Integra Convector Plus Manual Inset Live Fuel Effect Gas Fire Installation and Users Instructions These instructions should be read by the installer before installation and then should be handed to the end user when the installation is complete. This is an official requirement and is the responsibility of the fitter of this appliance.
CONTENTS SECTION PAGE Notes for the Installer and End User Installation Requirements Installation Procedure - Standard 22” x 16” Installation Procedure - Decorative Cast Commissioning Removing the Baffles Technical Data Replacement Parts Trouble Shooting (GAS SAFE Engineer Only) 10 User Instructions Cleaning and Maintenance Fire Front Specifications Coal Layout Instructions...
NOTES FOR THE INSTALLER AND END USER THIS APPLIANCE IS INTENDED FOR DECORATIVE PURPOSES This appliance has been designed, tested and manufactured to BS7977-1:2009 relating to Decorative Gas Appliances and must be installed by a qualified GAS SAFE Registered Installer in accordance with the Gas Safety (Installation and use) regulations 1994 and all other relevant standards.
INSTALLATION REQUIREMENTS This appliance must only be installed in Great Britain or Ireland. 1. This fire is a natural gas appliance and has been designed for use with the following applications: a) Class I - Conventional brick or stone chimney as used for a solid fuel fire with a cross sectional dimension of 225mm x 225mm (9”...
INSTALLATION PROCEDURE FOR STANDARD 22” X 16” OPENING 1. Carefully lift the appliance out of the packaging taking care not to damage the ceramic components in the separate carton. 2. Remove the magnetic trim and store to one side to prevent any damage. 3.
Page 7
INSTALLATION PROCEDURE FOR STANDARD 22” X 16” OPENING CONTINUED ALTERNATIVE FIXING METHOD Where the drilling of the back panel is not practical, an alternative fixing method may be employed using the optional cable fixing kit provided. Drill four holes in the rear of the fireplace opening (Fig. 5). Securely fix the four eye bolts provided using suitable rawl plugs.
INSTALLATION PROCEDURE FOR DECORATIVE CAST SURROUND 1. Install the decorative cast surround into the fireplace opening and ensure it is fully sealed including the open area above the fire (see Fig. 7). 2. Carefully lift the fire box out of the packaging taking care not to damage the ceramic components in the separate carton.
REMOVING THE BAFFLES Fig. 9 Securing Screw Securing Screw Baffles It may be necessary to remove the two baffles from the outlet ducts - see spillage section on page 5. To remove the baffles, undo the two screws (one on each of the ducts) and slide out the two baffles.
TROUBLE SHOOTING (GAS SAFE ENGINEER ONLY) 1. The Piezo will not spark. Check: If the electrode is cracked or broken - Replace pilot assembly. If the HT lead is shorting out on the burner body - Locate where the short is occurring, isolate and/or re-route the lead.
USER INSTRUCTIONS THIS APPLIANCE IS INTENDED FOR DECORATIVE PURPOSES. Please also familiarise yourself with the Notes for the Installer and End User on page 4. OPERATION AND CONTROLS It is most important that the operator of this gas appliance has fully read and understood all the operating, cleaning and maintenance procedures as laid out in these instructions.
CLEANING AND MAINTENANCE CAST TEC Fires recommend that this appliance is serviced at regular 12 monthly intervals. The chimney or flue should also be checked regularly to ensure that all products of combustion are entering the flue and there is no excessive build up of soot.
COAL LAYOUT It is very important that all the coals are used and arranged as shown in order to achieve the desired Burner Tray flame picture. It may be necessary to remove some or all of the coals to clean them at some time. Cleaning must only be done using a soft brush.
Page 14
COAL LAYOUT CONTINUED 5. Pick out the smallest two coals and lay to one side, lay the first row of four loose coals on top of the front coal. Ensure the back of the coals are resting on the coal bed and there are even gaps all round (Fig. 18). Fig.
GUARANTEE Your appliance is guaranteed for one year from proof of purchase. Should the appliance prove defective within that period we agree to repair or replace (at our discretion) the component or appliance provided that: 1. The user can produce a receipt for proof of purchase/installation. 2.
Page 16
Issue B - 13/9/11 Unit 200 Glenfield Park Site 1 Philips Road Blackburn Lancashire BB1 5PF Tel: 01254 695244 Fax: 01254 695255 Web: www.legend-fires.com Email: info@legend-fires.com...
