- Page 1 BRZF1760W 245 litre Freezer d yo...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BRZF1760W 245 litre freezer NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Specifications of your freezer 7 – 8 Specifications Dimensions of the appliance Description of the appliance Using your Baumatic freezer 8 - 10 Before switching on 8 - 9 During first use Switching on the appliance and setting the thermostat... -
Page 4: Environmental Note
This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the... -
Page 5: Important Safety Information
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. - Page 6 o Do not place any objects on top of the appliance, as this may damage the table top. Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.
-
Page 7: Specifications Of Your Freezer
You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Baumatic Customer Care Department. Specifications of your freezer o Total gross/net capacity:... -
Page 8: Description Of The Appliance
Description of the appliance Using your Baumatic freezer Before switching on o Make sure that it has been installed by a suitably qualified person, information contained Baumatic’s installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply. This will allow any refrigerant gasses that may have been disturbed during the transportation process to settle. -
Page 9: During First Use
o There can be an odour when you first switch on the appliance. It will lessen as the appliance starts to cool. During first use o When you first switch on the appliance, the compressor will run continuously for approximately 24 hours or until the freezer reaches a cool enough temperature. -
Page 10: Storing Food In The **** Freezer
o The freezer compartment temperature will vary between -18°C and -25°C during a typical cycle. o IMPORTANT: The ambient temperature of the room, the temperature of food and the amount of food that has been placed in the freezer and how often the door is opened, will all affect the temperature being maintained by the appliance. -
Page 11: Freezing Fresh Food
o If power is cut to your appliance, DO NOT open the door to the freezer. Your freezer will store food safely for approximately 9 hours. o IMPORTANT: If the food has started to defrost before power is restored, then DO NOT re-freeze the items. The food should be used within a relatively short period of time. -
Page 12: Storing Commercially Frozen Food
cause the bottle to burst during freezing. Storing commercially frozen food o The storage time and recommended temperature for storing commercially frozen foods are indicated on the packaging. o Always follow the manufacturer’s instructions for storage and use of frozen food. o When shopping, be careful to choose food which is adequately packed and is provided with complete storage instructions. -
Page 13: Saving Energy When Using Your Freezer
o After installation, the compressor may be noisier for a short period of time. Bubbling and burbling sound o This noise is emitted as the coolant flows through the pipework within the freezer. Saving energy when using your freezer Installing: o Install the appliance in a cool position. -
Page 14: Cleaning And Maintenance
o If you have a second appliance that is not used, make sure that it is stored with the power off and the door left ajar until it is actually required. Disposing: If you're going to throw out your old freezer, see if there's a chlorofluorocarbons (CFCs) recycler in your area. -
Page 15: Defrosting The Freezer Compartment
Defrosting the freezer Every so often you could get ice building in the freezer section. If this occurs, then you should follow the steps below. o Whilst defrosting the appliance, the food should be removed from the compartment and wrapped in several layers of paper and stored in a cool place. -
Page 16: Installation
nstallation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the freezer drawers. -
Page 17: Reversing The Door Swing
o When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath. Reversing the door swing The freezer is supplied with the door hinges on the right. You can choose whether you want the doors of your appliance to open from the left or the right according to your kitchen design or personal preference. -
Page 18: Positioning
o Unscrew the two screws (8) that hold the bottom right hand hinge (5) to the frame. Take away the bottom hinge (5). o Lift the door off the right upper hinge (2) and place it on a cushioned surface to prevent scratching it. o Unscrew the two screws (4) holding the front top panel (1) in position. -
Page 19: Troubleshooting
Troubleshooting IMPORTANT: If your freezer appears not to be operating properly, before contacting the Baumatic Customer Care Department, please refer to the checklist below. My freezer does not appear to be working/there is no power to my appliance. - Page 20 o Check that your mains supply voltage, corresponds to the voltage stated on the rating plate of your appliance. My freezer appears to be performing poorly. o Check that the appliance isn’t overloaded and that food hasn’t been packed too tightly into it. o The thermostat setting is too low;...
- Page 21 The freezer door will not open. o If the door has recently been opened and closed, you must wait for a few minutes before attempting to open the door again to allow the air pressure to equalise. The compressor runs continuously. o Make sure that the thermostat is set to the NORMAL position.
- Page 22 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
-
Page 23: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk... -
Page 24: Technical Data
Technical Data Manufacturer BAUMATIC LTD Model Number BRZF1760W Product Category 8 – Upright Freezer Energy Efficiency Class (1) Annual Energy Consumption (2) 259 kWh Storage Volume of Fridge Compartment Storage Volume of Freezer 225 litres Compartment Star Rating Frost Free Compartments... -
Page 25: Contact Details
United Kingdom Czech Republic Baumatic Ltd., Baumatic CR s.r.o. Baumatic Buildings, Lípová 665, 6 Bennet Road, 460 01, Liberec 4 Reading, Berkshire Czech Republic RG2 0QX United Kingdom +420 483 577 200 Sales Telephone www.baumatic.cz (0118) 933 6900 Sales Fax...
