6. Attach oxygen tubing from the humidifier bottle to oxygen outlet
connector on the oxygen concentrator.
Oxygen
Tubing
Humidifier Outlet
FIGURE 5 - ATTACHING THE OXYGEN TUBING
7. Attach the cannula/patient supply tubing to the humidifier bottle outlet.
8. After assembly, ensure that oxygen is flowing through the cannula.

POWER SWITCH

1. Press power switch to the
the audible alarm will come on for one second, indicating that the
unit is functioning properly. After one second, the only green

FLOWRATE

1. Turn the flowrate knob to the setting prescribed by your
physician or therapist.
WARNING
light will stay on.
FIGURE 6 - POWER SWITCH
OPERATING INSTRUCTIONS
position. All the panel lights and
15
Oxygen Outlet
Connector
On/Off (I/O)
Power Switch
PART ONE
