Philips GC9500 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
Product Feature
- Variable temperature : 4 selections by fabric type
- Dual pressure : Full pressure - 45
- Low heat generation : Outer surface do not get hot,
- Water tank capacity : 0.5 L for 2 to 3 hours ironing
- Transparent water tank for easy refill
- Adjustable water spray
- Automatic moisturizing
- Innovative sleeve board
- Easy maintenance
- Iron while seated
- Electronic lock for secure storage
Safety Feature
- Automatic safety shut-off after 15 minutes of no-use.
- Electronic lock activated only after the press has cooled
down.
Safety Information
- This product meets the requirements regarding
interference suppression on radio & TV
- Due to the high wattage of the product, only the
specified cord set must be used.
- After the product has been repaired, it should function
properly and has to meet the safety requirements and &
legal regulations as laid down & officially established at
this moment.
Published by Philips Domestic Appliances and Personal Care
06/09
kg
Half pressure - 22.5 kg
user stays cool.
Printed in the Netherlands
TECHNICAL INFORMATION
Voltage
Frequency
Power consumption
Ironing surface (main board) : 62 x 25 cm
Ironing surface (sleeve board) : 54 x 9 cm
Dimension
Weight
Automatic moisturizing
Super fi ne, adjustable water spray covers the entire ironing
area for creating steam IN the material. This soften the
fi bers in the fabric & provide a 'cushion' against heat shock,
resulting in high quality steam ironing.
Innovative sleeve board
Allows one to iron diffi cult items eg. yoke of a shirt, pleats,
jacket sleeves etc.
Easy maintenance
Creates steam without boiling water, so you use normal
tap water and avoid scale build-up; a system that is easy to
maintain.
Iron while seated
The ironing sessions may be done comfortably, while in a
sitting position. There is low heat generation, so the user stays
cool.
© Copyright reserved
Insta Press
GC9500
: 220 - 240 V
: 50 - 60 Hz
: 1000 W
: 70 (L) x 57 (W) x 23 (H) cm
: 13.7 kg
Subject to modification
