- Page 1 BRZF1759SE 240 litre Freezer d yo...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BRZF1759SE 240 litre freezer NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
5 – 6 Specifications of your freezer 7 – 8 Specifications Dimensions of the appliance Description of the appliance Using your Baumatic freezer 9 - 10 Before switching on During first use Control panel Switching on the appliance and setting the thermostat... -
Page 4: Environmental Note
This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the... -
Page 5: Important Safety Information
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. - Page 6 Do not place electrical devices inside of the appliance, such as mixers or ice cream makers. Service You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Baumatic Customer Care Department.
-
Page 7: Specifications Of Your Freezer
Specifications of your freezer o Total gross/net capacity: 270 / 240 litres o Energy efficiency class: o Freezer star rating: **** o Freezing capacity (kg / 24 hour): 15 kg o Adjustable thermostat o Manual defrost o Temperature rise warning indicator o 6 x Transparent freezer drawers o 1 X Freezer flap o 1 x Ice cube tray... -
Page 8: Description Of The Appliance
Description of the appliance 1) Top cover 2) Freezer flap 3) General freezer drawer (x 5) 4) Large freezer drawer 5) Adjustable feet 6) Thermostat control... -
Page 9: Using Your Baumatic Freezer
Using your Baumatic freezer Before switching on o Make sure that it has been installed by a suitably qualified person, information contained Baumatic’s installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. This will allow any refrigerant gasses that may have been disturbed during the transportation process to settle. -
Page 10: Control Panel
Control panel o GREEN light: This will turn on when the appliance has power. o RED light: This is the temperature-rise warning light. This will come on if the internal temperature of the appliance rises above acceptable levels. If this light comes on you should check that the drawers and door are closing properly and the thermostat is set to an appropriate level*. -
Page 11: Storing Food In The **** Freezer
o IMPORTANT: The ambient temperature of the room, the temperature of food and the amount of food that has been placed in the freezer and how often the door is opened, will all affect the temperature being maintained by the appliance. -
Page 12: Freezing Fresh Food
o IMPORTANT: If the food has started to defrost before power is restored, then DO NOT re-freeze the items. The food should be used within a relatively short period of time. Freezing fresh food o Fresh food should be packed into airtight containers or packaging. -
Page 13: Defrosting Frozen Food
o When shopping, be careful to choose food which is adequately packed and is provided with complete storage instructions. It should have been stored in a freezer where the temperature does not rise above -18°C. o Do not buy packages of food that are covered with frost. This could indicate that the package has thawed at least once before. -
Page 14: Saving Energy When Using Your Freezer
Saving energy when using your freezer Installing: o Install the appliance in a cool position. If it is placed in direct sunlight or next to an oven or other heat source, the energy consumption can increase substantially. o Ensure the appliance is installed with the correct ventilation requirements. -
Page 15: Cleaning And Maintenance
Disposing: If you're going to throw out your old freezer, see if there's a chlorofluorocarbons (CFCs) recycler in your area. The government department which looks after the environment in your area may be able to help you. Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR... -
Page 16: Defrosting The Freezer Compartment
Defrosting the freezer Over a period of time or if for example the door is left open for a prolonged period of time or the door gasket is not sealing correctly, then you could get ice building in the freezer section. If this occurs, then you should follow the steps below. -
Page 17: Installation
Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the freezer drawers. -
Page 18: Reversing The Door Swing
Reversing the door swing IMPORTANT: BEFORE COMMENCING THE DOOR REVERSAL PROCESS THE APPLIANCE MUST BE DISCONNECTED FROM YOUR MAINS SUPPLY. o We suggest that two people complete the door reversal process. o We recommend that the door reversal process is done before the appliance is placed in its final position. - Page 19 5) Remove the door. Remove the hinge-pin hole cap from the top of the door and insert it into the existing hinge-pin hole in the opposite side, thus exposing the new hinge-pin hole and covering the old hole. 6) Unscrew the plastic hinge-pin receiver from the bottom of the door and relocate it to the opposite side.
-
Page 20: Positioning
After the door has been reversed, you should check the door seal of the appliance. The seal should not be creased or crushed; otherwise there will be a gap between it and the inside of the door. o The seal must adhere properly all the way around the door. o If the seal is not adhering to the cabinet properly, then you should either:- 1. - Page 21 o Keep a minimum of 50 mm between your freezer and the back wall. There should also be a gap of 25 mm either side and 50 mm clear space above the freezer. If there is insufficient space this can create the sound of vibration, weakening of the appliance’s power and a waste of electricity.
-
Page 22: Troubleshooting
Troubleshooting IMPORTANT: If your freezer appears not to be operating properly, before contacting the Baumatic Customer Care Department, please refer to the checklist below. My freezer does not appear to be working/there is no power to my appliance. o Check that the plug is fully inserted into the power socket. - Page 23 Excessive frost and ice has built up in the freezer. o Make sure that the door is not left open for prolonged periods of time. o Check there is nothing preventing the door from closing correctly and that the door gasket is clean and intact. o It is normal for frost to build up over a period of time and when this happens you should follow the “Defrosting the freezer”...
- Page 24 - like plinths, or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
-
Page 25: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk... -
Page 26: Technical Data
Technical Data Manufacturer BAUMATIC LTD Model Number BRZF1759SE Product Category 8 – Upright Freezer Energy Efficiency Class (1) Annual Energy Consumption (2) 264 kWh Storage Volume of Fridge Compartment Storage Volume of Freezer 240 litres Compartment Star Rating Frost Free Compartments... -
