MAINTENANCE
CONCENTRATOR MAINTENANCE
NOTE: The Invacare Concentrators are specifically designed to minimize
routine preventive maintenance at intervals of once per year. In places with high
dust or soot levels, maintenance may need to be performed more often. The
following must be performed at a minimum of one (1) year in service to assure
years of additional reliability. Only authorized or factory-trained personnel should
perform preventive maintenance on the concentrator. Power should be discon-
nected before beginning preventive maintenance on the Invacare concentrator.

CLEANING THE CABINET FILTERS

FIGURE 1 - CABINET FILTER LOCATION
NOTE: There are two (2) cabinet filters. One (1) is located on each side of
the cabinet (FIGURE 1).
1. Remove each filter and
depending on environmental conditions (
NOTE: Environmental conditions that may require more frequent cleaning
of the filters include but are not limited to: high dust, smoking, air pollutants, etc.
2. Clean the cabinet filters with a vacuum cleaner or wash in
warm soapy water and rinse thoroughly (
3. Dry the filters thoroughly before reinstallation.
FIGURE 2 - CLEANING THE CABINET FILTERS
PART ONE
CAUTION
18
Cabinet Filter
(located on both sides
of concentrator)
).
).
