Black 2. With the NS1 only DC locks can be used when directly connected to the NS1. Figure 1 NS1 Connections 2 - 8...
  • Page 3 NS1 OPERATING LEVELS The NS1 Proximity Reader has two operating levels: • Installer Level. On this level the NS1 can be configured by the Installer. This level is also used to do typical Installer options. • User Level. On this level typical user options can be set, such as adding and voiding user cards, setting the door open time, etc.
  • Page 4 The following steps describe how to configure the NS1. 1. Wake up the NS1 from sleep mode. When powering up the NS1 for the first time, the NS1 is in the Installer sleep mode. This programmer will automatically become the Installer Remote Programmer. It is recommended to identify the Remote Programmer as the Installer by labelling it such.
  • Page 5 This period of time can be adjusted from 1 to 255 seconds. The default value is 2 sec, meaning that after presenting the tag to the NS1 reader, you have 2 seconds to open the door. If you want to use the default value, skip this step and proceed with the next.
  • Page 6 6. Set NS1 from Installer level to User level. To prevent tamper alarms, make sure the NS1 cover is in place. If for any reason you need to go back to the installer level, just present the Installer Remote Programmer in the RF field of the NS1 and enter 0*1*.
  • Page 7 Time-out to zero. The NS1 also has an anti-tamper switch and alarm. Tamper Protection The NS1 is equipped with an anti-tamper switch and alarm. And because it is both compact and it employs RF technology, it can be mounted behind any material except metal, with a maximum thickness of 5 cm (2”) for additional tamper protection.
  • Page 8 Honeywell Access Systems 135 West Forest Hill Avenue Oak Creek, WI 53154 PH: 414-766-1700 FAX: 414-766-1798 www.nciaccessworld.com 8 - 8 TD1166 rev1003...
