Chapter 8. Solving problems

This section provides basic troubleshooting information to help you solve some
problems that might occur while you are setting up the switch module. The
Application Guide for your switch module provides more details about
troubleshooting the switch module.
If you cannot locate and correct a problem by using the information in this section,
see Appendix A, "Getting help and technical assistance," on page 29.

Running POST

To ensure that it is fully operational, the switch module processes a series of tests
during power-up or a restart (power-on self-test, or POST). These tests take
approximately 1 minute to complete. The management module reads the test
results and displays them for you. During normal operation, these tests are
completed without error, and the green OK LED is lit. However, if the switch module
fails POST, the amber switch-module error LED and the system-error LED on the
BladeCenter unit are lit. An event is stored in the event log in the system status
panel of the management module. The specific failure is displayed on the system
status I/O-module panel of the management module.
Note: For the locations and descriptions of the switch module LEDs, see

POST errors

There are two types of errors: noncritical and critical. A noncritical error applies to
one port, and the switch module is operational. You can continue to operate the
switch module; however, you must replace it as soon as possible. When critical
errors occur, the switch module does not operate. To view POST results, complete
the following steps:
1. Log on to the management module as described in the IBM BladeCenter
2. Turn off the power to the switch module; then, turn it on again. After POST is
3. Refresh the window to view the POST results. If a critical error occurs, replace
© Copyright IBM Corp. 2012
Chapter 6, "Information panels, LEDs, and external ports," on page 21.
Management Module Command-Line Interface Reference Guide. If necessary,
obtain the IP address of the management module from your system
administrator. The login window opens.
completed, the management module displays the results.
the switch module. If a noncritical error occurs, see the switch-module error log
for additional details.
